MINIMUM SYSTEM REQUIREMENTS

Hardware: CD ROM drive
Operating system: MS Windows 98SE, ME,NT, NT4.0, 2000, XP.
LAN port: 10 Base-T Ethernet or 100 Base-TX Fast Ethernet
WLAN port: 802.11b/g router/access point (and Ethernet connection for installation)
For camera setup and Web Browser Users:
Processor: Pentium 2 or above
Memory: 64 MB RAM, 5MB free disk space
Web browser: Supporting ActiveX or Java
For installation and IP View Pro Application Users:
Processor: Pentium 3 or above
Memory: 128 MB RAM, 500 / 1000MB free disk space .
Web browser: Supporting ActiveX or Java

PACKAGE CONTENTS

• One Pan/Tilt Internet Camera
• One AC Power Adapter
• One RJ-45 Ethernet Cable
• One externe antenna
• One Metal Clip
• This Quick Installation Guide
• One Installation CD-ROM
Note: If any item contained is damaged or missing, please contact your local dealer immediately.
This is the quick installation guide describing how to connect the IP Robocam. For an extensive description of all
the possibilities of the camera, consult the user manual, which can be found on the CD ROM provided.
HARDWARE INSTALLATION: ATTACHING THE METAL CLIP
To attach the metal clip, remove the two rubber pads under the
base of the camera firstly. Place the metal clip
onto the camera base, and align the two holes of metal clip
with two screw holes on the base. Secure the
metal clip to the base with two screws (provided). Then, you
can: install the camera to the ceiling using two
ceiling screws (1); or, install the camera to the wall using
two wall screws (2).

CONNECTING THE ETHERNET CABLE

Connect an Ethernet cable to the network cable connector
located on the camera's rear panel, and then attach it to
the network.
