Indoor Unit Screen Display

Display and icons position may vary with models
For some model:
cooling power
indicator indicator
heating temp.
indicator indicator
For some model:
display
temp.
indicator
receiver
window
For some model:
display
temp.
indicator
receiver
window
Display content or position may be different from above graphics,
please refer to actual products.
receiver
window
drying
display
indicator
Power LED color
indicator:
Green status ON:
Red status OFF:
Mode LED color indicator:
White W Cool Mode
Red R Heat Mode
Green G Dry Mode
Power LED color indicator:
Green-status-ON.
Red -status-OFF.
Mode LED color indicator:
White W Cool Mode
Red R Heat Mode
Orange O Dry Mode
For some model:
heating
indicator
cooling
indicator
power
indicator
drying
indicator
(only for heating mode)
(only for heating mode)
6
display
receiver
window
