Summary of Contents for Finlux 32f502
-
Page 2: Table Of Contents
Contents Environmental Information ........2 Accessories included ..........3 TV - Features ............3 Safety Precautions and Important Information ..3 Viewing the TV ............4 TV Control Buttons & Operation ......4 Operation with the Buttons on the TV ..... 4 Operation with the Remote Control ...... -
Page 3: Environmental Information
Power cord and plug Screen • The power cord plug should be easily accessible. If • Occasionally, a few non-active pixels may appear there is lightning or storms, or if the TV is not going on the screen as a fixed blue, green or red point. to be used for a while (e.g. -
Page 4: Accessories Included
Accessories included Safety Precautions and Important Information Remote Control Batteries: 2 x AAA Please read these instructions fully before installing or operating. Instruction Book Preparation TV - Features Place the device on a solid even surface. For ventilation purposes, leave a free space of at least •... -
Page 5: Viewing The Tv
Operation with the Buttons on the Viewing the TV Press button to decrease the volume or button to increase the volume, so a volume level scale (slider) will be displayed on the screen. Press P/CH + button to select the next programme or P/CH - button to select the previous programme. -
Page 6: Remote Control
Remote Control 1. Standby / On 2. Channel list 3. Volume up-down 4. Menu on/off 5. OK / Channel list / Confirm 6. Return / Back 7. No function 8. My button 1 (*) 9. My button 2 (**) 10. Coloured buttons (Red, Green, Yellow, Blue) 11. - Page 7 Connections NOTE: When connecting a device via the YPbPr or Side AV inputs, you must use the connection cables to enable connection(not supplied). See the illustrations above. | To enable PC audio, you will need to use an Audio cable(not supplied). | If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.| When receiving DTV channels (Mpeg4 H.264) or while in Media Browser mode, output will not be available via the scart socket.
-
Page 8: Inserting The Batteries Into The Remote Control
Inserting the Batteries into the Remote Control 1. Lift the cover on the back of the remote upward gently. 2. Install two AAA batteries. Make sure to match the + and - ends of the batteries in the battery compartment (observe the correct polarity). 3. -
Page 9: Media Playback Via Usb Input
Media Playback via USB Input You can connect a USB hard disk drive or USB memory stick to your TV by using the USB inputs of the TV. This feature allows you to play files stored in a USB drive. 2.5” and 3.5” inch (hdd with external power supply) external hard disk drives are supported. -
Page 10: Quick Menu
options. Pressing the MENU button again will exit from Using the Channel List this screen. You can set your Media Browser preferences by using the Settings menu. The TV sorts all stored stations in the Channel List. You can edit this channel list, set favourites or set active stations to be listed by using the Channel List options. -
Page 11: Menu Features And Functions
Menu Features and Functions Picture Menu Contents You can change the picture mode to suit your preference or requirements. The Picture mode Mode can be set to one of these options: Cinema, Game, Sport, Dynamic and Natural. Contrast Sets the lightness and darkness values of the screen. Brightness Sets the brightness value for the screen. - Page 12 Menu Features and Functions Sound Menu Contents Volume Adjusts the volume level. In the equalizer menu, the preset can be changed to Music, Movie, Speech, Flat, Classic and User. Press the MENU button to return to the previous menu. Equalizer Equalizer menu settings can be changed manually only when the Equalizer Mode is in User.
- Page 13 Menu Features and Functions Settings Menu Contents Conditional Access Controls conditional access modules when available. Language Configures language settings. Configures parental settings. Default PIN code can change depending on the selected country. If you are asked Parental to enter a PIN code for viewing a menu option, use one of the following codes: 4725, 0000 or 1234.
-
Page 14: Electronic Programme Guide (Epg)
Set Timer / Delete Timer Electronic Programme Guide (EPG) After you have selected a programme in the EPG Some, but not all channels send information about the menu, press the OK button and the Options screen current and next programmes. Press the “ - EPG”... -
Page 15: Timeshift Recording
Record, Play, Pause, Display (for PlayListDialog) keys Press the (STOP) button to stop a playback and can not be used when teletext is ON. If a recording return to the Recordings Library. starts from the timer when teletext is ON, teletext Slow Forward is automatically turned off. -
Page 16: Digital Teletext
• Do not spray cleaner directly onto the surface of the Troubleshooting & Tips product.This may result in discoloration and cracks Image persistence - ghosting and may cause the screen display to peel off. • Do not let water come into contact with the product Please note that ghosting may occur while displaying when cleaning it. -
Page 17: Appendix A: Pc Input Typical Display Modes
Appendix A: PC Input Typical Display Appendix B: AV and HDMI Signal Modes Compatibility (Input Signal Types) The following table is an illustration of some of the typical video display modes. Your TV supports up to Supported 1920x1200. Source Available Signals Index Resolution... -
Page 18: Appendix C: Supported File Formats For Usb Media Browser
Appendix C: Supported File Formats for USB Media Browser Media Extension Format Notes Video Audio Movie dat, mpg, Mpeg1,2 MPEG1/2 Layer 1/2/3, AAC/ 1080P@ 30fps 50Mbit/ mpeg HEAAC, AC3/EAC3, LPCM/ADPCM dat, mpg, MPEG2 ,H.264, VC1, MPEG1/2 Layer 1/2/3, AAC/ H.264:1080Px2@25fps mpeg AVS, MVC HEAAC, AC3/EAC3, LPCM/ADPCM... -
Page 19: Appendix D: Supported Dvi Resolutions
Appendix D: Supported DVI Resolutions When connecting devices to your TV’s connectors using DVI converter cable (not supplied), you can refer to the following resolution information. 24Hz 25Hz 30Hz 50Hz 60Hz 480i þ 480p þ 576i þ 576p þ 720p þ... - Page 20 YEAR GUARANTEE WARRANTY CARD Thank you for your purchase. We are sure you w ll enjoy us ng F nlux for many years. The product warranty s for a per od of twelve Repa rs (12) months from the date of or g nal Our author sed serv ce partners w ll always purchase.
- Page 21 Warranty Exclus ons Th s Warranty does not cover any F nlux branded consumer product nstalled n a Th s Warranty does not extend to loss moveable dwell ng. Note that the performance of the product may be a ected (l qu d ngress on), theft, verm n or nsect f t s nstalled n a caravan or other such nfestat on.
