Sharp UP-5300 Service Manual

Pos terminal
Hide thumbs Also See for UP-5300:
Table of Contents

Advertisement

Quick Links

Download this manual
CHAPTER 1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
CHAPTER 2. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
CHAPTER 3. SERVICE PRECAUTION . . . . . . . . . . . . . . . . . . . . . 3-1
CHAPTER 4. UP-5300 DIAGNOSTICS SPECIFICATIONS . . . . . . 4-1
CHAPTER 5. CIRCUIT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . 5-1
CHAPTER 6. BIOS SETUP UTILITY . . . . . . . . . . . . . . . . . . . . . . . . 6-1
CHAPTER 8. CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
CHAPTER 9. PWB LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Parts marked with "!" is important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
CONTENTS
CODE: 00ZUP5300USME
POS TERMINAL
UP-5300
MODEL
("U" & "A" version)
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
