Introduction - Universal Remote Control MRF-260i Installation Manual

Introduction

The MRF-260i base station is an "addressable" base station. RF
Addressing gives you the ability to control as many as 60 identical
components throughout a house. To enable better range and reliabili-
ty the MRF-260i is equipped with the Narrow Band RF reception (like
the MRF-350i), so is only compatible with other Narrow Band remotes.
NOTE: The MRF-260i is ONLY compatible with Narrow Band remotes:
the current versions of the MX-3000i, MX-900i remote controls. The MRF-
260i is compatible with all MX-900is and MX-3000is. You can identify the
build date of a remote control by looking at the serial number. The first 6
digits indicate the build date. If the serial number appears as 122905
014054, the first 6 digits indicate that the remote was built on December
29, 2005.
1. MX/TX remote controls send
radio waves in every direction, so
your client enjoys "No More
Pointing" operation!
2. The MRF-260i's integrated Narrow
Band RF receiver receives commands
from any Narrow Band remote con-
trol.
3. The MRF-260i's built-in Front
Blaster sends commands to compo-
nents in the same cabinet space as
the MRF-260i.
MRF-260i B S
ASE
4. Self-adhesive "Flashers" affix to the
front panels of your client's
components (over the built-in IR sen-
sor). The Flashers relay commands to
components out of sight of the MRF-
260i's Front Blaster. The flashers plug
in to the MRF-260i's rear flasher line
outputs via their 10 foot cables.
Uniquely, the MRF-260i can also
connect to rear panel IR Inputs via its
two adjustable Outputs.
