Summary of Contents for SilverStone TJ07
- Page 1 October, 2011 NO:G11205602...
- Page 2 SSI EEB, SSI CEB, Extended ATX, ATX, Micro ATX 2 x 120mm intake fan, 1200rpm, 21dBA 2 x 92mm exhaust fans, 1600rpm, 20dBA USB 3.0 x 4, audio x 1, MIC x 1 USB 3.0 x 4 + MIC + SPK...
- Page 10 XEON back plate installation guide Step 1 Install the XEON back plate onto the motherboard. The back plate can be installed with hole A-A, B-B, C-C and D-D. The hole B-B supports with SSI-CEB motherboard and the hole C-C and D-D support SSI-EEB motherboard. Step 2 Secure the XEON back plate with included 2 PCS screws...
