SERVICE MANUAL

LCD COLOUR TELEVISION
LC-37XD10E/RU
MODELS
CONTENTS
[1]
[2]
[3]
[4]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
CHAPTER 8. SCHEMATIC DIAGRAM
[1]
[2]
No. S37C7LC37XD10
OVERALL WIRING DIAGRAM ......................6-1
BLOCK DIAGRAM.........................................6-3
MAIN BLOCK DIAGRAM...............................6-5
POWER BLOCK DIAGRAM ..........................6-7
BOARD..........................................................7-2
BOARD........................................................7-19
DIAGRAM......................................................8-1
SCHEMATIC DIAGRAM ................................8-2
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
LC-37XD10E/RU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-37XD10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharp LC-37XD10

Summary of Contents for Sharp LC-37XD10

  • Page 1: Table Of Contents

    TopPage LC-37XD10E/RU SERVICE MANUAL No. S37C7LC37XD10 LCD COLOUR TELEVISION LC-37XD10E/RU MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used. CONTENTS SAFETY PRECAUTION CHAPTER 6.

  • Page 2: Safety Precaution

    LC-37XD10E/RU LC37XD10E SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 3: Precautions For Using Lead-Free Solder

    LC-37XD10E/RU Precautions for using lead-free solder Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder. Example: F a/a Indicates lead-free solder of tin, silver and copper.

  • Page 4: Chapter 1. Operation Manual Specifications

    LC-37XD10E/RU CHAPTER 1. LC37XD10E OPERATION MANUAL Service Manual [1] SPECIFICATIONS 1 – 1...

  • Page 5: Operation Manual

    LC-37XD10E/RU [2] OPERATION MANUAL 1 – 2...
  • Page 6 LC-37XD10E/RU 1 – 3...
  • Page 7 LC-37XD10E/RU 1 – 4...

  • Page 8: Dimensions

    LC-37XD10E/RU [3] DIMENSIONS 1 – 5...

  • Page 9: Removing Of Major Parts

    LC-37XD10E/RU CHAPTER 2. LC37XD10E REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Remove the 4 lock screws , and the 10 lock screws . Detach the Rear Cabinet. Rear Cabinet 2. Remove the 2 lock screws and detach the Bottom Cover.
  • Page 10 LC-37XD10E/RU 4. Remove the 2 lock screws . 2 lock screws and the 2 lock scrwes . Detach the Center Angle. 5. Remove the 4 lock screws . Detach the Stand Angle. CENTER ANG STAND ANG 6. Remove the 4 lock screws .
  • Page 11 LC-37XD10E/RU 7. Remove the 4 lock screws . Detach the Speaker Angle. Speaker Angle Speaker Angle 2 – 3...
  • Page 12 LC-37XD10E/RU 8. Remove the 6 lock screws . Detach the Full Shield. Wire "KM" (to P151) KS TOP-COVER FULL SHIELD Not screw < CAUTIONS > # Do Not sandwich wire "RA","SP",MS 2 – 4...
  • Page 13 LC-37XD10E/RU 9. Remove the 2 lock screws . Detach the Mini Unit. Wire "RA" (to RA) Wire "RA", "MS" to WH Wire "RA", "MS", "SP" to WH Wire "SP" curve like this Wire "MS" (to RA) Wire "MS" to WH SP R Wire "SP"...
  • Page 14 LC-37XD10E/RU 11.Remove the 5 lock screws . Detach the Chassis Tray Unit. Chassis Tray Unit 2 – 6...
  • Page 15 LC-37XD10E/RU 12.Remove the 14 lock screws , and 4 lock screws . Detach the LCD Angle. Base of LCD Panel positioning LCD ANG TOP-C LCD ANG A LCD ANG B 37 LCD PANEL KS-FRONT CAB Base of LCD Panel positioning 2 –...
  • Page 16 LC-37XD10E/RU 13.Remove the 2 lock screws . Detach the D-Tuner Unit. 14.Remove the 1 lock screw . Detach the Terminal Cover. D-Tuner Unit Wire "LV" (to LV) GASKET Terminal Cover 15.Remove the 2 lock screws . Detach the R/C, LCD Unit. R/C, LED Unit Pull wire out to bottom side LED PWB must be insert...
  • Page 17 LC-37XD10E/RU 16.Remove the 4 lock screws . Detach the Tweeters. 17.Remove the 2 lock screws . Detach the Front Cabinet. TWEETER TWEETER 2 – 9...

  • Page 18: Chapter 3. Adjustment Procedure Adjustment Procedure

    IC1902 RH-iXB937WJZZS EDID(HDMI) IC2303 RH-iXB938WJZZS EDID(PC) 2. Software Upgrade 3. Double click on starter.exe and running. Main software update procedure of SHARP LCDTV 1. Connect your PC and LCDTV by 232C-CROSS-CABLE. Set up starter298 2. Decompress starter_298_ver100.zip. 3 – 1...
  • Page 19 LC-37XD10E/RU 4. Set the parameters of the starter software as below. 3) "Download": set configuration as below. [Options]-[Preferences] Setup window will be opened. (a) set directory path of starter tool 1) "General","Terminal","System update": no need to modify (b) set absolute path of target elf file anything.
  • Page 20 LC-37XD10E/RU Download 6. Connect to the LCD TV and start up "starter298" software. Input "fpga 3 0x80" command and return key on your PC, and the 7. After turn on the power of set, please push the below connect but- in small letters ton.
  • Page 21 LC-37XD10E/RU 10.Change the port settings. 11. Connect to the LCD TV by activating the connection button. 12.[Programming]-[Download] Download window will be opened. setting "115200" 3 – 4...
  • Page 22 LC-37XD10E/RU 13.Select the file which you want to upload. 14.Click "Flash" button and get executed. click once click once 3 – 5...
  • Page 23 LC-37XD10E/RU 15.If the Flash has burned successfully, "OK" message is shown as 16.Turn the AC power off , and turn AC power on. below. Return to default automatically. 17.Finish!! 18.Prepare for next model If you have once write the software to the set, the PC side commu- nication speed will be set up to "115200".
  • Page 24 LC-37XD10E/RU 4. Remote controller key operation and description of display in adjustment process mode. key operation Main unit key Remote controller key Function Changing a selected line setting ( 10/ 10) Turning a page PREVIOUS/NEXT Cursor Moving an item line by one UP/DOWN Cursor Turning a page PREVIOUS/NEXT Changing a selected item setting ( 1/ 1)

  • Page 25: M Gamma

    LC-37XD10E/RU 5. Adjustment process mode menu The character string in brackets [ ] will appear as a page title in the adjustment process menu header. Remarks (adjustment detail,etc.) Page Line Item Description 1/13 [INFO] Main Version Main microprocessor version 37/42XD10 ver 2.31 2007.03.15 Dev Version ver 1.151 DTV version.
  • Page 26 LC-37XD10E/RU 8/13 [M GAMMA 1-3] M GAMMA R 1 W/B adjustment, gradation 1R adjustment value M GAMMA G 1 W/B adjustment, gradation 1G adjustment value M GAMMA B 1 W/B adjustment, gradation 1B adjustment value M GAMMA R 2 W/B adjustment, gradation 2R adjustment value M GAMMA G 2 W/B adjustment, gradation 2G adjustment value M GAMMA B 2...
  • Page 27 LC-37XD10E/RU 6. Special features * ERROR STANDBY CAUSE (Page 1/13) The total time when the unit enters the standby due to operational error and cause of error are recorded on EEPROM as much as possible. The values can be used to locate the fault for repair. * EEP CLEAR (Page10/13) Clear of process adjustment EEP value.
  • Page 28 LC-37XD10E/RU 4. Tuner adjustment Adjustment point Adjustment conditions Adjustment procedure 1 Setting [Signal] Feed the PAL sprit colour bar (E-12ch) to TUNER. Make sure the PAL colour bar pattern (E-12) has the sync level of PAL sprit colour bar 7:3 with the picture level. RF signal E-12CH [Terminal]...

  • Page 29: M Gamma

    LC-37XD10E/RU 8. White Balance Adjustment Adjustment gradation values (IN) appear on page 7/13 of process adjustment, and adjustment initial values(offset value) appear on pages 8/13 and 9/ For white balance adjustment, adjust the offset values on pages 8/13 and 9/13. [Condition of the unit for inspection] Modulated light: MAX (+8) [Adjustment reference device]...
  • Page 30 LC-37XD10E/RU 9. Initialization to factory settings Caution: When the factory settings have been made, all user setting data, including the channel settings, are initialized. (The adjustments done in the adjustment process mode are not initialized.) Keep this in mind when initializing these settings. Adjustment item Adjustment conditions Adjustment procedure...
  • Page 31 LC-37XD10E/RU 10. Lamp error detection 1. Function This LCD color TV set incorporates a lamp error detection feature that automatically turns off the power for safety under abnormal lamp or lamp circuit conditions. If by any chance anything is wrong with the lamp or lamp circuit or if the lamp error detection feature is activated for some rea- son, the following will result.
  • Page 32 LC-37XD10E/RU 11. Public Mode 1. How to enter Public mode Enter the adjustment process mode, referring to "3.Entering and exiting the adjustment process mode". In the[INIT],page2/13 of service, turns on the PUBLIC MODE option. Turn off TV by pressing "Power button" of TV unit. Press "Power button"...
  • Page 33 LC-37XD10E/RU 3. Parameter setting (1) POWER ON FIXED Options "yes", "no" Default "no" (2) MAXIMUM VOLUME Options 0 --- 63 Default (3) VOLUME FIXED Options "yes", "no" Default "no" (4) VOLUME FIXED LEVEL Options 0 --- Maximum volume Default (5) INPUT MODE START Options "normal", "TV","DTV", "EXT1", "EXT2", "EXT3", "EXT4", "EXT5", "EXT6"...

  • Page 34: Chapter 4. Troubleshooting Table

    LC-37XD10E/RU CHAPTER 4. LC37XD10E TROUBLESHOOTING TABLE Service Manual [1] TROBLESHOOTING TABLE Power unit operation check. Are the power cord and har- Connect the power cord ness in the unit properly con- and harness properly, nected ? and turn on the power. Is F701 normal ? Are both ends of C704 Replace F701.
  • Page 35 LC-37XD10E/RU No sound (1) (during the reception of TV broadcasting) No audio output during UHF/VHF reception Checklist: 1) Is the volume set to MIN or MUTE on the remote control ? ... Set the desired volume. 2) Are headphones connected to HEADPHONE (J1301 ) ? ... Disconnect them. 3) Is ANT-CABLE disconnected or connected improperly ? ...
  • Page 36 LC-37XD10E/RU No sound from external input devices (2) -1 No sound from an external input No sound from an external No sound from an external input device connected to EXT1 input device connected to device connected to EXT3. (SCART1). EXT2 (SCART2). <EXT1>...
  • Page 37 LC-37XD10E/RU No sound from external input devices (2) -2 No sound from EXT4 (AUDIO) No sound from EXT5 connecting an external input (AUDIO) connecting an exter- device. nal input device. <EXT4> <EXT5> Is D-SUB-L audio signal sent Is HDMI-L audio signal sent from J2702 to pin (15) of from J2701 to pin (14) of IC2704?
  • Page 38 LC-37XD10E/RU No sound except from speakers (3) -1 No audio output from the No audio output from headphones. EXT1 (SCART) terminal. Is there audio output on pins Checklist: (2) and (3) of the headphone 1) Is the MUTE button on the remote control set to ON? ... Set to OFF. terminal (J1301)? 2) Check the connection to external devices..Is there any improper connection? 3) Is S-MUTE-LINE [IC1710 (pin92)] at H?
  • Page 39 LC-37XD10E/RU No sound except from speakers (3) -2 No audio output from No audio output from EXT2 (SCART) termi- AUDIO OUTPUT termi- nal. nal. Checklist: 1) Is the MUTE button on the remote control set to ON? ... Set to OFF. 2) Check the connection to external devices..Is there any improper connection? 3) Is S-MUTE-LINE [IC1710 (pin92)] at H? Is audio signal sent to...
  • Page 40 LC-37XD10E/RU DTV troubleshooting 1 The unit does not enter Go to "The unit does not The unit does not enter the DTV mode. Or, the DTV menu does not the DTV mode. Or, the enter the DTV mode. Or, appear. DTV menu does not the DTV menu does not appear.
  • Page 41 LC-37XD10E/RU DTV troubleshooting 2 No video output during No audio output during DTV reception. Colors DTV reception. Sound of Images are not right. is low. D-TUNER UNIT: Check R272 and R273. DIGITAL UNIT: Check R4002(AD2pin) Is data FED[0:7] sent Is audio signal fed to and IC4001(D-Proces- from pins pins (5) and (10) of...
  • Page 42 LC-37XD10E/RU <0n input of the tuner (U/V)> No picture on the display (1) No picture appears on LCD during the tuner (U/V) reception. Checklist: 1) Is "INPUT SOURCE" button on the remote control set up correctly ? ... See the operation manual and set "INPUT SOURCE" to "TV". 2) Is MENU-Picture-Contrast/Brightness set to "MIN"...

  • Page 43: Specifications

    LC-37XD10E/RU <Durlng external connectlon> No picture on the monitor (2) -1 SCART1: SCART2: No picture appears on EXT1 -connected monitor during the tuner (U/V) No picture from EXT1 appears on EXT2-connected montor. reception. Note: Normally, if the screen during display is sent to EXT2, no pic- ture is sent to EXT2.
  • Page 44 LC-37XD10E/RU <Durlng external connectlon> No picture on the monitor (2) -2 SCART2: No picture from EXT3 appears on EXT2- connected monitor. Checklist: 1) Are input terminal on back of TV and "INPUT SOURCE"button on the remote control set up correctly ? ... See the operation manual and set "INPUT SOURCE "appropriately.
  • Page 45 LC-37XD10E/RU <When EXT1 is used for external input> No picture on the display (3)-1 No EXT1 -Composite output of the external input system. No EXT1-RGB output of the external input system. Checklist: 1) Is "INPUT SOURCE" button on the remote control set up correctly? ...See the operation manual and set "INPUT SOURCE" to "EXIT". 2) Is MENU-Picture-Backlight/Contrast/Brightness set to "MIN"? ...Set it to an appropriate level.
  • Page 46 LC-37XD10E/RU <When EXT1 is used for external input> No picture on the display (3)-2 No EXT1-Y/C output of the external input system. Checklist: 1) Is "INPUT SOURCE" button on the remote control set up correctly? ...See the operation manual and set "INPUT SOURCE" to "EXIT". 2) Is MENU-Picture-Backlight/Contrast/Brightness set to "MIN"? ...Set it to an appropriate level.
  • Page 47 LC-37XD10E/RU <When EXT2 is used for external input> No picture on the display (4) No EXT2-Composite output of the external input system. No EXT2-Y/C output of the external input system. Checklist: 1) Is "INPUT SOURCE" button on the remote control set up correctly ? ... See the operation manual and set "INPUT SOURCE" to "EXT2". 2) Is MENU-Picture-Backlight/Contrast/Brightness set to "MIN"? ...Set it to an appropriate level.
  • Page 48 LC-37XD10E/RU <When EXT3 is used for external input> No picture on the display (5) No EXT3 output of the external input system. No EXT3-Y/C output of the external input system. Checklist; 1) Is"INPUT SOURCE" button on the remote control set up correctly? ... See the operation manual and set "INPUT SOURCE" to "EXT3". 2) Is MENU-Picture-Backlight/Contrast/Brightness set to "MIN"...
  • Page 49 LC-37XD10E/RU <When EXT4 is used for external input> No picture on the display (6) No EXT4 (15pin-D-SUB terminal) output of the external input sys- tem. Checklist: 1) Is "INPUT SOURCE" button on the remote control set up correctly ? ... See the operation manual and set "INPUT SOURCE" to "EXT4". 2) Connect the included D-SUB-Adapter-Cable to the COMPONENT terminal of an external device.
  • Page 50 LC-37XD10E/RU <When EXT5 is used for external input> No picture on the display (7) No EXT5 (HDMI) output of the external input system. Checklist: 1) Is "INPUT SOURCE" button on tne remote control set up correctly? ... See the operation manual and set "INPUT SOURCE" to "EXT5". 2) Have you checked the type video signal sent from HDMI-connected external device? ...Confirm the type (it should "RGB", "YCbCr 4:4:4"...
  • Page 51 LC-37XD10E/RU Is LVDS video signal (TA1± - TD1±) sent to pins (3)/(2) -(12)/(11) of CONNECTOR CN1 of LCD-CONT- Check CONNECTOR UNIT, and is CLK signal (CK1±) sent to pins (10)/(9)? (SC2302, CN1) and HAR- Is LVDS video signal (TA2± - TD2±) sent to pins (17)/(16) -(26)/(25) of CONNECTOR CN1 of LCD- NESS WIRE (LV).
  • Page 52 LC-37XD10E/RU <When EXT6 is used for external input> No picture on the display (8) No EXT6 (HDMI) output of the external input system. Checklist: 1) Is "INPUT SOURCE" button on tne remote control set up correctly? ... See the operation manual and set "INPUT SOURCE" to "EXT6". 2) Have you checked the type video signal sent from HDMI-connected external device? ...Confirm the type (it should "RGB", "YCbCr 4:4:4"...
  • Page 53 LC-37XD10E/RU Is LVDS video signal (TA1± - TD1±) sent to pins (3)/(2) -(12)/(11) of CONNECTOR CN1 of LCD- Check CONNECTOR CONT-UNIT, and is CLK signal (CK1±) sent to pins (10)/(9)? (SC2302, CN1) and HAR- Is LVDS video signal (TA2± - TD2±) sent to pins (17)/(16) -(26)/(25) of CONNECTOR CN1 of LCD- NESS WIRE (LV).
  • Page 54 LC-37XD10E/RU FRC circuit failure Note: The SD signal (576i 480i) alone passes through the FRC circuit. (The HD signal does not go through.) Does the image appear with the HD Does anything unusual (which or Does the image look unusual with signal, but not with the SD signal ? blackish screen, block noise, for the power switch turned on?
  • Page 55 LC-37XD10E/RU Backlight failure to light up Do all the fluorescent tubes light up? Check the individual fluorescent Replace any defective fluorescent tubes for light-up failure. tube (s) with new one (s). Is the power supplied to CN7501 on Check the connection between power the inverter unit? unit and inverter unit.
  • Page 56 LC-37XD10E/RU LCD failure 1 Does a single or several verti- Does a single or several hori- Do luminescent or black dots Is the on-screen image rip- cal stripes appear on the LCD zontal stripes appear on the appear on the screen? pling or distorted? screen? LCD screen?

  • Page 57: Chapter 5. Major Ic Informations

    LC-37XD10E/RU CHAPTER 5. LC37XD10E MAJOR IC INFORMATIONS Service Manual [1] MAJOR IC INFORMATIONS 1. DESCRIPTION OF MAJOR ICs Dwg. REF NO Name Part Code Discruotion Code IC1905 HDMI- VHISII9025+-1Q The SiI9025 is a second generation panelLink Cinema receiver that is compatible with Receiver the HDMI 1.1 (High Definition Multimedia interface)specification.
  • Page 58 LC-37XD10E/RU IC1706 BU+1.8V VHIMP1583++-1Y DC to DC Converter. 3A Step down switch mode regulator with a built in internal Power Mosfet. Fault condition protection includes cycle-by-cycle current limiting and thermal shut- down. IC1707 +3.3V VHIPQ20WZ11-1Y Low power-loss voltage regulators. Variable Output. Output current 1A. Built-in overcurrent, overheat protection functions,ASO protection circuit.
  • Page 59 LC-37XD10E/RU [DIGITAL TUNER SECTION] IC202 COFDM RH-IXB682WJZZQ This is a COFDM (Coded Orthogonal Frequency Division Multiplex) Demodulator IC. In Demod IC this equipment, IF signal from the digital tuner is decoded to MPEG-2 signal, and it is digitally output. Output signal is fed to the digital processor to implement video/audio decode processing.
  • Page 60 LC-37XD10E/RU 2. IC1905: VHISii9025+-1Q HDMI RECIEVER Pin No. Pin Name Pin Function 24-bit Output Pixel Data Bus. HDMI-B[0] 24-bit Output Pixel Data Bus. HDMI-B[1] 24-bit Output Pixel Data Bus. HDMI-B[2] 24-bit Output Pixel Data Bus. HDMI-B[3] 24-bit Output Pixel Data Bus. HDMI-B[4] 24-bit Output Pixel Data Bus.
  • Page 61 LC-37XD10E/RU R0X0+ TMDS input data pair. HDMI Port 0. R0X0- TMDS input data pair. HDMI Port 0. R0X1+ TMDS input data pair. HDMI Port 0. R0X1- TMDS input data pair. HDMI Port 0. R0X2+ TMDS input data pair. HDMI Port 0. R0X2- TMDS input data pair.
  • Page 62 LC-37XD10E/RU 2.1. Block Diagram 5 – 6...
  • Page 63 LC-37XD10E/RU 3. IC3501/3502: RH-IXB765WJZZ 256Mb DDR SDRAM Pin No. Pin Name Pin Function 45,46 CK, CK Clock: CK and CK are differential clock inputs. All address and control input signals are sampled on the positive edge of CK and negative edge of CK. Output (read) data is referenced to both edges of CK.
  • Page 64 LC-37XD10E/RU 34,48, Ground. VREF SSTL_2 reference voltage. 4. IC3503: RH-IXB754WJZZ 128Mb Flash Memory Pin No. Pin Name Pin Function 2-12, A0-A22 23 Address lnputs. 18-26, 54, 31 35,37,3 DQ0-DQ7 8 Data Inputs / Outputs. 9,41,44 ,46,48, DQ8-DQ14 7 Data Inputs / Outputs. 42,44- DQ15A-1 Data Input/Output or Address Input.
  • Page 65 LC-37XD10E/RU 5. IC3504: RH-IXB753WJZZ 16BIT D-TYPE LATCH. Pin No. Pin Name Pin Function 47,46, 1D1-1D8 Input Signal 1D1-1D8. 43,41, 38,37 36,35, 2D1-2D8 Input Signal 2D1-2D8. 32,30, 27,26 Non_Output Enable Signal 1. Non_Output Enable Signal 2. Latch Enable Signal 1. Latch Enable Signal 2. 2,3,5,6 1Q1-1Q8 Latch Output Signal 1Q1-1Q8.
  • Page 66 LC-37XD10E/RU 6. IC3701: RH-IXB752WJZZ Multistandard Sound Processor. Pin Function Pin Name NET_NAME Not Connected. N.C. I2C_CL I2C Clock. SCL5 I2C_DA I2C Data. SDA5 I2S_CL Sync. I2S Clock. N.C. I2S_WS Sync. I2S Word Strobe. N.C. I2S_DA_OUT Sync. I2S Data Output. N.C. I2S_DA_IN1 Sync.
  • Page 67 LC-37XD10E/RU AVSS Analog Ground for IF Part. AVSS Analog Ground for IF Part. Not Connected. N.C. Not Connected. N.C. AVSUP Analog Power Supply +5V. AVSUP Analog Power Supply +5V. ANA_IN1 + IF Input 1. SIF-IN ANA_IN - IF Common (can be Left vacant only if lF input 1 is not used) ANA-IN- ANA_IN2 + IF Input2 (can be left vacant only if lF input 1 is not used)
  • Page 68 LC-37XD10E/RU 7. IC3301: FRC RH-IXB064WJ (FRC9429A) FRAME RATE CONVERTER Pin No. Pin Name Pin Function No Connection Test, do not use 656I1/YIN1 Digital (luminance) input 656I2/YIN2 Digital (luminance) input Vertical sync input 656I3/YIN3 Digital (luminance) input 656I4/YIN4 Digital (luminance) input VDDP0 Supply digital pad (3.3 V) VSSP0...
  • Page 69 LC-37XD10E/RU Tristate (SELOMODE=0) RGBOUT3 Digital (red: SELRB=0; blue: SELRB=1;) Output (SELOMODE=1) Tristate (SELOMODE=0) RGBOUT2 Digital (red: SELRB=0; blue: SELRB=1;) Output (SELOMODE=1) Tristate (SELOMODE=0) RGBOUT1 Digital (red: SELRB=0; blue: SELRB=1;) Output (SELOMODE=1) Tristate (SELOMODE=0) RGBOUT0 Digital (red: SELRB=0; blue: SELRB=1;) Output [LSB] (SELOMODE=1) Tristate (ENITUE=0) YOUT9 Digital (luminance/green) output [MSB] (ENITUE=1)
  • Page 70 LC-37XD10E/RU UVOUT4/ Tristate (ENITUE=0) INTR Digital (chrominance/blue) output (ENITUE=1 and SELRB=0) Digital (chrominance/red) output (ENITUE=1 and SELRB=1) Interrupt signal output from µC (CPUIRQ=5) Static 0 (CPUIRQ=6) Static 1 (CPUIRQ=7) VDDP6 Supply digital pad (3.3 V) VSSP6 Supply digital pad (0 V) Tristate (ENITUE=0) UVOUT3 Digital (chrominance/blue) output (ENITUE=1 and SELRB=0)
  • Page 71 LC-37XD10E/RU 656I62 Digital (luminance) input 656I72 Digital (luminance) input CLKIN2 Clock input [max. 81.0 MHz] UVIN0 Digital (chrominance) input [LSB] UVIN1 Digital (chrominance) input UVIN2 Digital (chrominance) input UVIN3 Digital (chrominance) input VSSP8 Supply digital core (0 V) VDDP8 Supply digital core (3.3 V) VDD8M Supply memory (1.8 V) VSSD60...
  • Page 72 LC-37XD10E/RU 8. IC1710: RH-IXB946WJZZ FPGA Pin No. Pin Name Pin Function Sheet name EXP[8] REG2 light control system identify REG2 EXP[9] REG external sync identify EXP[10] QS parameter TEMP3 EXP[11] QS parameter TEMP2 EXP[12] QS parameter TEMP1 EXP[13] QS parameter QSSET EXP[14] LED SLEEP (ON at "L")
  • Page 73 LC-37XD10E/RU VCCINT 3.3V Power supply 3.3V 3.3V from VGC Ground from VGC FPGA_SDE SDAI from VGC FPGA_SDA GND* SDAO Write mode RESET output FPGA_SDAO GND* GND* GND* GND* GND* OFL2EN OFL2_EN external setting terminal GND* VGC write Open drain (Write mode at "H") BOOT GND* Ground...
  • Page 74 LC-37XD10E/RU 9. IC1712: VHIMP1410ES-1 Step Down Converter. Pin No. Pin Name Pin Function High-Side Gate Drive Boost input. BS supplies the drive for the high-side n-channel MOSFET switch. Connect a 10nF or greater capacitor from SW to BS to power the high-side switch. Power input.
  • Page 75 LC-37XD10E/RU 11. IC301/302: VHITDA8931T-1 SOUND AMP Pin No. Pin Name Pin Function VSSD negative digital supply voltage; heat spreader VSSA Negative analogue supply voltage. inverting input. non inverting input. VDDA positive analog supply voltage. POWERUP power-up input. ENABLE enable input. DIAG diagnostic output.
  • Page 76 LC-37XD10E/RU VDDAADAC 3.3 V power for audio DAC VDDADC VSSAADAC Ground for audio DAC command switches GNDA- VDDASADAC 3.3 V power for audio DAC substrate VDDA- VCCAADAC 3.3 V power for audio DAC command switches VDDA GNDAADAC Ground for audio DAC GNDA- VCCASADAC 3.3 V power for audio DAC command switches...
  • Page 77 LC-37XD10E/RU EMIRDnotWR External read/write access indicator. Common to all devices. EMIRW H3,H2,G2,H4,G4,E2,E1,E3, EMIDATA[15:0] External common data bus. EMID[15- H1,D1,D2,C2,G3,C1,B1,A1 D5,C5,D6,B3,A2,B2,A3,B4, EMIADDR[25:2] External common address bus EMIA[23- A4,C6,B5,A5,D7,C7,B6,A6, B7,A7,D9,C9,B9,A9,B10,C1 (D5,C5=N notEMIREQGNT Bus request/grant indicator notEMIACKREQ Bus grant/request indicator (5 V tolerant) EMIBOOTMODE0 External power-up port size indicator (5 V tolerant) EMISDRAMCLK...
  • Page 78 LC-37XD10E/RU AF11 GOUT Green output AF13 BOUT Blue output COUT Chroma output COUT CVOUT Composite video output CVBS AF10 YOUT Luma output YOUT AD22 notHSYNC Horizontal sync (5 V tolerant) AE22 EVENnotODD Vertical sync (5 V tolerant) TL4016 5 – 22...
  • Page 79 LC-37XD10E/RU 13. IC4201/4202: RH-IXB742WJZZQ 64Mb- SDRAM Pin No. Pin Name Pin Function Active on the positive going edge to sample all inputs. Disables or enables device operation by masking or enabling all inputs except CLK,CKE and DQM. Masks system clock to freeze operation from the next clock cycle. CKE should be enabled at least one cycle prior to new command.
  • Page 80 LC-37XD10E/RU 15. IC4402: VHILCX573FT-1Y Lutch 3-State output Pin No. Pin Name Pin Function Output Enable. Data Input D0. Data Input D1. Data Input D2. Data Input D3. Data Input D4. Data Input D5. Data Input D6. Data Input D7. Ground. Limited Enable.
  • Page 81 LC-37XD10E/RU 18. IC4604: VHITSH73CPT-1Y *3-OP-AMP Pin No. Pin Name Pin Function STB1 Standby Input Terminal1. STB2 Standby Input Terminal2. STB3 Standby Input Terminal3. Power Source. +IN1 Non Inverting Input1. -IN1 Invreting Input1. OUT1 Output1. OUT2 Output2. -IN2 Inverting Input2. +IN2 Non Inverting Input2.
  • Page 82 LC-37XD10E/RU 19. IC202: RH-IXB682WJZZQ CDFDM DEMODURATOR Pin No. Pin Name Pin Function RESET Hardware reset, active low. XTALI Crystal oscillator input/external clock (1.8V). XTALO Crystal oscillator output. VCCXTAL1.8 Analog oscillator supply (1.8V) GNDXTAL Analog oscilltor ground. DVCCA1.8 Analog part digital supply (1.8V) REFM Internal negative reference.
  • Page 83 LC-37XD10E/RU — MEMO — 5 – 27...

  • Page 84: Chapter 6. Block Diagram/Wiring Diagram

    LC-37XD10E/RU CHAPTER 6. LC37XD10E BLOCK DIAGRAM/WIRING DIAGRAM Service Manual [1] OVERALL WIRING DIAGRAM OVERALL WIRING DIAGRAM 6 – 1...
  • Page 85 LC-37XD10E/RU 6 – 2...

  • Page 86: Block Diagram

    LC-37XD10E/RU [2] BLOCK DIAGRAM BLOCK DIAGRAM 6 – 3...
  • Page 87 LC-37XD10E/RU 6 – 4...

  • Page 88: Main Block Diagram

    LC-37XD10E/RU [3] MAIN BLOCK DIAGRAM 6 – 5...
  • Page 89 LC-37XD10E/RU 6 – 6...

  • Page 90: Power Block Diagram

    LC-37XD10E/RU [4] POWER BLOCK DIAGRAM POWER BLOCK DIAGRAM 6 – 7...
  • Page 91 LC-37XD10E/RU 6 – 8...

  • Page 92: Chapter 7. Printed Wiring Board

    LC-37XD10E/RU CHAPTER 7. LC37XD10E PRINTED WIRING BOARD Service Manual [1] KEY UNIT PRINTED WIRING BOARD S157 P151 S153 S151 D151 R151 S152 S154 D152 R153 S155 KEY Unit (Component Side) KEY Unit (Chip Parts Side) 7 – 1...

  • Page 93: R/C, Led Unit Printed Wiring Board

    LC-37XD10E/RU [2] R/C, LED UNIT PRINTED WIRING BOARD R101 C105 R136 R102 R110 R105 R137 R108 Q103 R109 Q102 R106 R104 R107 R123 D113 R124 R111 R112 R114 R127 R113 R/C, LED Unit (Component Side) R/C, LED Unit (Chip Parts Side) 7 –...

  • Page 94: Main Unit Printed Wiring Board

    LC-37XD10E/RU [3] MAIN UNIT PRINTED WIRING BOARD MAIN Unit (Side A) 7 – 3...
  • Page 95 LC-37XD10E/RU 7 – 4...
  • Page 96 LC-37XD10E/RU MAIN Unit (SIde A Chip) R1807 SC2705 LUG1701 D1902 D1910 D1907 D1908 IC1902 IC1901 D2302 D2301 FB2302 RJ3009 FB1901 R3038 D2304 D2303 FB1902 D1903 FB2301 LUG1705 R3061R3062 R1934 R3005 C1935 C1909 C1957 C1947 C1944 C1937 C1926 C1925 L1905 IC3001 C1955 C1948 C1945...
  • Page 97 LC-37XD10E/RU SC2705 SC2707 LUG1703 C2730 R1811 RJ2716 RJ3009 R3038 L2702 R2726 C2726 C2733 P2702 R3051R3052 R3061R3062 R1862 C1773 FB1706 C1777 C1778 C1772 C1775 C1776 C1765 C1774 C1780 R1749 R1731 R1783 R1736 R1784 R1738 C1766 R1860 R1859 FL2304 FL2309 FL2305 FL2310 FL2306 FL2314 FL2311...
  • Page 98 LC-37XD10E/RU MAIN Unit (Side B) 7 – 7...
  • Page 99 LC-37XD10E/RU 7 – 8...
  • Page 100 LC-37XD10E/RU MAIN Unit (Side B-Chip) C2725 FB2701 FB2702 R2702 R2343 C2324 C2323 R2376 RJ2303 R2396 RJ2304 R2397 C1711 R2374 RJ2305 R1712 R1794 X3001 R1793 R1792 Q2710 Q2709 R1796 Q1704 R3010 R3023 R1797 C3034 R1831 R2320 C3039 R1832 R1717 R1847 R1833 R1718 C1759 R1834...
  • Page 101 LC-37XD10E/RU R1816 C2328 FB2712 R2316 R2384 R2776 FB2309 R2382 FB2702 C1907 Q2310 C1908 R2702 R1914 IC1903 R1913 IC1904 R1915 R3044 Q1907 IC2301 C1905 R2381 Q1903 Q1901 Q1904 Q1902 R1911 R1912 R2314 R2386 R3010 R3042 C1963 C1959 R3012 C1962 C1960 R1931 R3025 R1918 R1910...

  • Page 102: Av Unit Printed Wiring Board

    LC-37XD10E/RU [4] AV UNIT PRINTED WIRING BOARD LUG301 D1102 D1105 D1117 R1121 D1116 P1101 FL1104 D1121 FL1105 R1111 IC1102 R1113 D1103 FL1101 R1114 D1107 R1117 FL1102 D111 Q110 Q1108 R1112 D1124 R1158 R1155 Q1106 R1123 R1116 R1152 R1125 D1125 C1251 Q1202 D1113 Q1204...
  • Page 103 LC-37XD10E/RU D1105 LUG304 R1121 D1116 P1201 P1101 P1102 FL1104 R1111 FL1105 C1130 D1103 D306 FL1101 R1114 C358 D308 D1107 R1117 C35 7 D307 FL1102 IC1101 D1119 Q1103 Q1104 Q307 C356 D1124 Q303 R1123 IC301 IC302 D317 C328 C1251 D315 D310 R335 C1219 C1214...
  • Page 104 LC-37XD10E/RU FB1101 D1102 R1127 R1119 D1105 P1101 P1102 R1131 C1105 C1108 D1117 C1154 D1121 C1109 R1110 FL1104 FL1108 I C 1102 C1130 R1113 R1111 FL1105 R1128 D1103 FB1102 C1115 D1107 R1124 R1104 C1101 FL1101 C1162 C1131 C1151 D1119 FL1102 C1152 J1101 R1105 C1116...
  • Page 105 LC-37XD10E/RU D1105 P1102 P1201 R1131 C1108 R361 D318 FL110 4 C364 R355 C1130 R1111 FL110 5 C358 C359 R1128 D1103 FB110 2 D1107 D308 D306 I C 1101 R1104 C1101 FL1101 R353 C1147 C1131 D307 C1151 Q307 D1119 FL1102 C1152 C303 R1105 C1116...
  • Page 106 LC-37XD10E/RU P1102 P1201 AV Unit (Side-B) 7 – 15...
  • Page 107 LC-37XD10E/RU P1102 P1101 7 – 16...

  • Page 108: Power Unit Printed Wiring Board

    LC-37XD10E/RU [5] POWER UNIT PRINTED WIRING BOARD POWER Unit (Side A) JD118 JD116 C762 P703 C766 P702 P701 JD138 C754 JD137 JD115 R819 C809 R821 JD136 C727 JD135 R850 JD114 C757 JD119 C744 C751 C755 C731 L753 L752 R889 JD133 D737 FB709 D735...
  • Page 109 LC-37XD10E/RU POWER Unit (Side B) 7 – 18...

  • Page 110: Digital Tuner Unit Printed Wiring Board

    LC-37XD10E/RU [6] DIGITAL TUNER UNIT PRINTED WIRING BOARD LUG201 Q209 C256 R271 C206 IC204 C204 R259 R214 R217 C212 R242 C218 R241 Q203 R222 FB203 IC208 C250 C249 R294 R298 C247 C246 R299 R293 L208 L209 C222 C236 R278 C279 C278 LUG203 LUG205...
  • Page 111 LC-37XD10E/RU D203 R201 D201 R226 R203 R204 R207 C202 C277 R208 C203 C211 D202 C205 R225 C219 R209 C223 FB202 L202 C220 R205 R238 R220 C209 R287 R264 R265 R216 R215 C263 C259 L210 C269 R289 R248 C268 R247 C254 R285 C272 C266...

  • Page 112: Digital Unit Printed Wiring Board

    LC-37XD10E/RU [7] DIGITAL UNIT PRINTED WIRING BOARD DIGITAL Unit (Side-A) 7 – 21...
  • Page 113 LC-37XD10E/RU 7 – 22...
  • Page 114 LC-37XD10E/RU R 4016 C4781 R 4034 R 4705 C4782 R 4782 R4718 R 4021 R 4024 C4023 C4010 LUG4602 R 4710 R4243 R4037 IC4701 FB4202 R 4191 C4702 R 4036 C4701 R 4196 IC4001 D4702 D4701 R 4195 R 4192 R 4194 C4019 FB4009...
  • Page 115 LC-37XD10E/RU R 4711 R 4016 P4002 R 4034 IC4702 R 4709 R 4650 R 4021 C4023 IC4705 C4010 R 4704 R 4675 R 4659 R 4616 R 4671 C4623 LUG4601 C4625 Q4607 R 4635 C4634 C4639 R 4636 C4604 C4635 C4001 C4640 C4606...
  • Page 116 LC-37XD10E/RU DIGITAL Unit (Side-B) 7 – 25...
  • Page 117 LC-37XD10E/RU 7 – 26...
  • Page 118 LC-37XD10E/RU R 4604 R 4603 R 4602 R 4645 R 4633 C4029 R 4601 S C4601 IC4003 C4208 R 4250 R 4246 R 4646 C4210 R 4647 R 4245 R 4648 R 4249 R 4649 FB4005 C4621 R 4642 FB4601 C4022 R4651 C4617...
  • Page 119 LC-37XD10E/RU R 4250 R4246 C4210 R4245 C4711 R4249 FB4701 R 4225 R 4229 R 4228 C4025 R 4227 IC4201 C4027 R4239 R 4025 4018 4019 D4703 R 4 717 C4714 C4414 R4434 R4433 R4419 R4439 7 – 28...
  • Page 120 LC-37XD10E/RU — M E M O — 7 – 29...

  • Page 121: Description Of Schematic

    LC-37XD10E/RU CHAPTER 8. LC37XD10E SCHEMATIC DIAGRAM Service Manual [1] DESCRIPTION OF SCHEMATIC DIA- GRAM VOLTAGE MEASUREMENT CONDITION: 1. The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 230V. Signals are fed by a colour bar signal generator for servicing pur- pose and the above voltages are measured with a 20k ohm/V tester.
  • Page 122 LC-37XD10E/RU [2] SCHEMATIC DIAGRAM MAIN Unit-1/8 8 – 2...
  • Page 123 LC-37XD10E/RU 8 – 3...
  • Page 124 LC-37XD10E/RU MAIN Unit-2/8 8 – 4...
  • Page 125 LC-37XD10E/RU 8 – 5...
  • Page 126 LC-37XD10E/RU MAIN Unit-3/8 8 – 6...
  • Page 127 LC-37XD10E/RU 8 – 7...
  • Page 128 LC-37XD10E/RU MAIN Unit-4/8 8 – 8...
  • Page 129 LC-37XD10E/RU 8 – 9...
  • Page 130 LC-37XD10E/RU MAIN Unit-5/8 8 – 10...
  • Page 131 LC-37XD10E/RU 8 – 11...
  • Page 132 LC-37XD10E/RU MAIN Unit-6/8 8 – 12...
  • Page 133 LC-37XD10E/RU 8 – 13...
  • Page 134 LC-37XD10E/RU MAIN Unit-7/8 8 – 14...
  • Page 135 LC-37XD10E/RU 8 – 15...
  • Page 136 LC-37XD10E/RU MAIN Unit-8/8 8 – 16...
  • Page 137 LC-37XD10E/RU 8 – 17...
  • Page 138 LC-37XD10E/RU AV Unit 8 – 18...
  • Page 139 LC-37XD10E/RU 8 – 19...
  • Page 140 LC-37XD10E/RU POWER Unit 8 – 20...
  • Page 141 LC-37XD10E/RU AND SHADED COMPONENTS=SAFETY RELATED PARTS 8 – 21...
  • Page 142 LC-37XD10E/RU D-TUNER Unit 8 – 22...
  • Page 143 LC-37XD10E/RU AND SHADED COMPONENTS=SAFETY RELATED PARTS 8 – 23...
  • Page 144 LC-37XD10E/RU DIGITAL Unit-1/4 8 – 24...
  • Page 145 LC-37XD10E/RU 8 – 25...
  • Page 146 LC-37XD10E/RU DIGITAL Unit-2/4 8 – 26...
  • Page 147 LC-37XD10E/RU 8 – 27...
  • Page 148 LC-37XD10E/RU DIGITAL Unit-3/4 8 – 28...
  • Page 149 LC-37XD10E/RU 8 – 29...
  • Page 150 LC-37XD10E/RU DIGITAL Unit-4/4 8 – 30...
  • Page 151 LC-37XD10E/RU 8 – 31...
  • Page 152 LC-37XD10E/RU KEY Unit 8 – 32...
  • Page 153 LC-37XD10E/RU R/C,LED Unit 8 – 33...
  • Page 154 LC-37XD10E/RU — M E M O — 8 – 34...

  • Page 155: Parts Guide

    LC-37XD10E PartsGuide PARTS GUIDE LCD COLOUR TELEVISION LC-37XD10E/RU MODELS CONTENTS PRINTED WIRING BOARD DUNTKD833FM06 (D-TUNER Unit) ASSEMBLIES (NOT REPLACEMENT ITEM) DUNTKE100FM01 (POWER Unit) LCD PANEL AND TUNER DUNTKD909FM05 (R/C, LED Unit) (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN DUNTKD910FM01 (KEY Unit) ASSEMBLY BUT NOT INDEPENDENTLY.)
  • Page 156 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACEMENT ITEM) MAIN Unit DUNTKD915FM10 AV Unit DUNTKD604FM21 DIGITAL Unit DUNTKD628FM12 POWER Unit DUNTKE100FM01 D-TUNER Unit DUNTKD833FM06 DUNTKD909FM05 R/C, LED Unit KEY Unit DUNTKD910FM01 [2] LCD PANEL AND TUNER (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY.) 37V FULL HD LCD Panel Module Unit R1LK370D3LZ1AY...
  • Page 157 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) C1783 Capacitor 0.01 50V Ceramic VCKYCY1HB103KY C1784 Capacitor 10 16V Ceramic RC-KZA073WJZZY C1903 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C1904 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C1910 Capacitor 10 16V Ceramic RC-KZA073WJZZY C1912 VCKYCY1HB102KY...
  • Page 158 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) C2725 Capacitor 220p 50V Ceramic VCKYCY1HB221KY C2726 Capacitor 0.1 25V Ceramic VCKYTV1EB104KY C2733 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C2734 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C2739 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C2740 VCKYTV1HB103KY...
  • Page 159 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) C3330 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C3331 Capacitor 10 16V Ceramic RC-KZA073WJZZY C3332 Capacitor 10 16V Ceramic RC-KZA073WJZZY C3333 Capacitor 10 16V Ceramic RC-KZA073WJZZY C3334 Capacitor 10 16V Ceramic RC-KZA073WJZZY C3335 VCEASY1CN476MY...
  • Page 160 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) C3709 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C3710 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C3711 Capacitor 10 16V Electrolytic VCEASX1CN106MY C3712 Capacitor 470p 50V Ceramic VCCCCY1HH471JY C3713 Capacitor 100 16V Electrolytic VCEASY1CN107MY C3714 VCCCCY1HH560JY...
  • Page 161 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) FB2303 Balun BLN-0210TA RBLN-0210TAZZY FB2305 Balun BLN-0061TA RBLN-0061TAZZY FB2306 Balun BLN-0061TA RBLN-0061TAZZY FB2307 Balun BLN-0061TA RBLN-0061TAZZY FB2308 Balun BLN-0061TA RBLN-0061TAZZY FB2309 RBLN-0061TAZZY Balun BLN-0061TA FB2310 Balun BLN-0210TA RBLN-0210TAZZY FB2701 Balun BLN-0254TA...
  • Page 162 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) IC3502 IC K4H561638H-UCB3 RH-iXB765WJQZQ IC3503 IC M29DW128F70NF6E RH-iXB754WJZZQ IC3504 IC SN74LVCH16373ADGGR RH-iXB753WJZZY IC3506 IC BD3533F-E2 VHiBD3533F+-1Y IC3701 IC MSP4410K-QA-D6 RH-iXB752WJZZQ IC3702 VHiAK4363VF-1Y IC AK4363VF J2701 Jack HDMI Input QJAKEA073WJZZ J2702 Jack HDMI Input...
  • Page 163 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) R1703 Resistor 0 1/4W Metal Oxide VRS-TW2ED000JY R1704 Resistor 0 1/16W Metal Oxide VRS-CY1JF000JY R1705 Resistor 0 1/16W Metal Oxide VRS-CY1JF000JY R1706 Resistor 33k 1/16W Metal Oxide VRS-CZ1JF333JY R1707 Resistor 0 1/16W Metal Oxide...
  • Page 164 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) R1797 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R1798 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R1800 Resistor 22 1/16W Metal Oxide VRS-CZ1JF220JY R1804 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY R1805 Resistor 100 1/16W Metal Oxide...
  • Page 165 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) R2333 Resistor 100 1/16W Metal Oxide VRS-CH1JF101JY R2334 Resistor 10k 1/16W Metal Oxide VRS-CY1JF103JY R2335 Resistor 1k 1/16W Metal Oxide VRS-CY1JF102JY R2336 Resistor 2.2k 1/16W Metal Oxide VRS-CY1JF222JY R2337 Resistor 10k 1/16W Metal Oxide...
  • Page 166 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) R3018 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY R3019 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R3024 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY R3026 Resistor 100 1/16W Metal Oxide VRS-CJ1JF101JY R3028 Resistor 100k 1/16W Metal Oxide...
  • Page 167 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) R3540 Resistor 33k 1/16W Metal Oxide VRS-CZ1JF333JY R3541 Resistor 22 1/16W Metal Oxide VRS-CZ1JF220JY R3542 Resistor 33 1/16W Metal Composition VRK-CD1JJ330JY R3543 Resistor 33 1/16W Metal Composition VRK-CD1JJ330JY R3544 Resistor 33 1/16W Metal Composition...
  • Page 168 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] DUNTKD915FM10 (MAIN Unit) SC2703 Connector 23Pin QCNCWA251WJZZY SC2704 Connector 23Pin QCNCWA251WJZZY SC2705 Connector 15Pin QCNCWA010WJZZY SC2707 Connector 23Pin QCNCWA251WJZZY TH3001 Thermistor VHHM1103J03-1Y X1901 RCRSCA108WJZZY Crystal X3001 Crystal 20.25MHz RCRSC0012CEZZY X3301 Crystal 20.25MHz RCRSC0012CEZZY X3701...
  • Page 169 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKD604FM21 (AV Unit) C1117 Capacitor 100p 50V Ceramic VCCCCY1HH101JY C1118 Capacitor 100p 50V Ceramic VCCCCY1HH101JY C1119 Capacitor 1000p 50V Ceramic VCKYCY1HB102KY C1120 Capacitor 1000p 50V Ceramic VCKYCY1HB102KY C1121 Capacitor 1 16V Ceramic VCKYTV1CB105KY C1122 VCKYCY1HB331KY...
  • Page 170 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKD604FM21 (AV Unit) D1113 Zener Diode EX1034CE RH-EX1034CEZZY D1114 Zener Diode EX1034CE RH-EX1034CEZZY D1115 Zener Diode EX1034CE RH-EX1034CEZZY D1116 Zener Diode EX1034CE RH-EX1034CEZZY D1117 Zener Diode EX1034CE RH-EX1034CEZZY D1118 RH-EX1026CEZZY Zener Diode 3.9V D1119 Zener Diode 3.9V...
  • Page 171 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKD604FM21 (AV Unit) R306 Resistor 4.7k 1/16W Metal Oxide VRS-CJ1JF472JY R307 Resistor 100k 1/16W Metal Oxide VRS-CJ1JF104JY R308 Resistor 47k 1/16W Metal Oxide VRS-CY1JF473JY R309 Resistor 47k 1/16W Metal Oxide VRS-CY1JF473JY R310 Resistor 1k 1/16W Metal Oxide...
  • Page 172 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DUNTKD604FM21 (AV Unit) R1143 Resistor 2.7k 1/16W Metal Oxide VRS-CJ1JF272JY R1144 Resistor 1k 1/16W Metal Oxide VRS-CY1JF102JY R1145 Resistor 1k 1/16W Metal Oxide VRS-CY1JF102JY R1146 Resistor 220 1/16W Metal Oxide VRS-TV1JD221JY R1147 Resistor 1k 1/16W Metal Oxide...
  • Page 173 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKD628FM12 (DIGITAL Unit) C4207 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C4209 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C4401 Capacitor 10 16V Electrolytic VCEASX1CN106MY C4402 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C4403 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY C4404 VCKYCY1EF104ZY...
  • Page 174 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKD628FM12 (DIGITAL Unit) IC4005 IC TC7SHU04FU(T5L,JF) VHiTC7SHU04-1Y IC4201 IC IXB742WJ RH-iXB742WJZZQ IC4202 IC IXB742WJ RH-iXB742WJZZQ IC4203 IC IXB921WJ RH-iXB921WJZZQ IC4204 IC BR24L64F-WE2 VHiBR24L64F-1Y IC4401 VHiTCLCX245-2Y IC TCLCX245 IC4402 IC TC74LCX573FT(EKJ) VHiLCX573FT-1Y IC4403 IC TC7SH08FU(TE85L,JF)
  • Page 175 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKD628FM12 (DIGITAL Unit) R4202 Resistor 47 1/16W Metal Oxide VRS-CH1JF470JY R4203 Resistor 47 1/16W Metal Oxide VRS-CH1JF470JY R4204 Resistor 47 1/16W Metal Oxide VRS-CH1JF470JY R4205 Resistor 47 1/16W Metal Oxide VRS-CH1JF470JY R4206 Resistor 47 1/16W Metal Oxide...
  • Page 176 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKD628FM12 (DIGITAL Unit) R4602 Resistor 47 1/16W Metal Oxide VRS-CY1JF470JY R4603 Resistor 47 1/16W Metal Oxide VRS-CY1JF470JY R4604 Resistor 47 1/16W Metal Oxide VRS-CY1JF470JY R4605 Resistor 47 1/16W Metal Oxide VRS-CY1JF470JY R4606 Resistor 47 1/16W Metal Oxide...
  • Page 177 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DUNTKD628FM12 (DIGITAL Unit) Screw, x4 XBPSN20P14JS0 Screw, x4 XJPS730P08WS0 Nut, x4 XNESN20-16000 [6] DUNTKD833FM06 (D-TUNER Unit) C202 Capacitor 22p 50V Ceramic VCCCCY1HH220JY C203 Capacitor 22p 50V Ceramic VCCCCY1HH220JY C204 Capacitor 1000 6.3V Electrolytic VCEASX0JN108MY C205 Capacitor 0.01 50V Ceramic...
  • Page 178 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [6] DUNTKD833FM06 (D-TUNER Unit) R216 Resistor 4.7k 1/16W Metal Oxide VRS-CY1JF472JY R217 Resistor 4.7k 1/16W Metal Oxide VRS-CY1JF472JY R218 Resistor 4.7k 1/16W Metal Oxide VRS-CY1JF472JY R220 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R225 Resistor 560 1/4W Metal Oxide...
  • Page 179 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] DUNTKE100FM01 (POWER Unit) C743 Capacitor 470 50V Electrolytic RC-EZ1268CEZZ C744 Capacitor 1200 35V Electrolytic RC-EZB104WJZZ C745 Capacitor 4700p 50V Ceramic VCKYCY1HB472KY C749 Capacitor 0.068 50V Ceramic VCKYTV1HB683KY C750 Capacitor 0.1 50V Ceramic VCKYCY1HB104KY C751 RC-EZB104WJZZ...
  • Page 180 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] DUNTKE100FM01 (POWER Unit) D737 Diode D15SCA4M-7000 RH-DXA081WJZZ D738 Diode D1FL40-5063 RH-DXA088WJZZY D739 Diode D5S9M-7000 RH-DXA085WJZZ D740 Diode 1SS352(TPH3,F) VHD1SS352//-1Y D741 Zener Diode EX1049CE RH-EX1049CEZZY D742 VHD1SS352//-1Y Diode 1SS352(TPH3,F) D743 Diode U05NU44(TE12L,Q) VHDU05NU44+-1Y D744 Diode RB160M-40TR...
  • Page 181 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] DUNTKE100FM01 (POWER Unit) Q710 Transistor 2SC3928A-T112-1R VS2SC3928AR-1Y Q712 Transistor 2SC3928A-T112-1R VS2SC3928AR-1Y Q713 Transistor 2SC3928A-T112-1R VS2SC3928AR-1Y Q721 Transistor 2SC3928A-T112-1R VS2SC3928AR-1Y Q723 Transistor PBLS6003D,115 RH-TXA037WJZZY Q724 RH-TXA037WJZZY Transistor PBLS6003D,115 Q725 Transistor PBLS6003D,115 RH-TXA037WJZZY Q726 Transistor 2SC3928A-T112-1R...
  • Page 182 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] DUNTKE100FM01 (POWER Unit) R783 Resistor 22k 1/16W Metal Oxide VRS-TV1JD223JY R784 Resistor 22k 1/16W Metal Oxide VRS-TV1JD223JY R785 Resistor 10k 1/16W Metal Oxide VRS-TV1JD103JY R786 Resistor 10k 1/16W Metal Oxide VRS-TV1JD103JY R787 Resistor 10k 1/16W Metal Oxide...
  • Page 183 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] DUNTKE100FM01 (POWER Unit) RDA702 Heat Sink (for SUB-H) PRDARA306WJFW RDA703 Heat Sink (for INV-H) PRDARA337WJFW RDA704 Heat Sink (for SUB-C) PRDARA308WJFW RDA705 Heat Sink (for INV-C) PRDARA367WJFW RDA706 Heat Sink (for 12V-C) PRDARA242WJFW VRS-CY1JF000JY Resistor 0 1/16W Metal Oxide...
  • Page 184 LC-37XD10E [10] CABINET PARTS 1-13 1-11 1-10 1-11 1-10 1-11 1-12...
  • Page 185 PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [10] CABINET PARTS Front Cabinet Ass'y CCABAB776WJ01 CABINET COVER GCOVAC259WJSA Badge, "SHARP" HBDGBA060WJSA LED Cover HDECQA667WJSA Shine Trim HDECSA010WJSA Spacer (Bottom) PSPAHB188WJZZ Spacer, x4 (Side) PSPAHB190WJZZ Spacer, x6 (FRONT COV TAPE) PSPAZB264WJZZ QCNW-F099WJQZ...
  • Page 186 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [10] CABINET PARTS Screw, x28 (CEN/LCD-ANG TUN) XBPS730P06WS0 Screw, x2 (FOR HDMI) XBPS830P06000 Screw, x3 (for-JACK) XEBS930P08000 Screw, x12 (CAB-B) XEBS940P20000 Screw, x4 (LCD ANG/CAB-A) XEBSN40P10000 XJPS730P04WS0 Screw, x3 (TRAYI/PLATE-FIX) Screw, x23 XJPS730P08WS0 Screw, x15 XJPS730P08WS0...
  • Page 187 LC-37XD10E [12] PACKING PARTS...
  • Page 188 LC-37XD10E PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [12] PACKING PARTS Packing Case (LC-37XD10E/S) SPAKCD434WJZZ Packing Case (LC-37XD10RU) SPAKCD435WJZZ Buffer Material SPAKXB400WJZZ Wrapping Paper SPAKPA338WJZZ Polyethylene Bag SSAKAA009WJZZ Polyethylene Bag SSAKAA010WJZZ Packing Label, x2 TLABM5584BMZZ Green Dot Label (LC-37XD10F) TLABSA050WJZZ Label TLABNB415WJZZ...
  • Page 189 LC-37XD10E/RU...
  • Page 190 LC-37XD10E/RU 2007 COPYRIGHT © 2005 BY SHARP CORPORATION ALL RIGHTS RESERVED. No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying , recording, or otherwise, without prior written permission of the publisher.

Table of Contents
