Istruzioni per luso LAVASTOVIGLIE Sommario Installazione, 2-3 English,13 Posizionamento e livellamento Collegamenti idraulici ed elettrici Avvertenze per il primo lavaggio Dati tecnici Descrizione dellapparecchio, 4 Vista dinsieme Pannello comandi Caricare i cestelli, 5 Cestello inferiore Cestello delle posate Cestello superiore LKF 72 Avvio e utilizzo, 6-7 LKF 71...
Installazione Posizionamento e livellamento vedi foglio di Montaggio vedi Assistenza vedi a lato (vedere foglio istruzioni incasso allegato alla documentazione) Collegamenti idraulici ed elettrici New Acqua Stop vedi figura...
Avvertenze per il primo lavaggio vedi capitolo Brillantante e sale rigenerante vedi capitolo Brillantante e sale rigenerante vedi figura Larghezza cm. 60 Dimensioni Altezza cm. 85 Profondità cm. 60 Capacità 12 coperti standard Pressione acqua 0,05 ÷ 1MPa (0.5 ÷ 10 bar) vedi capitolo Descrizione della lavastoviglie alimentazione 4,3 psi –...
Caricare i cestelli Dopo aver caricato, controllare che gli irroratori ruotino liberamente. E preferibile regolare laltezza del cesto superiore a Cesto inferiore CESTO VUOTO. Non sollevare o abbassare MAI il cesto su un solo lato. Esempi di caricamento. vedi figura Dual Space vedi figura...
Avvio e utilizzo Caricare il detersivo Avviare la lavastoviglie vedi sotto vedi Caricare i cestelli vedi a lato Tabella dei programmi Opzioni di lavaggio* (vedi tabella programmi)
Page 7
Lopzione Pastiglie Multifunzione, comporta lallungamento del programma. vedi tabella delle opzioni Avvio Mezzo Pastiglie Ritardato Carico Multifunz. Intensivo Normale Daily A 60 Ammollo Speed Cristalli...
Programmi Detersivo Durata del Programmi (A) = vaschetta A programma Indicazioni per la scelta Programma Opzioni (B) = vaschetta B (tolleranza dei programmi prevedono ±10%) l’asciugatura polvere liquido pastiglie Hrs. Min. Stoviglie e pentole molto sporche (da non usare 30 g (A) 30 ml (A) 1 (A) A-B-C...
Brillantante e sale rigenerante si consiglia invece di aggiungere sale, specie se lacqua è dura o molto dura. Tabella Durezze Acqua °dH °fH mmol/l livello Caricare il brillantante 20 1,1 30 2,1 60 3,1 90 6,1 Da 0°f a 10°f si consiglia di non utilizzare sale. con questa impostazione la durata dei cicli può...
Precauzioni, consigli e Assistenza vedi Avvio e utilizzo Sicurezza generale Assistenza vedi Anomalie e Rimedi Smaltimento vedi Descrizione dellapparecchio Assistenza Attiva 7 giorni su 7 Risparmiare e rispettare lambiente vedi Programmi * Al costo di 14,25 centesimi di Euro al minuto (iva inclusa) dal Tabella dei programmi Lun.
Anomalie e rimedi Anom alie : Possibili cause / Soluzio ne: La lavastoviglie no n parte. • L a s p in a n on è b e n ins e r i ta ne l la p r es a di c o r r e n te o pp u r e in c as a n o n c ’...
Operating instructions DISHWASHER Contents Installation, 14-15 Positioning and levelling Connecting the water and electricity supplies Advice regarding the first wash cycle Technical data Description of the appliance, 16 Overall view Control panel Loading the racks, 17 Lower rack Cutlery basket LKF 72 Upper rack LKF 71...
Installation Positioning and levelling see Assistance see adjacent information see the Assembly instruction sheet New Acqua Stop Connecting the water and electricity supplies see figure...
Advice regarding the first wash cycle chapter entitled Rinse aid and refined salt see chapter entitled Rinse aid and refined salt see figure width 60 cm Dimensions height 85 cm see chapter entitled Description of depth 60 cm the appliance Capacity 12 standard place-settings Water supply...
Description of the appliance Overall view Upper rack Upper sprayer arm Tip-up compartments Rack height adjuster Lower rack Lower sprayer arm Cutlery basket Washing filter Salt dispenser Detergent and rinse aid dispensers Data plate Control Panel Control panel Washing and 3h. Delayed start Half load ON/OFF...
Loading the racks After loading the appliance, check that the sprayer arms can rotate freely. The height of the upper rack should ideally be adjusted Lower rack WHEN THE RACK IS EMPTY. Never lift or lower the rack on one side only. Loading examples.
Start-up and use Starting the dishwasher Measuring out the detergent A good wash result also depends on the correct 1. Turn the water tap on. amount of detergent being used; exceeding the stated 2. Press the ON/OFF button: all the indicator lights on amount does not result in a more effective wash and the control panel will light up for a few seconds.
Page 19
If there are not many dishes to be washed, a half load This option optimises washing and drying results. cycle may be used in order to save water, electricity When using multi-functional tablets, press the MULTI- and detergent. Select the wash cycle and press the FUNCTIONAL TABLETS button.
Wash cycles Detergent Wash Wash cycle (A) = compartment A cycles duration :DVK F\FOH :DVK F\FOH Wash cycle selection Options (B) = compartment B which (tolerance instructions include ±10%) Powder Liquid Tablets drying Hrs. Min. Heavily soiled dishes and pans (not to be used for 30 g (A) 30 ml (A) 1 (A)
Rinse aid and refined salt Only use products which have been specifically designed for dishwashers. Do not use table salt or industrial salt, or washing up liquid. we recommend that you add salt, especially if you live in an area where the water is hard or very hard.
Care and maintenance dishwasher. Clean the water inlet filter at the tap outlet regularly. - Turn off the water tap. - Unscrew the end of the water inlet hose, remove the filter and clean it carefully under running water. - Replace the filter and screw the water hose back into position.
Precautions, advice and Assistance Table of wash cycles General safety see Start-up and use see Start-up and use Disposal Assistance Check whether the problem can be resolved using the Troubleshooting guide (see Troubleshooting). Restart the programme to check whether the problem has ceased to exist.
Troubleshooting 195064349.02 12/2007 - Xerox Business Services Whenever the appliance fails to work, check for a solution from the following list before calling for Assistance. Proble m : Poss ible ca us es / Solut ions : T he d is hw as he r d oes n o t star t. •...
