INSTRUCTIONMANUAL

Version No：20151026

Thank you for buying Agile products. Please read this manual

carefully before assembling. We recommend that you keep this

manual for future reference regarding tuning and maintenance.

SAFETY PRECAUTIONS

This radio controlled helicopter is NOT A TOY! It has some technical

requirements, you must pay attention to the flying environment and

correct operation. Never fly your radio controlled helicopter over

people or near crowds. Teenagers must fly under the guardian's guide.

Beginners must fly under the guardian of experienced pilot.

Product Specifications

Length：1370mm

Height：420mm

Width：200mm

Main Rotor Diameter：Ø1560

Main Blade Length：690-713mm

Tail Rotor Diameter：Ø294mm

Tail Blade Length：105-115mm

Motor Pinion：19T

Motor KV：540KV

Driving Gear：(19/54)(20/66)

Gear Ratio：19T(9.37:1)

Tail Gear Ratio: 4.75:1

Weight(w/o power)：4000g

Flying Weight: 5600g

Battery：22.2V 5000mAh x2

ESC：160-200A

Aluminium: 7075-T6

Bearings: japanese

One way Bearing: German

Version No

：

20150420

Table of Contents

Summary of Contents for KDS AGILE 7.2

Page 1 INSTRUCTIONMANUAL INSTRUCTIONMANUAL Version No：20151026 Product Specifications Length：1370mm Height：420mm Width：200mm Main Rotor Diameter：Ø1560 Main Blade Length：690-713mm Tail Rotor Diameter：Ø294mm Tail Blade Length：105-115mm Motor Pinion：19T Motor KV：540KV Driving Gear：(19/54)(20/66) Gear Ratio：19T(9.37:1) Tail Gear Ratio: 4.75:1 Thank you for buying Agile products. Please read this manual Weight(w/o power)：4000g carefully before assembling.
Page 2: Safety Notes
1.INTRODUCTION Congratulations on your purchase of the Agile 7.2 radio controlled helicopter kit. Agile 7.2 was designed in Europe by Eng. Gaziano Roberto and is proudly manufactured by KDS Model. Our goal was to offer you something different with a minimum of parts, easy maintenance, and outstanding flying performances.
Page 3: Safety Check Before Flying
-Threadlock blue * (medium) -Threadlock red * (high strength) -Bearing retainer compound -Epoxy A+B Glue -Grease -Oil *Colors may vary depending on your area. Page 02 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 4: Equipment Required For Assembly
Screws bag Metal parts of main Rotor Head x1 Metal parts of main frame x1 Metal parts of Tail Unit x1 Page 03 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 5: Backplane Assembly
Do not overtighten It Is recommended to put on this area some adhesive Hook and loop tape to hold the battery Page 04 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 6: Assembly Process Of Main Frames And Power System
8.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 05 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 7 9.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 06 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 8 10.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 07 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 9 11.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 08 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 10 12.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 09 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 11 1 x M3 x14 mm FRONT CANOPY DAMPING ALUMINIUM SLEEVE FOR CASE BOLTS Ensure you get all the Insert guides into the right place Page 10 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 12 ALUMINIUM SLEEVE FOR CASE BOLTS FRONT CANOPY DAMPING 1x Nylstop NutM4 1x Set Screw 4x25 mm 1xM3x14mm 1x Set Screw 4x25 mm 1x Nylstop NutM4 Page 11 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 13 KA-72-094 KA-72-094 KA-72-094 K A - 7 2 - 0 9 2 Ø3. 0 xØ5 . 0 x 0 . 5 Page 12 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 14 16.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 13 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 15 REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Servo plate x4 Page 14 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 16 18.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 15 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 17 19.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 16 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 18 Washer 10x 15x 0.5 Washer 10x15mm This washer cancelled，not needed in asse mbling Page 17 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 19 B u t t o n h e a d s o c k e t c a p 3 x 6 S e t S c r e w 3 x 3 Page 18 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 20 22.Assembly Process of Main Frames and Power System REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Threadlock used Page 19 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 21: Tail Case Assy
K A - 7 2 - 0 9 5 K A - 7 2 - 0 1 3 K A - 7 2 - 0 9 6 Page 20 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 22 REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. 11.5mm 10.3mm This direction outwards Page 21 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 23: Pre Assembled Tail Blade Grip
25.Pre Assembled Tail Blade Grip REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Threadlock used Page 22 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 24: Torque Tube Bearing Guide Assy
26.Torque Tube Bearing Guide Assy REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 23 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 25: Tail Boom Mount Assy
27.Tail Boom Mount Assy REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 24 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 26 REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. This washer is used for adjusting the tightness of gear Page 25 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 27 29.Tail Control Rod Assy 1 REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 26 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 28 30.Installing The Tail Boom Brace Set REM: Apply Medium Thread lock or Equivalent to all screws, balls, and threads which are engaged with metal-parts. Page 27 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 29: Parts List
1 x Nylon lock nuts M4 4 x Umbrella head screws M2x4mm 2 x Set screws M4X4mm 2 x Set screws M4X4mm Page 30 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 30 2 x Surface bearing Ø10xØ19x5mm 1 x Front universal joint for tail drive shaft 2 x Ball head buckle for tail holder Page 31 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 31 Screws set KA-72-074 KA-72-075 KA-72-076 KA-72-077 Battery straps x2 1 x Washers set 1 x Screws set 10 x Conical washers Page 32 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 32 4 x Set screw M4 x 4 4 x Set screw M4 x 4 4 x Set screw M4 x 4 Page 33 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 33 2 x CF Main blade 2 x CF Tail blade 1 x Brushless motor 4 x Set screw M4 x 4 Page 34 Agile Helicopter is a Trademark of Flight Research Rc Europe , Proudly made by KDS Model Shenzhen...
Page 34: Regular Maintenance
34.REGULAR MAINTENANCE Regular maintenance is required to keep the KDS AGILE 7.2 helicopter in optimal and safe flying condition. The model requires precise configuration of the components and settings to be kept by the owner. Maintain regular maintenance on the model to avoid accidents or loss, and optimum performance.
Page 35 ...it's time to fly different!!! ： Version No 20151026...
