Performance Specifications ........................................ 2
Notes ......................................................................... 2
Block Diagram ........................................................... 4
Interconnection Diagram ........................................... 5
Main Schematic and PCB .................................... 7 - 10
CD TRANSPORT
CONTENTS
SERVICE MANUAL
Display Schematic and PCB ............................... 11 - 13
L-Keyboard Schematic and PCB ............................... 14
R-Keyboard Schematic and PCB ............................... 15
Parts List ............................................................ 17 - 18
Exploded View and Parts Lists ........................... 19 - 20
Repacking Instructions ............................................. 21
Advertisement
Related Manuals for McIntosh MCD1000
Summary of Contents for McIntosh MCD1000
-
Page 1: Table Of Contents
CD TRANSPORT CONTENTS Performance Specifications ........2 Display Schematic and PCB ....... 11 - 13 Notes ................. 2 L-Keyboard Schematic and PCB ....... 14 Rear View and Section Location ......... 3 R-Keyboard Schematic and PCB ....... 15 Block Diagram ............4 Parts List ............ -
Page 2: Performance Specifications
Coaxial: 0.5V p-p @ 75ohms 240 Volts, 50/60Hz at 20 watts XRL: 5V p-p @ 110ohms (AES/EBU) Transport Note: Refer to the rear panel of the MCD1000 for the Pickup: Optical 3-beam laser correct voltage. Objective Lens Drive System: 2-Dimensional parallel... -
Page 3: Rear View
MCD1000 REAR VIEW SECTION LOCATION TOP VIEW WITH COVER REMOVED... -
Page 4: Block Diagram
BLOCK DIAGRAM... - Page 5 MCD1000 INTERCONNECT...
- Page 6 NOTES...
- Page 7 MCD1000 MAIN 050017...
- Page 8 MAIN 050017...
- Page 9 MCD1000 DISPLAY 050018...
- Page 10 DISPLAY L-KEYBOARD 050019 050018...
- Page 11 MCD1000 R-KEYBOARD 050020...
- Page 12 NOTES...
-
Page 13: Parts List
MCD1000 DIODE RECTIFIER 070131 COUPLER OPTICAL SCHMITT OUTPUT 131023 PROGRAMMED VERSION OF 133495 133520 PARTS LIST DIODE SILICON 070047 TRANSISTOR PNP SILICON 132172 REGULATOR 3.3V LOW DROP 133464 DIODE SILICON 070047 TRANSISTOR NPN 132223 IC REGULATOR 5V 133250 Ref. No. -
Page 14: Exploded View And Parts Lists
EXPLODED VIEW and PARTS LIST Part Description 016503 GLASS CENTER 102064 NUT CAP 6-32 016504 GLASS RIGHT 005374 SUBPANEL 016502 GLASS LEFT 101196 SCR TAP SEMS 6-32 X 1/4 PH PN 017517 PUSHBUTTON ASSY BLK 005392 TRAY SUPPORT LEFT 078033 O-RING 005375 TRAY SUPPORT RIGHT... -
Page 15: Repacking Instructions
MCD1000 REPACKING INSTRUCTION... - Page 16 SERVICE MANUAL The continuous improvement of its products is the policy of McIntosh Laboratory Incorporated, who reserve the right to improve design without notice. Because of the constant upgrading of McIntosh products’ circuitry and components, the Company cannot insure, and does not warrant, the accuracy of the within schematic material, which is intended for information only.
