DS-70U/DS-90U/DS90UC
TROUBLE SHOOTING GUIDE
A. Note on Windows Vista Modes
=============================
Normally, Windows Vista is in WDDM mode. In this mode, Vista graphics drivers are used,
and the Vista Aero Glass and Vista Basic themes are available.
Windows Vista PCs whose graphics drivers are not Windows Vista native will run in
XDDM (XP-Compatible) mode. In this mode, the 3D Aero Glass theme is not available.
This mode will be limited to PCs that were upgraded from XP to Vista and PCs with low-end
graphics cards.
DisplayLink software supports both modes in different ways, and the level of support and issues
are different in the two cases.
B. PC Recommended Specifications
=============================
DisplayLink software can be run on PCs ranging from Netbooks (e.g. Asus EeePC),
Notebooks/Laptops, and Desktops - on processors ranging from Atom N270 based PCs,
basic single Core CPUs, and of course the latest Dual and Quad Core CPUs.
The performance of the software is dependent upon the processing power available, and so more
capable systems offer higher performance.
Recommended typical system requirements are:
C. Windows Vista
=============================
For Windows Vista, the Windows Experience Index (WEI) is a useful measure of hardware level.
The WEI is accessible from Computer->Properties or from Control Panel->System.
The recommended typical hardware requirements for the PC are:
* WEI score of at least 3 in the 'Graphics; Desktop performance for Windows Aero' category.
* Recommended: WEI score of at least 3 overall, as recommended by Microsoft.
* At least one USB 2.0 port
* 30 megabytes (MB) of free disk space
* Computer screen for use with the DisplayLink device, if it is not integrated.
* Network access for software downloads, or access to a CD-ROM drive.
If the PC specification is below this, performance will be lower (or CPU loading higher).
Advertisement
Related Manuals for DoubleSight DS-7OU
Summary of Contents for DoubleSight DS-7OU
-
Page 1: Trouble Shooting Guide
DS-70U/DS-90U/DS90UC TROUBLE SHOOTING GUIDE A. Note on Windows Vista Modes ============================= Normally, Windows Vista is in WDDM mode. In this mode, Vista graphics drivers are used, and the Vista Aero Glass and Vista Basic themes are available. Windows Vista PCs whose graphics drivers are not Windows Vista native will run in XDDM (XP-Compatible) mode. - Page 2 D. Windows XP/2000 ================ * For 1-2 monitors, business usage, productivity target. This may not provide full frame rate DVD playback at full screen. - 1.2GHz Single Core CPU (Celeron or Atom N270 for example) - 512MB memory * For 3 monitors where 1 could run DVD video while also targeting productivity and business apps. Will support only 1 video of DVD resolution at full screen: - 1.8GHz CPU - 1GB memory...
- Page 3 Known Issues - General DisplayLink screens are not supported on systems with two graphics cards used simultaneously (supporting separate screens, or in ATI Crossfire configuration). Two graphics cards in Nvidia SLI configuration are supported. (1704, 4441) DispayLink software may cause blue screens on software configurations where WDDM drivers from different manufacturers have been installed on the same system, even if just one graphics card is present.
- Page 4 On Vista WDDM systems with Intel 945GM graphics and with graphics driver versions around 7.14.10.1461 and 7.14.10.1504, playing a video on a DisplayLink attached screen can cause the whole system to run very slow. A reboot is needed to resolve this. To avoid the problem, do not play video on such DisplayLink screens, or downgrade the graphics drivers.
- Page 5 With Vista, a maximum of four DisplayLink screens are supported on machines with Nvidia graphics. In certain rare cases, exceeding this has been seen to cause repeated serious crashes. (1781) On Vista WDDM, older versions of Nvidia drivers with versions prior to 7.15.11.146 can behave badly in the presence of DisplayLink software.
- Page 6 On Vista WDDM, Nvidia 5 series graphics cards with driver version 7.15.10.9685 cause rundll32 crash messages in the presence of DisplayLink software. If you have such a card, please update to a more recent graphics driver version. (3077) On some Nvidia SLi systems, it is not possible to enable or disable SL1 mode while a DisplayLink screen is attached.
- Page 7 If devices are detached from the PC before going into standby, then reattached during standby, very occasionally they may not resume when the PC comes out of standby. If this happens, detach and reattach the devices to make them work again. (1492) Known Issues - Other In PowerPoint, the “Display slide show on:”...
- Page 8 E3. Video players, rendering technologies and applications ----------------------------------------------------------------------------- Video is supported on Windows Vista in WDDM (Aero) mode. Video playing and rendering using hardware overlays is not supported. The following players are tested by DisplayLink: - Windows Media Player 11 (www.microsoft.com/windows/windowsmedia/default.mspx) - WinDVD 8 (www.intervideo.com) - PowerDVD 7 (www.cyberlink.com)
- Page 9 On Vista WDDM, applications such as games that use Direct3D will not display on a DisplayLink attached screen that is set to primary. (1815) Some players, including Windows Media Player, do not play DVD content well on DisplayLink attached screens which are set as primary. (2084) Known issues with specific players and applications On Vista WDDM, if Windows Media Player is moved to the DisplayLink screen and is then made full-screen, the screen blanks.
- Page 10 When installing, make sure that only a single user is logged into the PC. That user needs administrator privileges. (1112) On PCs where vbscript.dll is not registered with the DLLServer, the DisplayLink installer cannot run. (1824) AutoUpdate dialogs and menus are not yet localised in Hungarian, Portuguese and Traditional Chinese.
- Page 11 Known issues - Windows 2000 Installation of DisplayLink driver on Windows 2000 SP4 requires patch SP4 Rollup 1. This is available from www.microsoft.com. See Microsoft Knowledge Base article KB891861. It is important to check in Windows 2000 that full USB2 is available, otherwise performance will be impaired.
- Page 12 On XP, video support is limited to players that support hardware overlays. In extend mode, the following media players work: - Windows Media Player 11 (www.microsoft.com/windows/windowsmedia/default.mspx) - WinDVD 8 (www.intervideo.com) - PowerDVD 7 (www.cyber1ink.com) - RealPlayer 11 (www.real.com) There is limited support for other video players, and for video in mirror mode. This table shows what rendering interfaces are supported: Interface Supported on XP extend?
- Page 13 Skype video does not work on DisplayLink screens with Windows XP. This is because Skype video uses VMR9, which is supported by DisplayLink software on Vista WDDM, but not on Vista XDDM or on XP. Trying to use skype video on XP may cause black screens or freeze the DisplayLink attached screen.
- Page 14 DisplayLink devices are not operational. In this case, reboot again and they become operational. (969) Smart USB Monitor - Product Support Additional support for your DoubleSight Displays Smart USB Monitor can be found by visiting www.doublesight.com or by calling DoubleSight Customer Service at 888.897.8869...
