Manual No.'12•SRK-T-137
RESIDENTIAL AIR-CONDITIONING
TECHNICAL MANUAL & PARTS LIST
WALL MOUNTED TYPE
RESIDENTIAL AIR-CONDITIONER
(Split system, air cooled cooling only type)
SRK10CMV, 13CMV
SRK10CMS, 13CMS
SRK10CMS-2, 13CMS-2
SRK19CMS, 25CMS
