GFDS170EH

7.5 cu. ft. capacity frontload electric dryer with Steam and stainless steel drum

Dimensions and Installation Information (in inches)

Electric Dryer Rating

240V

5600W, 24A, 60Hz

208V

4400W, 22A, 60Hz

Exhaust Options: 4-way via rear, right, left and bottom.

Circuit Requirements: An individual, properly grounded

branch circuit, protected by a 30-amp circuit breaker or

a time-delay fuse, is required.

Note: Dryer wall outlet must be located within 36"

of service cord entry and accessible when dryer is

mounted in position.

Installation Information: For complete information, see

installation instructions packed with your dryer.

For answers to your Monogram,

GE Profile

appliance questions, visit our website at

geappliances.com or call GE Answer Center

service, 800.626.2000.

™

39-3/8

4-3/8

5-3/8

Listed by

Underwriters

Laboratories

Specification Created 4/14

Need help?

Do you have a question about the GFDS170EH and is the answer not in the manual?

Page 1 4-3/8 5-3/8 For answers to your Monogram, GE Profile ® ™ ® appliance questions, visit our website at geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 4/14...
Page 2 For more information on venting kits and accessories, please call 1-800-GE-CARES. For answers to your Monogram, GE Profile ® ™ appliance questions, visit our website at ® 28-3/4 geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 4/14...
Page 3 Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap must also be located at least 12" above the ground or any other obstruction with the opening pointed down. For more information on venting kits and accessories, please call 1-800-GE-CARES. 3-1/2 2-1/2...
Page 4 GFDS170EH 7.5 cu. ft. capacity frontload electric dryer with Steam and stainless steel drum ® Features and Benefits • Steam Refresh - Rejuvenate lightly worn clothes by getting rid of wrinkles and odors with this convenient setting using the power of steam •...
