Summary of Contents for Citizen Eco-Drive B872
- Page 1 INSTRUCTION MANUAL Model No.BJ5＊ ・ BJ8＊ Cal.B870・B872 CTZ-B8028②...
- Page 2 ENGLISH FRANÇAIS ESPAÑOL DEUTSCH ITALIANO PORTUGUÊS 中文 （繁体字）...
- Page 3 Please make sure to check the following before use. Please read carefully section entitled "If Your Watch is a Diver's Watch" to ensure proper use of the watch in the case your watch is a diver's watch. If your watch is a diver's watch, the words "AIR DIVER'S 200M" are indicated on the case back (or dial).
-
Page 4: Table Of Contents
Contents Before using ……………………………………………………… 4 Setting the time and date ……………………………………… 6 Functions of solar powered watches ………………………… 8 Insufficient charge warning function ……………………… 10 Quick start function ………………………………………… 10 Time setting warning function …………………………… 11 Overcharge prevention function ………………………… 11 Care and handling during charging …………………………... - Page 5 Contents Charging time by environment …………………………… 14 If your watch is a diver's watch ……………………………… 16 Water resistance ……………………………………………… 24 Precautionary items and usage limitations ……………… 26 Specifications ………………………………………………… 32...
-
Page 6: Before Using
Before using This watch is powered not by an ordinary battery, but by converting photo energy to electrical energy. Before using, expose to light and make sure the watch is sufficiently charged. See "TIME REQUIRED FOR CHARGING" for reference charging times. A rechargeable cell is used in this watch to store electrical energy. - Page 7 Before using There is no risk of overcharging this watch. (Overcharge Prevention Function is provided) We recommend that you recharge the watch everyday.
-
Page 8: Setting The Time And Date
Setting the time and date * If the crown is of the screw- type, set the time and date after first loosening the screw. Retighten the screw after the time and date have been set. Solar cell Date setting Time setting Crown Normal position... -
Page 9: Setting The Time
Setting the time and date ■ Setting the time 1. Stop the second hand at the 0 second position by pulling the crown out to the 2nd click. 2. Turn the crown to set the time. 3. After setting the time, firmly push the crown back in to its normal position. ■... -
Page 10: Functions Of Solar Powered Watches
Functions of solar powered watches If the charge becomes insufficient, a warning function will operate and the display changes as shown below. Normal time Insufficient charge display warning display If insufficiently charged If sufficiently charged One second Two second interval movement interval movement If sufficiently charged and time is set... - Page 11 Functions of solar powered watches If insufficient charge continues Time setting warning display Stop If insufficiently The watch will begin to operate charged and time soon after it is exposed to light due is set to the Quick Start Function Hitch movement...
-
Page 12: Insufficient Charge Warning Function
Functions of solar powered watches ■ Insufficient charge warning function The second hand changes to a two second interval movement to indicate insufficient recharging. Even in such a case, the watch keeps correct time, but about 3 days after the two second interval movement begins, the watch will stop. -
Page 13: Time Setting Warning Function
Functions of solar powered watches ■ Time setting warning function If the watch stops, subsequent exposure to light allows the Quick Start Function to start again, and the second hand moves with a hitch to indicate that the time is incorrect. In this case, quickly recharge the watch and reset the time. -
Page 14: Care And Handling During Charging
Care and handling during charging ■ Notes on use Take care to charge your watch during use. Please note that if you wear long sleeves, the watch can easily become insufficiently charged because it is hidden and not exposed to light. • W hen you take the watch off, place it in as bright a place as possible, and it will always continue to run properly. -
Page 15: Replacing The Rechargeable Cell
Replacing the rechargeable cell Unlike ordinary batteries, the rechargeable cell used in this watch does not have to be periodically replaced due to repeated charging and discharging. CAUTION Never use another battery different from the rechargeable cell used in this watch. The watch structure is designed so that a different kind of battery other than that specified cannot be used to operate it. In case a different kind of battery such as a silver battery is used, there is the risk of it becoming overcharged and bursting, causing damage to the watch and even to the wearer. -
Page 16: Charging Time By Environment
Charging time by environment Below are the approximate times required for charging when exposing the watch dial to light continuously. Please use this table as a reference only. Charging time (approx.) Illuminance To start working To become fully Environment To work for (lx) normally when the charged when the... - Page 17 Charging time by environment * The recharging time is the time when the watch is continuously exposed to light. • To become fullycharged when the cell is discharged The time to fully recharge after the watch has stopped. • To work for one day The time required for the watch to run for one day with one second interval movement...
-
Page 18: If Your Watch Is A Diver's Watch
If your watch is a diver's watch [1] Precautions when Using during Diving: * When using a diver's watch, please make sure that you have received the proper education and training for various types of diving, and observe all rules. * Please make sure to use the watch properly based on a thorough understanding of watch handling and precautions. -
Page 19: During Diving
If your watch is a diver's watch * Please check that the time and date are set correctly. * Please check that the second hand is moving properly. If the second hand is moving at two-second intervals, this means that the watch is not sufficiently charged. - Page 20 If your watch is a diver's watch [2] How to use Rotating bezel The rotating bezel is a convenient way to keep track of diving time, permitting the indication of the elapsed and remaining times. * Turn the rotating bezel counterclockwise, while pushing it. It is locked under normal conditions to prevent free rotation, and cannot be turned in the reverse direction for safety reasons.
- Page 21 If your watch is a diver's watch Elapsed time Remaining time Elapsed time: shows that Remaining time: shows that 10 minutes have passed 20 minutes remain until since 9:10. 9:25. The rotating bezel can be used for various other activities besides diving, for example parking, walking, and keeping track of the remaining time before an important appointment.
- Page 22 If your watch is a diver's watch [3] No decompression limits The range within which the diver can rise to the surface without rest for decompression is determined by the depth and elapsed time of the dive. The ranges are called "No Decompression Limits". A table of "No Decompression Limits"...
- Page 23 If your watch is a diver's watch Example: Read the table as follows. In case the maximum diving depth is 21m(70ft) and the elapsed time is 50 minutes or shorter, the diver is not required to take a rest for decompression while rising to the surface. CAUTION • The table of no decompression limits is provided for one-time diving.
- Page 24 If your watch is a diver's watch [4] When Luminous Paint is used for your watch The paint on the dial and hands helps you with reading the time in a dark place. The luminous paint stores light (daylight or artificial light) and glows in a dark place. It is free from any radioactive substance or any other material harmful to a human body or environment.
- Page 25 [5] Maintaining Water Resistance Please have your watch inspected either through your dealer or directly by a Citizen Service Center every 1 to 2 years to maintain water resistance. Please have the packing, glass, crown or other components replaced as necessary.
-
Page 26: Water Resistance
Water resistance WARNING Water Resistance • Refer to the watch dial and the case back for the indication of the water resistance of your watch. The following chart provides examples of use for reference to ensure that your watch is used properly. (The unit “1bar” is roughly equal to 1 atmosphere.) • WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar. • Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for occasional accidental splashing. Indication Specifications Minor exposure to water Dial Case (Case back) (washing face, rain, etc.) - Page 27 Water resistance • Upgraded water resistance for daily use (to 5 atmospheres) means that the watch may be worn while swimming, but is not to worn while skin diving. • Upgraded water resistance for daily use (to 10/20 atmospheres) means that the watch may be worn while skin diving, but not while scuba or saturated diving using helium gas. Examples of use Moderate exposure to water (washing, Saturation diving Operation of kitchen work, Marine sports Scuba diving...
-
Page 28: Precautionary Items And Usage Limitations
Precautionary items and usage limitations CAUTION To Avoid Injury • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and others. • Do NOT wear your watch while in a sauna or other location where your watch may become excessively hot, since there is the risk of burns. • Be careful when putting on and taking off your watch, since there is a risk of damaging your fingernails, depending on the manner in which the band is fastened. • Take off your watch before going to bed. CAUTION Precautions • Always use the watch with the crown pushed in (normal position). If the crown is of the screw... - Page 29 Precautionary items and usage limitations • Even if your watch has a high level of water resistance, please be careful of the following. • If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a dry cloth. • Do not pour water from a tap directly onto your watch. • Take off your watch before taking a bath. • If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in for repair. Otherwise, pressure inside the watch will increase, and parts (crystal, crown, push button, etc.) may come off. CAUTION When Wearing Your Watch <Band>...
- Page 30 For band adjustment, we recommend you consult the retailer from where the watch was purchased or your nearest Authorized Citizen Service Center. Some repair shops may charge a nominal fee for adjustment if the watch was not purchased directly from them. <Temperature> • The watch may stop or the function of the watch may be impaired in extremely high or low temperature.
-
Page 31: Static Electricity
Precautionary items and usage limitations <Magnetism> • Analog quartz watches are powered by a step motor that uses a magnet. Subjecting the watch to strong magnetism from the outside can cause the motor to operate improperly and prevent the watch from keeping time accurately. Do not allow the watch to come into close proximity to magnetic health devices (magnetic necklaces, magnetic elastic bands, etc.) or the magnets used in the latches of refrigerator doors, clasps used in handbags, the speaker of a cell phone, electromagnetic cooking devices and so on. - Page 32 Precautionary items and usage limitations <Protective Stickers> • Be sure to remove any protective stickers that may be on your watch (case back, band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between the protective stickers and the parts, which may result in a skin rash and/or corrosion of the metal parts. CAUTION Always Keep Your Watch Clean • Rotate the crown while it is pressed in fully and press the buttons periodically so they do not become stuck due to accumulations of foreign matter.
-
Page 33: Caring For Your Watch
Precautionary items and usage limitations Caring for Your Watch • Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth. • For a metallic, plastic or rubber (urethane) watchband, wash any dirt off with water. Remove the small amounts of dirt trapped between the crevices of the metallic band with a soft brush. • For a leather band, wipe off dirt using a dry cloth. • If you will not be using your watch for an extended period of time, carefully wipe off any perspiration, dirt or moisture and store in a proper location, avoiding locations subject to excessively high or low temperatures and high humidity. <When Luminous Paint is used for your watch>... -
Page 34: Specifications
Specifications Model B870・B872 Type Analog Quartz Watch with 3 Hands Accuracy Within ±15sec/month (within a normal temperature range of 5°C/41°F to 35°C/95°F) Quartz 32,768Hz oscillator frequency: C/MOS-LSI (1 pc.) Operational -10°C/14°F to +60°C/140°F temperature range Display Time: hour, minute, second features Date: date (models with date display) - Page 35 Specifications Additional Insufficient charge warning features Quick start Time setting warning Overcharge prevention Continuous Approx. 6 months (from full recharge to stop) operating time Approx. 3 days (from two second interval movement to stop) Battery Rechargeable cell (lithium button cell), 1pc. * Specifications are subject to change without prior notice.
- Page 36 Model No.BJ5＊ ・ BJ8＊ Cal.B870・B872 CTZ-B8028②...
