  • Page 1 GRUNDFOS PRODUCT GUIDE Domestic Water Supply Family...

  • Page 2: Table Of Contents

    Domestic Water Supply Family Table of Contents Handbook Applications Page No. • Constant pressure ............5 • Flow based pressure boosting ........5 • Suction lift ................6 • Rainwater harvesting ............6 Pump Selections • EZ Boost ................6 • MQ ..................6 • Basic Line Jets ..............6 Accessories • Pressure Tanks ..............7 • Pressure Switches .............. 7 • Valves ...................
  • Page 3 Handbook Domestic Water Supply Handbook Domestic Water Supply Handbook...
  • Page 4 Handbook Notes...

  • Page 5: Constant Pressure

    Handbook Applications Constant Pressure System: In constant water pressure systems, only the required discharge pressure needs setting. Cut-in / out pressures do not play a role in this system. In Grundfos’s BMQE constant water pressure system (EZ Boost), this is done by a simple touch of a button on the accompanying CU 301 control unit. Discharge pressure can be set from 40 to 100PSI, according to individual needs and piping system limitations. Time Flow Based Pressure Boosting: The pump starts automatically when water is consumed and stops automatically when the consumption ceases. This is accomplished by a flow switch connected to a printed circuit board (PCB). The flow switch is closed when water is consumed and the signal sent to the PCB starts the pump. The flow switch is opened when the con- sumption ceases and the signal sent to the PCB stops the pump. The pump will produce pressure in relation to the flow rate with any incoming pressure cumulative to the total discharge pressure. Incoming PSI = City Water Pressure Outgoing PSI = Incoming PSI + MQ Performance...

  • Page 6: Suction Lift

    Pump Selections: EZ Boost: Constant Pressure at the touch of a button. The EZ Boost uses the time tested technology used in the SQE constant pressure system (submersible application). The MSE 3 motors are based on solid state electronics and permanent magnet rotors which account for high motor efficiencies. Variable speed is offered though frequency control via the CU301 remote status box. The System can be set to operate at any duty point in the range between minimum and maximum performance of the pump. The EZ Boost has built in safeties in the solid state electronics. The small footprint of the pump allows the system to be positioned either vertically or horizon- tally depending on the needs of the application. Refer to the EZ Boost installation video on our web site www.grundfos.us MQ: Maximum Quality Flow Based Pressure Boosting System: The MQ is a complete, all-in-one unit, incorporating pump, motor, diaphragm tank, pressure and flow sensor, controller and check valve. Built in safeties ensure long life of the pump. These safeties include: dry running; excessive temperature; any overload conditions. The MQ is a self priming pump and needs no priming other than that at installation. The MQ is a plug- n-play system. Basic Line: Durable and dependable Basic Line Jets. Grundfos offers shallow well, deep well, and convertible jet pumps. Our jets are self-priming centrifugal pumps suitable for domestic water supply, light agriculture, and industrial water transfer applications. Three models include: JPS; JPF; JDF. The...

  • Page 7: Pressure Tanks

    Theory: Matching consumption and pump capacity: Selecting the right pump is a matter of matching water c onsumption with pump capacity. Installing an under or oversized pump should be avoided. Consumption varies greatly d epending on housing standards and lifestyle. Garden watering in the summer can increase consumption. Pump Selection: Pump selection is based on the water demand and the system h ead. The water demand depends on the number of consumers connected to the system. Head can either be expressed in feet or P SI. Head refers to static head, pressure head, and friction head. For assistance in Pump Selection refer to the WebCAPS selection p rogram found on the Grundfos web site. Piping: In any water supply system, the sizing and choice of materials of t he pipe work has an impact on the choice of pumps and on the cost. Piping takes into account the system head as referred to in P ump Selection. Static head is the distance from the ground water level to the uppermost tap. Pressure head is the system p ressure the customer wants to achieve. I n most residential application this pressure is approximately 60PSI. Friction head depends on the pipe size, type and length. When calculating friction loss always remember to allow for deterioration in the piping schematic as all water pipes will eventually become coated with rust, lime deposits, etc. Flow velocity in the piping must be kept low as noise can occur due to turbulence in elbows and valves or from water hammer. Fitting a pressure relief valve in the discharge...

  • Page 8: Suction Lift

    Handbook Troubleshooting Troubleshooting: Suction Lift: When installing above ground suction lift pumps, the following basic rules must be adhered to: • Avoid frost. • Pump only clean water. • Install a filter if water contains impurities. • A foot-valve must be installed. • The suction pipe must be 100% air tight. • The pump must be primed before starting for the first time. Fault Cause Remedy a) The pump and suction pipe Fill the pump and pipe with work need to be primed. water. 1. The pump is running but there is no pressure. Check all connections and the b) The suction pipe is not 100% tight.

  • Page 9: Pressure Tanks

    8. Pump switches on and off b) Faulty foot valve. essary. frequently. c) The pressure switch differential between the start and stop pressures Increase the differential. is too small. Pressure Tanks: Keep the following tips in mind, when dealing with installations using pressure tanks: • Stop the pump and open a valve to relieve the water pressure before checking the pre-charge pressure of the tank. • For traditional on/off controlled pumps, the pre-charge pressure should equal the cut-in pressure multiplied by 0.9. Installation note: You should always consult the Instruction and Operation manual for each specific pump during installation and start. WebCAPS: Find detailed information via the Grundfos website. WebCAPS is an easy to use on-line tool that enables users to size systems and access general information about our products, where you can easily download the most up-todate pump information.
  • Page 11 Product Guide EZ Boost™ System EZ Boost System with BMQE Booster Pump, Tank, Pressure Sensor, and Controller...

  • Page 12: Ezboost

    Contents EZ Boost System Product Guide Page No. General data Product range Materials of construction Type key 15 BMQE performance curves 22 BMQE performance curves 30 BMQE performance curves Dimensions, weights and electrical data Dimensional sketch Technical data - BMQE pump Technical data - EZ Boost controller Accessories EZBoost Quick Guide EZBoost System Diagram EZBoost Pre-Installation Parallel Operation...
  • Page 13 Inlet pressure: Min. 8 PSI (0.55 bar) BMQE Pump Sound-pressure level: The sound pressure level of the The pumps used for The Grundfos EZ Boost system are BMQE is lower than 74 db[A] at a distance of 3 feet (1 modified SQE submersible pumps. The EZ Boost BMQE meter). pump is an SQE pump with an MSE 3 motor. Pump and motor are centered in the 4” stainless steel sleeve.
  • Page 14 22 BMQE 10C-190 15 BMQE 05A-110 22 BMQE 05B-120 30 BMQE 10C-130 22 BMQE 05A-80 30 BMQE 05B-90 Q [US GPM] Q [m³/h] Product range Range BMQE 15 BMQE 22 BMQE 30 Nominal flow rate [US GPM (m3/h)] 15 (3.4) 22 (5.0) 30 (6.8) Temperature range +32 to +95°F (0 to +35°C) Maximum inlet pressure [PSI (bar)] 217 (15)
  • Page 15 Product Guide EZ Boost System Materials BMQ Sleeve Pos. Description Material AISI Sleeve Stainless steel Flange Stainless steel Stainless steel/ Cable entry Air vent screw Stainless steel O-ring Pump Pos. Description Material AISI Valve casing Polyamide/PVDF Discharge chamber Stainless steel O-ring NBR rubber Valve seat NBR rubber 222a Empty chamber Polyamide/PVDF Top bearing NBR rubber Neck ring Polyamide/PVDF Lock ring Stainless steel...
  • Page 16 Product Guide EZ Boost System [psi] [ft] 15 BMQE 60 Hz 07B-180 (5-stage) 05A-110 (3-stage) Q [US GPM] 4.5 Q [m³/h] [kW] [hp] Q [US GPM]...
  • Page 17 Product Guide EZ Boost System [psi] [ft] 10C-190 (5-stage) 05B-120 (3stage) 05A-80 (2-stage) 30 Q [US GPM] Q [m³/h] [kW] [hp] 30 Q [US GPM]...
  • Page 18 Product Guide EZ Boost System [psi] [ft] 10C-130 (3-stage) 05B-90 (2-stage) Q [US GPM] Q [m³/h] [kW] [hp] Q [US GPM]...
  • Page 19 Product Guide EZ Boost System Weights and electrical data Max. motor output Rated Locked rotor Shipping Shipping [P2] Material Rated Model current current weight volume number Voltage [lb (kg)] 15 BMQE 05A-110 91128524 0.845 0.63 110-115 11.1 26 (11.8) 22 BMQE 05A-80 91128527 0.845 0.63 110-115 11.1 26 (11.8)
  • Page 20 Sound pressure level The sound pressure level is < 74 db[A] at a distance of 3 feet (1 meter). It is recommended by Grundfos that the pump be installed with sound and vibration dampening equipment such as; flexible piping adapters and anti-vibration mounting. The pump should not be mounted in or adjacent to living quarters. The pump can also be wrapped with sound proofing insulation to reduce noise.
  • Page 21 Product Guide EZ Boost System Voltage 1 x 100-240 V –10%/+6%, 60 Hz EZ Boost Controller Power The EZ Boost controller is a control and communication consumption unit especially developed for the BMQE booster pumps in Current Maximum 130 mA constant pressure applications. consumption Enclosure class NEMA 3R (IP 55) The EZ Boost controller provides: Ambient In operation: -22 to +122°F (-30 to +50°C) • Full control of the BMQE pumps temperature during storage: -22 to +140°F (-30 to +60°C) • Two-way communication with the BMQE pumps Relative • Possibility of adjusting the pressure air humidity • Alarm indication (LED) when service is needed Maximum length between EZ Boost control-...
  • Page 22 Product Guide EZ Boost System Accessories EZ Boost constant pressure kit Description Rating Material number EZ Boost controller and pressure sensor 40 to 100 PSI setting range 91128636 EZ Boost controller Description Rating Material number EZ Boost controller 40 to 100 PSI setting range 91121987 Sensor Description Rating Material number Pressure sensor kit for EZ Boost controller 0 to 120 PSI, 1/2” NPT 96437852 Diaphragm tank Duty range Materials Pre-charge pressure: 40 PSI Liner: Polypropylene Max. operating pressure: 150 PSI...
  • Page 23 Product Guide EZ Boost System EZ Boost Quick Guide EZ Boost Quick Selection Guide Example: 1. The maximum demand is 15 GPM (3.4 m3/h). 2. The pressure required is 70 PSI system pressure at the taps in the building. 3. The normal minimum inlet pressure (e.g. city pressure) is 20 PSI. 4. The additional boost required is 50 PSI at 15 GPM (3.4 m /h). 5. Select a 15 BMQE 05A-110. Additional (boost) pressure required in PSI 15 BMQE 07B-180 15 BMQE 07B-180 22 BMQE 10C-190 22 BMQE 10C-190 15 BMQE 05A-110 15 BMQE 05A-110...
  • Page 24 Product Guide EZ Boost System PRE-INSTALLATION Fig. 1 Pressure Stop +7 PSI A guide to the EZ Boost System The EZ Boost Constant Pressure System automatically balances water surges and equalizes flow and pressure according to consumption. In other words, the system Controlling Dynamic Start...
  • Page 25 Product Guide EZ Boost System BMQE pumps connected in parallel When connecting BMQE pumps in parallel as shown in fig. 5, a separate EZ Boost controller must be used on each BMQE. Set the pressure on one BMQE 10 PSI lower than the other.
  • Page 27 Product Guide Flow based pressure boosting system 60 Hz...
  • Page 28 Contents General data Page No. Application Type key Pumped liquids Operating conditions Technical data Features and benefits Control panel Product range Technical data Electrical data Dimensions Material specifications Flooded suction performance curves MQ 3-35 suction lift performance curves MQ 3-45 suction lift performance curves Accessories...

  • Page 29: Technical Data

    Product Guide Flow Based Pressure Boosting System Application Features and benefits The MQ pump is designed for water supply and pressure • Complete system boosting ... The MQ is a complete, all-in-one unit, incorporating pump, motor, diaphragm tank, pressure and flow sensor, • homes controller and check valve.
  • Page 30 Product Guide Flow Based Pressure Boosting System Control panel operation Pos. Function Description The Pump is started and stopped by ON/OFF button means of the ON/OFF button. Indicates that the pump is ready for operation (green). Power indicator lights Indicates that the pump is on standby (red).
  • Page 31 Product Guide Flow Based Pressure Boosting System Material specification Pos. Components Material Pos. Components Material Support flange PP+30% Glass Fiber HB (f1) Suction port PPO+20% Glass Fiber Shaft seal: Chamber PPO+20% Glass Fiber Stationary and Carbon/ceramics/NBR rubber Drain and priming plug PPO+20% Glass Fiber rotating part Self-priming valve...
  • Page 32 Product Guide Flow Based Pressure Boosting System Flooded suction (0 PSI inlet) performance curves* *See suction lift performance curves for installations with water level below intake.
  • Page 33 Product Guide Flow Based Pressure Boosting System MQ 3-35 Suction lift performance curves H [ft] p [psi] MQ 3-35 model B MQ 3-35 60 Hz 60 Hz 0 Ft 3.3 Ft 6.6 Ft 13.1 Ft 19.7 Ft 23.0 Ft 26.2 Ft Q [US GP M] Q [m³/h] Provided it is filled with water, the pump is able to lift water from a depth of 26 ft (8 m) in less than 5 minutes.
  • Page 34 Product Guide Flow Based Pressure Boosting System MQ 3-45 Suction lift performance curves MQ 3-45 model B MQ 3-45 [ft] [psi] 60 Hz 60 Hz 0 Ft 3.3 Ft 6.6 Ft 13.1 Ft 19.7 Ft 23.0 Ft 26.2 Ft Q [US GP M] Q [m³/h] Provided it is filled with water, the pump is able to lift water from a depth of 26 ft (8 m) in less than 5 minutes.
  • Page 35 Product Guide Flow Based Pressure Boosting System Accessories Protection Cover: Designed to protect the MQ Key Pad and electronics in outdoor applications. Protection cover is required for outdoor applications where the MQ is exposed to the elements. The protection cover is sold as an accessory PN 96693071. The cover is made of polypropylene and is a snap fit to the MQ.
  • Page 37 Product Guide Basic Line Jets JPF, JPS, JDF Shallow Well, Deep Well and Convertible Jet Pumps 60 Hz...

  • Page 38: Basic Line Jets

    Contents Basic Line Jets General data Page No. Performance range Product range Applications Pumps Motors Pumped liquid Agency approvals Mounting position Electrical data Materials of construction Technical data JPF 2A, 3A, 4A, 41A Shallow Well Cast Iron Dimensions and Weights Performance Chart Performance Curves JPF 5A, 7A Convertible Cast Iron Dimensions and Weights Conversion Instructions Performance Chart Performance Curves Deep Well Performance Chart...
  • Page 39 Product Guide Basic Line Jets Performance range * Capacities given are for near-sea level installations.
  • Page 40 Product Guide Basic Line Jets Product range Model JPF 2-A JPF 3-A JPF 4-A JPF 41-A JPF 5-A JPF 7-A JPS 2-A JPS 4-A JDF 2-A JDF 4 Flow range (U.S. gpm) 1.7-13 1.7-12.2 1.7-16 1.8-21 2.6-22 2.6-35 1.7-17 3.5-28.2 1.8-10.3 0.75-13.1 Max.
  • Page 41 Basic Line Jets Applications Motors Shallow well, Deep well and Convertible pump appli- All jet pump motors are totally enclosed and fan- cations. Grundfos jet pumps are self-priming centrifu- cooled design for quiet operation and superior protec- gal pumps suitable for domestic water supply systems, tion in harsh environments. Stainless steel motor shaft offers excellent corrosion resistance. Double, oversized light agricultural and industrial water transfer applica-...
  • Page 42 Product Guide Basic Line Jets Electrical Data: Electrical Data Model Voltage Capacitor S.F. Amps 60 Hz Maximum Nominal µF JPF2A 0.65 1.75 JPF2A 0.65 1.75 JPF3A 0.85 JPF3A 0.85 12.5 JPF4A 1.10 JPF4A 1.10 JPF41A 1.31 JPF41A 1.31 JPF5A 1.70 31.5 JPF7A 2.40...
  • Page 43 Product Guide Basic Line Jets JPF 2A, 3A, 4A, 41A* Shallow Well JPF 5A, 7A Convertible* 41A available in Canada Available in Canada Materials: JPF 5A, 7A Materials: JPF 2A, 3A, 4A, 41A Convertible Shallow Well Descriptions Material Descriptions Material Motor Stool Cast Iron Motor Stool...
  • Page 44 Product Guide Basic Line Jets JPS 2A, 4A Shallow Well JDF 2A, 4A Deep Well Materials: JPS 2A, 4A Shallow Well Materials: JDF 2A, 4A Deep Well Descriptions Material Descriptions Material Motor Stool Cast Iron Motor Stool Cast Iron Shaft Seal Carbon/Ceramic/NBR Shaft Seal Ceramic/Ceramic/NBR...
  • Page 45 Product Guide Basic Line Jets JPF3A Pump package* JPS2A Pump package* Cast Iron Stainless Steel Available in Canada Available in Canada Features and Benefits Assembled jet-pump and tank package. Available with rugged 1/2 hp cast iron pump or corrosion-resistant stainless steel pump, mounted on a stainless steel, 6.3 gallon (24 litre) diaphragm tank. Package comes complete with pressure switch, gauge, hose and fittings, ready for installation.
  • Page 46 Product Guide JPF 2A, 3A, 4A, 41A Dimensional Drawings Dimensions and Weights Pump Motor Data Dimensions (inches) Ship Ship Type Suction Disch. Vol. (lbs) Ft.) S.F. Volts IØ JPF2A 1/3 1.75 115 or 230 1’’ 1’’ 16.2 0.38 JPF3A 115 or 230 1’’...
  • Page 47 Product Guide JPF 2A, 3A, 4A, 41A Performance curves * Capacities given are for near-sea level installations.
  • Page 48 Product Guide JPF 5A, 7A Convertibles Dimensional Drawings Shallow Well Deep Well Dimensions and Weights Pump Motor Data Dimensions (inches) Ship Ship Type Suction Disch. Vol. turn (lbs) Ft.) HP S.F. PH Volts IØ JPF5A 1-1/4’’ 1’’ 1’’ 22.0 15.3 8.3 11.0 8.7 2.0 13.8 7.8 0.78 5.7 10.0 6.2 4.3 2.1 0.44 70 JPF7A 1-1/4’’...
  • Page 49 Product Guide JPF 5A, 7A Convertibles Shallow Well Performance Chart Discharge Pressure (PSI) Pressure Switch Model Depth to Water Shut-off (PSI) Settings (PSI) Capacities (U.S. gpm)* 20.5 17.5 86.5 18.5 17.5 17.5 JPF5A 1-1/2 15.5 14.5 81.5 50-70 13.5 13.5 13.5 12.5 76.5...
  • Page 50 Product Guide JPF 5A, 7A Convertibles Deep Well Performance Chart Depth to water (feet) Model Ejector Type Discharge Pressure (psig) Capacities U.S. gpm* 14.9 13.2 11.4 12.1 10.2 10.1 JPF5A 17.5 15.8 14.3 11.7 14.2 12.5 10.6 11.0 11.9 10.5 JPF7A * Capacities given are for near-sea level installations.
  • Page 51 Product Guide JPS 2A, 4A Dimensional Drawings Dimensions and Weights Pump Motor Data Dimensions (inches) Ship Ship Suction Disch. Type Vol. (lbs) Ft.) S.F. Volts IØ JPS2A 115 or 230 1’’ 1’’ 14.8 0.83 0.42 JPS4A 115 or 230 1’’ 1’’...
  • Page 52 Product Guide JPS 2A, 4A Performance curves * Capacities given are for near-sea level installations.
  • Page 53 115 or 230 1.25’’ 1’’ 1’’ 15.2 0.38 Deep Well Ejector Dimensions 11.6 5.63 1’’ NPT 1’’NPT 1.25’’NPT Nozzle and Venturi Combinations for Grundfos Deep Well Jet Pumps Ejector Type Nozzle Size Venturi Size Inches Inches 0.24 0.48 0.24 0.40 0.24 0.34...
  • Page 54 Product Guide JDF 2A, 4A Performance Chart Depth to water (feet) Model Ejector Type Discharge Pressure (psig) Capacities U.S. gpm* 12.0 SHUTOFF (psi) 10.4 JDF2A SHUTOFF (psi) 1.25 SHUTOFF (psi) SHUTOFF (psi) 13.3 11.1 JDF4A SHUTOFF (psi) SHUTOFF (psi) * Capacities given are for near-sea level installations.
  • Page 55 Product Guide JPF3A Pump Package* Cast Iron Body Construction Available in Canada Dimensional Drawings Dimensions and Weights Motor Data Pump Type Dimensions (inches) Ship Ship Suction Disch. Vol. (lbs) Ft.) S.F. Volts JPF3A 115 or 230 1’’ 1’’ 11.9 15.2 11.9 Shallow Well Performance Chart Discharge Pressure (PSI)
  • Page 56 Product Guide JPS2A Pump Package* Stainless Steel Body Construction Available in Canada Dimensional Drawings Dimensions and Weights Pump Motor Data Dimensions (inches) Ship Ship Vol. Suction Disch. Type (Cu Ft.) (lbs) S.F. Volts IØ JPS2A 1/2 1.6 115 or 230 1’’...

  • Page 57: Submittal Data Sheet

    Submittal data sheet Company name: Prepared by: Phone number: ( Fax number: ( Submittal Data Sheet Date: Page 1 of: Quote number: Client Information Project title: Client name: Reference number: Client number: Client contact: Client phone no: ( Location Information For: Unit: Site:...
  • Page 60 Thinking ahead makes it possible Innovation is the essence 2008, 2009 Grundfos Pumps Corp. Subject to alterations Grundfos Pumps Corporation Grundfos Canada, Inc. Bombas Grundfos de Mexico, S.A. de C.V. 17100 W. 118th Terrace 2941 Brighton Road Boulevard TLC #15 Olathe, KS 66061 Oakville, Ontario L6H 6C9 Canada Parque Stiva Aeropuerto...
