Page 1: Quick Installation Guide
Quick Installation Guide TL-PS210U Single USB2.0 Port MFP Print Server Rev:1.0.2 7106500730... -
Page 2: Hardware Installation
A Packing List: One MFP server One external AC power adapter One Setup CD includes user manual for Windows 2000/XP/Vista One quick installation guide (this one) B Wired Network with MFP Server: MFP Server MFP Printer Computer Computer Computer C Hardware Installation: Connect one end of the UTP cable to the Ethernet port on MFP Server and the other end to a wall jack or HUB. - Page 3 Installation Guide. Insert the setup CD into your CD-drive. The auto-run program will be started. Click the TL-PS210U to begin the setup. Choose Installation to install all software programs. Click OK.
- Page 4 Click Next. Click Next.
- Page 5 Click Next. Click Finish. 10 Select No, not this time, and then click Next.
- Page 6 11 Select Install the software automatically (Recommended), and then click Next. 12 Click Continue Anyway.
- Page 7 13 Click Finish to complete the software installation. 14 Then, start to setup MFP server. Click start -> All Programs -> Remote Virtual USB folder; click Remote Virtual USB to launch the MFP server utility. 15 If you have Windows XP and the Windows Firewall is enabled you will see this window pop-up message when the MFP server utility is first launched.
- Page 8 software is allowed to bypass such programs. 16 The MFP server utility will search your network for the MFP server and display it in the window. If no MFP server is found, please make sure any third party firewalls have been disabled or bypassed and click the Search button to try again.
- Page 9 Note: The default IP address of MFP server is 192.168.0.10, and subnet mask is 255.255.255.0. If the MFP server utility didn’t find MFP server, please make sure of the MFP server and your computer’s IP segment are the same, e.g. 192.168.0.xxx.
- Page 10 20 Click OK to confirm that the printer is in your favorites list. 21 Once you have connected to the MFP server you can close the MFP server utility. Be sure to use the close box with an X in the top right corner so that the MFP server utility continues to run in the background.
- Page 11 23 Congratulation! Your MFP printer is now ready to share. Note: If you wish to setup more MFP servers, start MFP server utility from your Windows Start menu: start -> All Programs -> Remote Virtual USB -> Remote Virtual USB and repeat the setup procedure. Appendix Configuring the PCs In this section, we’ll introduce how to configure the TCP/IP correctly in Windows 2000/XP and Vista.
- Page 12 In the prompt page showed below, double click on the Internet Protocol (TCP/IP). The following TCP/IP Properties window will display. Select Use the following IP address radio button. And the following items are available. Type IP address is 192.168.0.x (x is from 2 to 254), Subnet mask is 255.255.255.0 and Default gateway is 192.168.0.1.Then click OK.
- Page 13 For Windows Vista Users On the Windows taskbar, click the Start, then select Control Panel; Select Classic View on the left side then double-click Networking and Sharing center;...
- Page 14 Click Manage network connections on the left side. Right click the icon that showed below, select Properties on the prompt page.
- Page 15 In the prompt page showed below, double click on the Internet Protocol Version 4(TCP/IPv4). The following TCP/IPv4 Properties window will display. Select Use the following IP address radio button. And the following items are available. Type IP address is 192.168.0.x (x is from 2 to 254), Subnet mask is 255.255.255.0 and Default gateway is 192.168.0.1.Then click OK.
- Page 16 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
