  • Page 1 COOKER HOOD GDK 5782 B...
  • Page 3 Please read this user manual first! Dear Customer, Thank you for purchasing this Grundig product. We hope that you get the best results form your product which has been manufactured with high quality and starte-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS ______________________________ 1 Warnings 2 Technical specification General appearance ....8 3 Installation 9-13 Electrical connection ....9 Assembly .
  • Page 5 ________________________________________________________...
  • Page 6 WARNINGS _________________________________________ Please review the following Do not operate the hood with- information. Failure to com- out aluminum filters and do ply with these instructions may not remove the filters while it cause risk of personal injury or is operated. material damage.
  • Page 7: Warnings

    WARNINGS _________________________________________ Do not allow high flames under Do not make connections the hood. Otherwise, oil in the to the flues connected with aluminum filter may ignite and stoves, exhaust shafts or flues lead to a fire. with rising flames. Observe Do not keep easily flammable the rules set by authorities on materials under your hood.
  • Page 8: Technical Specification

    TECHNICAL SPECIFICATIONS _____________________ General appearance Hood body Lighting Control panel Flue connection element GDK 5782 B Width 898 mm Depth 380 mm Height Min. 1055 - Max. 1330 mm Supply voltage 220-240 V ~ 50 Hz Control 4 positions Suction power...
  • Page 9: Installation

    INSTALLATION _____________________________________ Note: Remove the grease filters making sure that Preparation of the installation place and the connector of the supply cable is cor- electric wiring is the responsibility of the rectly inserted in the socket placed on the customer. side of the fan (Refer to Maintenance sec- tion).
  • Page 10: Assembly

    INSTALLATION _____________________________________ Assembly Quantity Product materials Accessories and installation material Hood Body and parts: Controls, light, blower, filters Telescopic chimney comprising of: Upper section Lower section Air outlet grill Reducer flange 150- 120 mm Damper 150 Air outlet connection 14.1 extension Air outlet connection Installation...
  • Page 11: Mounting The Hood Body

    INSTALLATION _____________________________________ Wall drilling and bracket fixing (7.2.1) Fix the upper bracket and the air outlet connection support (7.3), together using the 2 (4.2 x 44.4) screws sup- plied. Insert the two (4.2 x 44.4) screws sup- plied in the hood body fixing holes, leaving a gap of 5-6 mm between the wall and the head of the screw.
  • Page 12 INSTALLATION _____________________________________ Air outlet in ducted version Fix the pipe in position using suitable pipe clamps (not supplied). When installing the ducted version, connect the hood to the chimney using either a flexible Fix the grille which can be installed only or rigid pipe with a diameter 150 or 120mm in one direction on the recirculation air out- (the choice of which is left to the installer).
  • Page 13: Flue Assembly

    INSTALLATION _____________________________________ Flue assembly Transportation Disconnect the appliance from mains supply and remove the hood first if you need it to be transported. Transport the appliance with its original package if possible, and observe the transport markings on the original package. If the original package is not available, pack the appliance so that it will not be damaged.
  • Page 14: Operating Your Appliance

    OPERATING YOUR APPLIANCE __________________ Use the high suction speed in cases of con- in operation during cooking and for another centrated kitchen vapors. It is recommended 15 minutes approximately after terminating that the cooker hood suction is switched on cooking. for 5 minutes prior to cooking and to leave Touch control This function is suitable for a complete...
  • Page 15: Maintenance And Cleaning

    MAINTENANCE AND CLEANING _________________ Before all maintenance and cleaning opera- Alarm reset: tions, remove the plug of the appliance or turn Press the “G” key for at least 2 seconds. off or remove the fuse! Cleaning the filters Service your hood periodically! Pull the comfort panels to open them.
  • Page 16: Cleaning The Hood

    MAINTENANCE AND CLEANING _________________ Within 3 seconds press the “D” key to Outer surfaces of the hood must be cleaned with a mild cleaning agent (e.g. dish soap). activate/deactivate carbon filter saturation Do not use strong cleaning agents, abrasive alarm. agents or sharp objects.
  • Page 17: Troubleshooting Suggestions

    TROUBLESHOOTING SUGGESTIONS ____________ Problem Explanation / Suggestion Turn off the hood with keys and cut off electricity supply for a Hood operates incorrectly few seconds by removing the plug or closing the fuse. ∑ Is the plug connected to mains outlet? Hood does not operate ∑ Is the fuse in the household installation burnt off? ∑ Did you press the fan keys?
  • Page 18: Guarantee

    GUARANTEE _______________________________ Guarantee for Refrigeration, Cooking Appliance, Washing Machines & Dishwashers Your new Grundig product is guarenteed against the cost of breakdown repairs for 5 years from the daie of the orginals purchase. “Please visit the “support” section on the Grundig website at www.grundig.co.uk to register your 5 year warranty.
  • Page 19: Service

    If you have purchased an exlended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be oblained at a charge. Grundig, 1 Greenhill Crescent, Watford Herts WD18 8QU...
  • Page 20 FOR A GOOD REASON...
