SERVICE
YEPP
YP-S3
Refer to the service manual in the GSPN (see the rear cover) for the more information.
YEPP
Model Name : YP-S3
Model Code : YP-S3JCB/EDC
Manual
1. Precaution
2. Product Specification
3. Disassembly & Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. PCB Diagram
7. Schematic Diagram
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung YP-S3

Summary of Contents for Samsung YP-S3

  • Page 1 YEPP Model Name : YP-S3 Model Code : YP-S3JCB/EDC SERVICE Manual YEPP CONTENTS 1. Precaution 2. Product Specification 3. Disassembly & Reassembly 4. Troubleshooting 5. Exploded View & Part List 6. PCB Diagram 7. Schematic Diagram YP-S3 Refer to the service manual in the GSPN (see the rear cover) for the more information.
  • Page 2 Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com © Samsung Electronics Co.,Ltd. Jul. 2008 This Service Manual is a property of Samsung Electronics Printed in Korea Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law.

  • Page 3: Table Of Contents

    Contents 1. Precaution 1-1 Safety Precautions ................... 1-1 1-2 Static Electricity Precautions ................1-2 2. Product Specification 2-1 Product Feature ....................2-1 2-2 Specifications ....................2-3 2-3 Specifications Analysis ..................2-4 2-4 Accessories ......................2-6 3. Disassembly & Reassembly 3-1 Overall Disassembly & Reassembly ..............3-1 4.

  • Page 4: Precaution

    5. You should not put any object or liquid into product. Otherwise, it may cause failure or mal-operation. 6. If replacement material is required, service engineer should use materials with the same standard. The use of non-standardized materials may cause failure of product. Samsung Electronics...

  • Page 5: Static Electricity Precautions

    4. Minimize physical operation when handling with the ESD device for replacement without packing (Otherwise, namely friction between cloth fibers or lifting of the foot from the carpet floor may cause static electricity enough to damage the ESD device). Samsung Electronics...

  • Page 6: Product Specification

    - Design: Sparkling Design & Color - GUI & PUI: Sensitive Color/Stella GUI Sensitive image with middle LED button dimming effect  Grip & Touch - Grip → Wireless curved 9.8mm Grip → Soft Grip (No edge lines on part that touches hand) → More compact face size than K3 (42.5 x 94 mm) - Touch Pad → Stylish usability with soft control → Complete stylish look with LED lighting Samsung Electronics...
  • Page 7 Product Specification  Best Audio - DNSe 2.0+ → Enjoy natural sound with new DNSe 2.0+ audio technology → User EQ that can directly set and share precise audio effects - EP380 → EP380 is color-matched to the set and provides perfect audio quality and style (Judged by American audio quality specialist as superior to EP370) - Various Life Styles → Compatible with various accessories such as Cradle Speaker (Samsung Brand & 3rd Vendor), FM Transmitter (3rd Vendor), etc. Samsung Electronics...

  • Page 8: Specifications

    AUDIO: MPEG1/2/2.5 Layer3 (8kbps~320kbps, 8kHz~48kHz), WMA(48kbps~192kbps, 8kHz~48kHz), Ogg(Q1~Q10) File Compatibility VIDEO: SVI (Video: MPEG4, Audio: MP3 (44.1kHz, 128kbps), Resolution: 208X176, Frame Rate: 15fps) IMAGE: JPG (Progressive, Sequential Scanning, File Size: less than 3MB) Supported Number of Files Max. 5000 (Include folder) Earphone Output 20mW/Ch. (based on 16Ω) Output Frequency Range 40Hz~20kHz Signal to Noise Ratio 90 dB with 20 kHz LPF (based on 1kHz 0 dB) Maximum of 25 hours for music playback, Play Time Maximum of 4 hours for video playback (Based on: MP3 128kbps, Volume: 15, Normal Mode) Temperature Range for -5~35°C (23~95°F) Operation Case Metal Plating, Plastic Weight 1.87 oz Dimensions (W x H x D) 1.73 x 3.74 x 0.38 inch FM Frequency 87.5~108.0MHz FM Signal to 55 dB Noise Ratio FM Radio FM T.H.D FM Useable 38dBu Sensitivity Samsung Electronics...

  • Page 9: Specifications Analysis

    Product Specification 2-3 Specifications Analysis YP-S3 YP-S5 Model Name Photo Storage TYPE Flash memory (MLC) Flash memory (MLC) Size: 1.8" 262K QCIF TFT LCD Size: 1.8" 262K QCIF TFT LCD Display Color: 262K LCD Display Color: 262K LCD Display (Real color 65K color) (Real color 65K color) Resolution: 176(H) X 220(V) Resolution: 176(H) X 220(V) Platform Blues (SYS LSI) Blues (SYS LSI) Basic Battery Li-Polymer Li-Polymer Battery Capacity 580mAh 600mAh Playback Time (Earphone) 25 hrs 25 hrs Playback Time (Speaker) 5 hrs Color White / Black / Green / Blue / Red White / Black 512M Capacity ...
  • Page 10 Product Specification YP-S3 YP-S5 Model Name Photo   Programmed FM REC.   Encoding Line in Video     Tuner Etc. Voice Recording  Voice Recording Recording Format Function Recording Mode 4 Mode (32Kbps ~128Kbps)   Playlist Mobile Playlist (Favorite) Mobile Playlist (Favorite) PC Playlist (SPL, WPL) PC Playlist (SPL, WPL) Function Folder play (Browse)   (Music) Library  (Artist, Album, Genre, Title DB sorting)

  • Page 11: Accessories

    Product Specification 2-4 Accessories 2-4-1 Supplied Accessories Accessories Item Item code Remark Earphones AH59-01884A AH39-00899B USB Cable Samsung Service center AH46-00057B Program Installation CD Samsung Electronics...

  • Page 12: Disassembly & Reassembly

    FRONT side tapes. When separating them, be careful not to make scratches. FPC-TOUCH 1) Remove the FPC-TOUCH from the TOUCH-PAD’s CONNECTOR. When separating the FPC-TOUCH, use the pin set so as not to break Samsung Electronics...
  • Page 13 HOLDER-LED. 1) Use the pin set and pull up from the bottom to the top and remove the LCD. CABINET- 1) Remove the CABINET-MIDDLE MIDDLE screw. : CH,+,B,M1.4,L4,NI PLT 2) Remove the CABINET-MIDDLE. Samsung Electronics...
  • Page 14 MAIN PCB 1) Insert the pin set in one SIDE of the PCB, then use it as a lever to remove BATTERY the locking from the hook. 2) Remove the battery. 3) How it looks when completely dismantled. Samsung Electronics...
  • Page 15 MEMO Samsung Electronics...

  • Page 16: Troubleshooting

    Troubleshooting 4. Troubleshooting 4-1 Checkpoints by Error Mode ..............4-2 4-2 Upgrade Methods .................4-14 Samsung Electronics...

  • Page 17: Checkpoints By Error Mode

    L602: 1.1V, L603: 2.8V Power check Check Battery power Did XTAL1 CLOCK appear? Check BT1 +, - TP  Refer to wave pattern image of Fig. 4-1. Malfunction Check power at the Battery? Replace the Battery and recheck Finished Samsung Electronics...
  • Page 18 Troubleshooting IC200 IC201  S5L8700A02 Page, 7-3 IC800 IC103 IC601  PCB Bottom Page, 6-4 <Fig. 4-1> Samsung Electronics...
  • Page 19  Refer to wave pattern image of Fig. 4-2. Can audio stoppage or interference be heard? Can it be heard when playing other files? Do the symptoms appear even after upgrading to the latest firmware? Replace Board (Requires close inspection) Finished Samsung Electronics...
  • Page 20 Troubleshooting CON302  POWER Page, 7-8 IC300 IC700 IC701  PCB Top Page, 6-2 <Fig. 4-2> Samsung Electronics...
  • Page 21 Disassemble device and check for FPCB malfunction. Does the TOUCH KEY respond? If TOUCH is malfunctioning, replace TOUCH PAD. Replace Board Is the TOUCH PAD malfunctioning? (Requires close inspection) Disassemble device and check if the TOUCH PAD has come loose Samsung Electronics...
  • Page 22 When there is no FM reception  Refer to wave pattern image of Fig. 4-3. Does the XTAL700 Is the IC700 RTC operating? Replace IC 32.768 Khz Clock appear? Is there communication Solder and recheck with R700, R701 I2? Finished Samsung Electronics...
  • Page 23 Troubleshooting CON302  FM/RTC Page, 7-9 C300 IC700 IC701  PCB Top Page, 6-2 <Fig. 4-3> Samsung Electronics...
  • Page 24 Finished and does the MP3 play? firmware? Does it operate after Is the IC300 Pin 2 enabled? replacing the LCD?  Refer to wave pattern image of Fig. 4-4. Finished Replace Board (Requires close inspection) Samsung Electronics...
  • Page 25 Troubleshooting  LCD/KEY Page, 7-5 CON302 CON301 IC300 IC700  PCB Top Page, 6-2 <Fig. 4-4> IC701 4-10 Samsung Electronics...
  • Page 26 High)  Refer to wave pattern image of Fig. 4-5. Disassemble device. Is the battery properly Check Connector malfunction connected? Check for power in Replace Battery and check again the Battery? Finished Replace Board (Requires close inspection) Samsung Electronics 4-11...
  • Page 27 Troubleshooting IC200 IC201  POWER Page, 7-8 IC800 IC103 IC601  PCB Bottom Page, 6-4 <Fig. 4-5> CON400 4-12 Samsung Electronics...
  • Page 28 In the device DFU NAND FORMAT mobile storage device in manager, is there an unknown and BOOT update been "My Computer"? device? done? Install driver and recheck Is formatting Is there ACCESS? occurring in Windows Malfunction Explorer? Finished Samsung Electronics 4-13...

  • Page 29: Upgrade Methods

    5. Go to “Settings → System → System Information” and check the firmware version.  If a Bootloader update is needed, steps 1, 2 and 3 are completed and then step 4 occurs. If the Bootloader update is not needed, only step 4 occurs. 4-14 Samsung Electronics...
  • Page 30 2. After connecting the USB, the device must be installed. - After initially installing it once, it connects automatically from thereon. Specify the folder in which DFU is stored. [Bluesdfu_vid419_pid0145.inf Once the device is recognized, it will be connected to USB DFU DEVICE. Samsung Electronics 4-15...
  • Page 31 A “Format…” message will appear and the formatting occurs. 5 Push the Reset button and connect it to the PC again.  If the Browse button is inactive, there is no DFU connection and you must pull out the USB and try again. 4-16 Samsung Electronics...

  • Page 32: Exploded View & Part List

    Exploded View & Part List 5. Exploded View & Part List 5-1 Exploded View ..................5-2 5-2 Electrical Part List ................5-4 Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 33: Exploded View

    Exploded View & Part List 5-1 Exploded View AA001 AC010 AK200 AH312 AA225 AS040 This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 34 AH97-02482B ASSY-TOUCH PAD;TOuch PAD ASSY,YP-S3,Syna AC010 AH97-02624A ASSY CABINET-FRONT;ASSY,YP-S3,BLACK,- AH312 AH61-02541A HOLDER-LED;YP-S3,PC,T1,W20,L20,BLK,- AK200 AH64-04524A KNOB-HOLD;YP-S3,PC,T2,W2,L2,-,BLK,-,- AS040 6003-001166 SCREW-TAPTITE;CH,+,B,M1.4,L4,NI PLT,SWRC BATTERY AH43-00015A ERY;363844,YP-S3,Lithium-Polymer,5 AH07-00223A .CD-TFT;DA-176TC-02,YP-S3,176X220,34X4 PCB-MAIN AH92-02796F ASSY PCB-MAIN;YP-S3 MAIN,8GB(RDS) Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 35: Electrical Part List

    0601-002037 LED;SMD,BLUE,1.6x0.8x0.4mm,465/470 C306 2203-002709 C-CER,CHIP;100nF,+80-20%,16V,Y5V,10 D105 0601-002037 LED;SMD,BLUE,1.6x0.8x0.4mm,465/470 C307 2404-001381 C-TA,CHIP;10##F,20%,10V,-,TP,1608(0 D106 0601-002037 LED;SMD,BLUE,1.6x0.8x0.4mm,465/470 C313 2203-002709 C-CER,CHIP;100nF,+80-20%,16V,Y5V,10 C321 2404-001491 C-TA,CHIP;100##F,##20%,6.3V,-,REEL, D308 1405-001093 VARISTOR;14V,20A,1x0.5x0.6mm,TP D309 1405-001093 VARISTOR;14V,20A,1x0.5x0.6mm,TP C322 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,201 This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 36 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 R423 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 R101 2007-007001 R-CHIP;3.9Kohm,5%,1/16W,TP,1005 R501 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 R102 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 R502 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 R103 2007-000566 R-CHIP;220Kohm,5%,1/16W,TP,1005 R504 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 R104 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 R505 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 Samsung Electronics This Document can not be used without Samsung’s authorization.
  • Page 37 VAR404 1405-001093 VARISTOR;14V,20A,1x0.5x0.6mm,TP VAR407 1405-001093 VARISTOR;14V,20A,1x0.5x0.6mm,TP VAR408 1405-001093 VARISTOR;14V,20A,1x0.5x0.6mm,TP VAR500 2203-005493 C-CER,CHIP;220nF,+80-20%,16V,Y5V,10 VAR501 2203-005493 C-CER,CHIP;220nF,+80-20%,16V,Y5V,10 XTAL100 2801-000102 CRYSTAL-SMD;12MHz,30ppm,-,12pF,100o XTAL101 2801-004339 CRYSTAL-SMD;0.032768MHZ,20PPM,SMD,9 XTAL700 2801-004339 CRYSTAL-SMD;0.032768MHZ,20PPM,SMD,9 AH99-10017V ASSY AUTO INSERT-PCB-MAIN;-,YP-S3,- AH97-02772K ASSY-MACHINERY;YP-S3,XAC,-,- AH39-00899B CBF CABLE;ALDSX145,YP-S3,24,1200,3A This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 38 A/S Code AH82-00164A AH82-00164B AH82-00164C Existing A/S Code AH82-00164A AH82-00164B AH82-00164C Existing AH92-02796B A/S Code AH82-00164A AH82-00164B AH82-00164C Existing AH92-02796B A/S Code AH82-00164A AH82-00164B AH82-00164C <YP-S3 AS Code Table 1> Samsung Electronics This Document can not be used without Samsung’s authorization.
  • Page 39 Existing A/S Code Existing A/S Code Existing A/S Code Existing A/S Code Existing A/S Code Existing A/S Code Existing A/S Code Existing A/S Code <YP-S3 AS Code Table 2> This Document can not be used without Samsung’s authorization. Samsung Electronics...

  • Page 40: Pcb Diagram

    PCB Diagram 6. PCB Diagram 6-1 PCB Top ......................6-2 6-2 PCB Bottom ...................... 6-4 Samsung Electronics...

  • Page 41: Pcb Top

    - Recognized as Power On/Off when pressed for a regular period of time towards the lower direction and self resetting - Recognized as Hold when held in upper direction LCD Connector & Guide Hole - Assembled Top → Down and fixed to top of LCD Samsung Electronics...
  • Page 42 2 CON300 GROUND Touch PAD Connector LED3 LCD_D[10] Pin No. Signal GROUND LCD_D[0] GROUND LED2 LCD_D[9] GROUND GROUND LCD_D[1] GROUND LED1 LCD_D[8] T_RESET LCD_RESET LCD_D[2] T_DATA VOUT(LED PWR) GROUND T_CLK LCD_D[15] LCD_D[3] LCD_CE LCD_D[7] LCD_D[14] LCD_D[4] LCD_RS LCD_D[6] LCD_D[13] LCD_D[5] Samsung Electronics...

  • Page 43: Pcb Bottom

    - Data communication with external devices Earphone Jack - Audio Output CODEC IC CON400 - Audio Function power Finger GASKET - ESD internal reinforcement Reset Switch - Resets power for set SDRAM IC - Supports data transfer in system Samsung Electronics...
  • Page 44 VCC [IO 2.8V] L-CH ADAPTOR INPUT ADAPTOR INPUT CRADLE DETECT USB D- GROUND UART RX UART TX USB D+ USB POWER LINE OUT R LINE OUT L GROUND CRADLE_ANT (FM) BATTERY INPUT BATTERY INPUT EXTERNAL BATTERY DETECT PBA_CE Samsung Electronics...
  • Page 45 MEMO Samsung Electronics...

  • Page 46: Schematic Diagram

    7-1 Overall Block Diagram ..................7-2 7-2 S5L8700A02 ...................... 7-3 7-3 MEMORY ......................7-4 7-4 LCD/KEY ......................7-5 7-5 USB/MODE/DET ....................7-6 7-6 AUDIO (EAR JACK) ..................7-7 7-7 POWER ......................7-8 7-8 FM/RTC ......................7-9 7-9 CODEC ......................7-10 Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 47: Overall Block Diagram

    - 32bit ARM940T (200Mhz) VCC_2.8 Jack Line-In - 16bit CalmADM2E (120Mhz) - 256kb SRAM Line-Out CODEC Earphone (WM1800G) Reset VCC_2.8 Power On 32.768KHz FM Tuner USB 5V /12Mhz S-35392A (Si4702) This Document can not be used without Samsung’s authorization. Samsung Electronics...

  • Page 48: S5L8700A02

    Schematic Diagram 7-2 S5L8700A02 POWER Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 49: Memory

    Schematic Diagram 7-3 MEMORY POWER This Document can not be used without Samsung’s authorization. Samsung Electronics...

  • Page 50: Lcd/Key

    Schematic Diagram 7-4 LCD/KEY POWER Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 51: Usb/Mode/Det

    Schematic Diagram 7-5 USB/MODE/DET POWER AUDIO This Document can not be used without Samsung’s authorization. Samsung Electronics...

  • Page 52: Audio (Ear Jack)

    Schematic Diagram 7-6 AUDIO (EAR JACK) POWER AUDIO Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 53: Power

    Schematic Diagram 7-7 POWER POWER This Document can not be used without Samsung’s authorization. Samsung Electronics...

  • Page 54: Fm/Rtc

    Schematic Diagram 7-8 FM/RTC POWER Samsung Electronics This Document can not be used without Samsung’s authorization.

  • Page 55: Codec

    Schematic Diagram 7-9 CODEC POWER AUDIO 7-10 This Document can not be used without Samsung’s authorization. Samsung Electronics...
