2X5 Crossover - dbx DriveRack User Manual

DriveRack
Hardware
1.
2. Connect the outputs of the DriveRack™ PA and run to the selected speaker amplifier.
3. Make sure that the mixer and power amps are turned off prior to powering up the
Software
1. From Program mode, select factory program #F2 (3 Way w/mSub) as a template, or use the
2. Once the program has been chosen, press the DATA wheel to load the program.
Mono Low
®
™
PA
Connect the outputs from the mixer to the inputs of the DriveRack™.
DriveRack™ PA.
Wizard to setup the specific program.
Left
Left Mid
Left Mid
Application Guide
Right
Right Mid
Left High
SR4731XF
SR4719X
DriveRack™ PA User Manual
Section 5

5.2- 2X5 Crossover

Left High
Right High
Right Mid
Right High
SR4731XF
Mono Sub
31
