6. SPECIFICATIONS

This section provides technical information about the MultiSync MT840/MT1040/MT1045 Projector's performance.
Model Number MT840 / MT840G / MT1040 / MT1040G/ MT1045 / MT1045G
Optical
LCD Panel 1.3" p-Si TFT active-matrix, 800 600 dots (MT840) / 1024 768 dots (MT1040/MT1045)
1.3" p-Si TFT active-matrix with Micro Lens Array (MT1045)
Lens Manual zoom, manual focus
MT840/MT1040 : F2.3 – 2.7
MT1045 : F1.8 – 2.2
Lamp MT840/MT1040 : 180W NSH lamp / MT1045 : 200W NSH lamp
Image Size 30 – 300 inches (762 – 7620 mm) diagonal
Projection Distance MT840/MT1040 : 4.3 – 36.7 ft (1.3 - 11.2 m)
MT1045 : 4.3 – 37.1 ft (1.3 - 11.3 m)
Electrical
Inputs Video (NTSC / PAL / PAL60 / SECAM / NTSC4.43)
Horizontal Frequency : 15 – 85 kHz (RGB : 24 kHz or over)
Vertical Frequency : 50 – 85 Hz
Video Bandwidth RGB: 80 MHz
Color Reproduction Full color, 16.7 million colors simultaneously.
Horizontal Resolution 550 TV lines : NTSC / PAL / NTSC4.43 / YCbCr
350 TV lines : SECAM
RGB
Power Requirement 100 – 120 / 200 – 240 VAC, 50 / 60 Hz
Input Current 3.5 A (100 – 120 VAC) / 1.7A (200 – 240 VAC)
Mechanical
Dimensions MT840/MT1040 : 11.1" (W) 4.8" (H) 14.3" (D) / 281mm (W) 121mm (H) 364mm (D) (not including lens and feet)
MT1045 : 11.1" (W) 4.8" (H) 14.9" (D) / 281mm (W) 121mm (H) 376mm (D) (not including lens and feet)
Net Weight MT840/MT1040 : 12.4 lbs / 5.6 kg
MT1045 : 12.8 lbs / 5.8 kg
Environmental Considerations Operational Temperatures: 32˚ – 104˚F (0˚ to 40˚C), 20 – 80% humidity
Storage Temperatures:
Regulations UL Approved (UL 1950, CSA 950)
Meets DOC Canada requirements
Meets FCC Class A requirements
Meets AS/NZS3548
Meets EMC Directive (EN55022, EN55082-1, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950, TUV GS Approved)
The specifications are subject to change without notice.
f=48.6 – 58.4 mm
f=49.3 – 59.3 mm
MT840 : 800 dots horizontal, 600 dots vertical
MT1040/MT1045 : 1024 dots horizontal, 768 dots vertical
14˚ – 140˚F (-10˚ to 60˚C), 30 – 85% humidity
E–37
