FTXS60/71GV1B

1. FTXS60/71GV1B
Signal transmitter
Receiver
• To use the remote controller, aim the
transmitter at the indoor unit. If there
is anything to block signals between
the unit and the remote controller,
such as a curtain, the unit will not
operate.
• The maximum distance for
communication is approx. 7m.
FAN setting button
• Selects the airflow rate setting
every time you press this button.
Auto Indoor unit quiet
High Middle high
• In indoor unit quiet operation,
operation sound becomes weak.
(The airflow rate also decreases.)
• In DRY operation, the airflow rate
setting is not available.
The remote controller is compatible with both cooling only and heat pump models
Reference Refer to the following pages for detail.
Note: Refer to the operation manual of applicable model for detail. You can download operation
manual from 'DISTRIBUTOR'S PAGE':
DISTRIBUTOR'S PAGE → Product Information → Operation/Installation Manual
(URL: http://global.daikin.com/Daikin/global/Distributors_admin/user_mng/login.php)
54
Low
Middle low
Middle
1 POWERFUL operation
2 Model Type Setting
< ARC452A3 >
P.27
P.116
SiBE041011_A
Display (LCD)
• Displays the current settings.
(In this illustration, each section is
shown with all its displays on for the
purpose of explanation.)
TEMPERATURE
adjustment buttons
• Changes the temperature setting.
18 ~ 30 °C
: AUTO
Not available
: DRY
18 ~ 32 °C
: COOL
10 ~ 30 °C
: HEAT
Not available
: FAN
ON/OFF button
• Press this button once to
start operation.
Press once again to stop it.
1
POWERFUL button
• POWERFUL operation.
Remote Controller
(R18202)
2
.
