JVC PD-50X575 Service Manual

Pdp color tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
2
2005
YA238
RM-C1257G
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-29
PDP COLOR TELEVISION
PD-50X575
VM-50X575/K [PLASMA DISPLAY UNIT]
TU-50X575/K [RECEIVER UNIT]

TABLE OF CONTENTS

COPYRIGHT © 2005 Victor Company of Japan, Limited
/K
BASIC CHASSIS
FP2
No.YA238
2005/3

Advertisement

Table of Contents
loading

Related Manuals for JVC PD-50X575

Summary of Contents for JVC PD-50X575

  • Page 1: Table Of Contents

    SERVICE MANUAL PDP COLOR TELEVISION YA238 2005 PD-50X575 BASIC CHASSIS VM-50X575/K [PLASMA DISPLAY UNIT] RM-C1257G TU-50X575/K [RECEIVER UNIT] TABLE OF CONTENTS PRECAUTION............... . . 1-3 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION Items Contents Dimensions ( W × H × D ) Plasma display unit 135cm × 83.6cm × 11cm Receiver unit 43.5cm × 7cm × 31.9cm Mass Plasma display unit 51.0kg Receiver unit 3.6kg TV RF System CCIR (M) Color System NTSC Sound System A2 (KOREA)

  • Page 3: Precaution

    SECTION 1 PRECAUTION SAFETY PRECAUTIONS (1) The design of this product contains special hardware, dress in the high voltage circuit area. Where a short circuit many circuits and components specially for safety has occurred, those components that indicate evidence of purposes.
  • Page 4 INSTALLATION 1.2.1 HEAT DISSIPATION If the heat dissipation vent behind this unit is blocked, cooling efficiency may deteriorate and temperature inside the unit will rise. The temperature sensor that protects the unit will be activated when internal temperature exceeds the pre-determined level and power will be turned off automatically.
  • Page 5 PRECAUTIONS REGARDING PDP 1.3.1 PRECAUTIONS DURING NOTES FOR TRANSPORTATION 1.3.4 OPTICAL FILTER (PANEL FILTER) When transporting the unit, pressure exerted on the internal PDP Avoid placing the unit under direct sunlight over a prolonged (Plasma Display Panel) due to improper handling (such as period of time.

  • Page 6: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS FEATURES D.I.S.T. (Digital Image Scaling Technology) V-CHIP This system uses line interpolation to double the number of Since the V-CHIP is built in, it can choose, view and listen to a scanning lines and achieve high resolution, flicker-free picture. healthy program.
  • Page 7 TECHNICAL INFORMATION 2.3.1 PDP STRUCTURE AND CHARACTERISTIC This unit uses the flat type panel PDP (Plasma Display Panel), instead of the conventional CRT (Cathode Ray Tube), as a display unit. 2.3.1.1 PIXEL (CELL) ARRAY PDP is constructed by sealing the xenon, which emits neon and ultraviolet rays for discharging purpose, in between the electrodes lay on the front glass substrate and rear glass substrate.
  • Page 8 2.3.2 MAIN CPU PIN FUNCTION [IC7601 : DIGITAL SIGNAL PWB ASS'Y / RECEIVER UNIT] Pin name Function Pin name Function VHOLD1 Data slice for main screen closed caption Not used HFLT1 I/O LPF for main screen closed caption video input Not used Not used Not used...
  • Page 9 2.3.3 SUB (CHASSIS) CPU PIN FUNCTION [IC7001 : DIGITAL SIGNAL PWB ASS'Y / RECEIVER UNIT] Pin name Function Pin name Function LB_PRO Not used BS_TXD Not used : Data transmission for digital tuner communication P_MU Picture muting [Muting = H] BS_RXD Not used : Data receive for digital tuner communication JP_CSB...

  • Page 10: Disassembly

    SECTION 3 DISASSEMBLY DISASSEMBLY PROCEDURE (DISPLAY UNIT) NOTE: • When exchanging parts etc. with the front side (PDP side) fancing down, place a protection sheet under the DISPALY UNIT to prevent scratches on the front side. • It is advisable to take notes of the connecting locations (connector numbers) of the removed connectors. 3.1.1 REMOVING THE REAR COVER (Fig.1) 3.1.6 REMOVING THE DISPLAY INTERFACE PWB (Fig.1) (1) Remove the power cord and the system cable.
  • Page 11 BACK COVER REAR COVER DISPLAY INTERFACE PWB LINE FILTER INSULATOR AUDIO PWB BACK COVER LINE FILTER CHASSIS SHIELD BLACKET TERMINAL COVER CHASSIS BASE SPEAKER HOLDER SPEAKER HOLDER Fig.1 (No.YA238)1-11...
  • Page 12 3.1.8 REMOVING THE TEMP. SENSOR PWB (Fig.2) 3.1.14 REMOVING THE DISPLAY LED PWB (Fig.2) • Remove the REAR COVER. • Remove the BACK COVER. (1) Disconnect the connector [CN800V] from the TEMP. • Remove the SPEAKER HOLDER. SENSOR PWB PWB . •...
  • Page 13 MAIN POWER UNIT FAN BLACKET COOLING FAN SUB POWER PWB POWER CHASSIS PWB TEMP. SENSOR PWB BACK BLACKET PDP (PANEL) UNIT GAS insertion hole DISPLAY LED PWB DD SPEAKER DD SPEAKER DISPLAY SWITCH PWB WOOFER BACK COVER CONTROL KNOB WOOFER SPEAKER WOOFER SPEAKER...
  • Page 14 3.1.18 REMOVING THE PWB IN PDP UNIT 3.1.18.1 REMOVING THE X LEFT TOP PWB (Fig.3) 3.1.18.7 REMOVING THE Y DRIVE UPPER PWB (Fig.3) • Remove the PDP UNIT. • Remove the PDP UNIT. (1) Disconnect the connector [P4] / [P5] / [P501] / [P502] / (1) Disconnect the connectors [P2] / [P10] from the Y-SUB PWB .
  • Page 15 3.1.19 REMOVING THE FRONT FILTER (Fig.4) 3.1.20 REMOVING THE TOP FRAME BRACKET, BOTTOM • Remove the REAR COVER. FRAME BRACKET AND SIDE FRAME BRACKET (Fig.4) • Remove the CHASSIS SHIELD BRACKET. • Remove the REAR COVER. • Remove the TERMINAL COVER. •...
  • Page 16 DISASSEMBLY PROCEDURE (RECEIVER UNIT) CAUTION AT DISASSEMBLY: • Be sure to perform the SYSTEM SETTING on the page 1-6, at the end of the procedure. • Make sure that the power cord is disconnected from the outlet. • Pay special attention not to break or damage the parts. •...
  • Page 17 TOP COVER DIGITAL HOLDER RECEIVER PWB DIGITAL SIGNAL PWB SYSTEM POWER PWB ANALOG SIGNAL REGULATOR PWB FRONT PANEL REAR JACK PWB FRONT CONTROL PWB REAR COVER Fig.9 (No.YA238)1-17...
  • Page 18 MEMORY IC REPLACEMENT • This model uses the memory IC. • This memory IC stores data for proper operation of the video and drive circuits. • When replacing, be sure to use an IC containing this (initial value) data. 3.3.1 MEMORY IC REPLACEMENT PROCEDURE 1.
  • Page 19 3.3.3 SETTINGS OF FACTORY SHIPMENT 3.3.3.1 BUTTON OPERATION 3.3.3.2 REMOTE CONTROL DIRECT OPERATION Setting item Setting position Setting item Setting position INPUT POWER CHANNEL CABLE-02 CHANNEL CABLE-02 VOLUME VOLUME MUTING INPUT DISPLAY ASPECT NTSC PANORAMA HD FULL SLEEP TIMER THEATER PRO VIDEO STATUS DYNAMIC TWIN...
  • Page 20 REPLACEMENT OF CHIP COMPONENT 3.4.1 CAUTIONS (1) Avoid heating for more than 3 seconds. (2) Do not rub the electrodes and the resist parts of the pattern. (3) When removing a chip part, melt the solder adequately. (4) Do not reuse a chip part after removing it. 3.4.2 SOLDERING IRON (1) Use a high insulation soldering iron with a thin pointed end of it.

  • Page 21: Adjustment

    SECTION 4 ADJUSTMENT ADJUSTMENT PREPARATION ADJUSTMENT ITEMS (1) There are 2 ways of adjusting this TV : One is with the POWER CIRCUIT REMOTE CONTROL UNIT and the other is the • PDP POWER VOLTAGE adjustment conventional method using adjustment parts and VIDEO CIRCUIT components.
  • Page 22 4.5.3 DESCRIPTION OF STATUS DISPLAY (6) SETTING ITEM NO. Setting item numbers are displayed. For the setting item SETTINGITEM No. SETTING ITEM SETTING VALUE (DATA) WHITE BALANCE names to be displayed, refer to "Initial setting value of adjustment mode". S001 PREPARE S001 PREPARE NTSC3 NTSC3...
  • Page 23 INITIAL SETTING VALUES IN THE SERVICE MODE • Perform fine-tuning based on the "initial values" using the remote control when in the Service mode. • The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved may be different from the default values.
  • Page 24 Item No. Item Variable range Setting value Item No. Item Variable range Setting value D020 SYH CON 00 - 3F D070 (Not display) 00 - FF D021 SYH CONF 00 - 01 D071 (Not display) 00 - FF D022 SC CON 00 - 3F D072 (Not display)
  • Page 25 Item No. Item Variable range Setting value Item No. Item Variable range Setting value D120 (Not display) 00 - FF D170 (Not display) 00 - FF D121 (Not display) 00 - FF D171 (Not display) 00 - FF D122 (Not display) 00 - FF D172 (Not display)
  • Page 26 ADJUSTMENT PROCEDURE 4.7.1 POWER CIRCUIT [DISPLAY UNIT] Measuring Item Test point Adjustment part Description instrument PDP POWER Signal Connector Vs VR:190V ADJ (R551) CAUTION: VOLTAGE generator CN806 Va VR:60V ADJ (R351) • During adjustment operation of PDP POWER [MAIN POWER UNIT] VOLTAGE, don't touch the heat sink of the MAIN DC voltmeter POWER UNIT.
  • Page 27 4.7.2 VIDEO CIRCUIT Measuring Item Test point Adjustment part Description instrument 525i Remote [1.ADJUST] (1) Receive a 525i component ramp pattern signal. A-D OFFSET control unit S001: PREPARE (2) Set "VIDEO STATUS" to STANDARD. (Adjustment setting mode change) (3) Set "ASPECT" to FULL. Signal (4) St "COLOR TEMPERATURE"...
  • Page 28 Measuring Item Test point Adjustment part Description instrument SUB SCREEN Remote [1.ADJUST] (1) Set “VIDEO STATUS” to STANDARD. A-D OFFSET control unit S001: PREPARE (2) Set “ASPECT” to FULL. (Adjustment setting mode change) (3) Set "COLOR TEMPERATURE" to LOW. Signal (4) Set "MULTI SCREEN"...

  • Page 29: Troubleshooting

    SECTION 5 TROUBLESHOOTING SELF CHECK FEATURE 5.1.5 POINTS TO NOTE WHEN USING THE SELF CHECK FEATURE 5.1.1 OUTLINE In addition to circuit failures (abnormal operation), the following This unit comes with the "Self check" feature, which checks the cases may also be iagnosed as "Abnormal" and displayed and operational state of the circuit and displays/saves it during counted as "NG".
  • Page 30 5.1.6 DETAILS Self check is performed for the following items: < Page 1 of screen (RECEIVER UNIT) > Diagnosis Detection item Display Detection content Detection timing signal (line) Low bias line short Confirm the operation of the low bais LB_PRO Detection starts 3 seconds after protection (2.5V / 3.3V / 5V / 9V) protection circuit.
  • Page 31 < Page 2 of screen (DISPLAY UNIT) > Diagnosis Detection item Display Detection content Detection timing signal (line) Fan lock Confirm the operation of the cooling fan. FAN_LOCK Detection starts 8 seconds after IC807 [DISPLAY INTERFACE PWB] the power is turned on. Detection is performed every 16ms.
  • Page 32 1-32 (No.YA238)
  • Page 33 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY VIDEO DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan (No.YA238) Printed in Japan...

  • Page 84: Parts List

    PARTS LIST CAUTION The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the  safety. The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied. P.
  • Page 85 CONTENTS [DISPLAY UNIT : VM-50X575/K] USING P.W. BOARD & REMOTE CONTROL UNIT ..................3 EXPLODED VIEW PARTS LIST -1 ....................... 3 EXPLODED VIEW -1 ............................. 4 EXPLODED VIEW PARTS LIST -2 ....................... 5 EXPLODED VIEW -2 ............................. 6 EXPLODED VIEW PARTS LIST -3 ....................... 7 EXPLODED VIEW -3 .............................

  • Page 86: [Display Unit : Vm-50X575/K] Using P.w. Board & Remote Control Unit

    [DISPLAY UNIT : VM-50X575/K] USING P.W. BOARD & REMOTE CONTROL UNIT P.W.B ASS'Y name P.W.B ASS'Y No. AUDIO PWB LCA90441-02B (SFP-6501A) DISPLAY INTERFACE PWB LCA10360-08D (SFP-7508A) TEMP SENSOR PWB LCA90146-06B (SFP-8381A) SUB POWER PWB LCA10353-02D (SFP-9505A) LINE FILTER PWB LCA90143-12B (SFP-9521A) DISPLAY LED PWB LCA90175-06B (SFP-0L285A) DISPLAY SWICH PWB...

  • Page 87: Exploded View -1

    EXPLODED VIEW -1 TERMINAL COVER CHASSIS SHIELD BLACKET CHASSIS BASE 3-4(No.YA238)

  • Page 88: Exploded View Parts List -2

    EXPLODED VIEW PARTS LIST -2  Ref.No. Part No. Part Name Description Local QAL0557-004 MAIN POWER UNIT  QAR0315-001 COOLING FAN (x2)   QQR0491-001 FERRITE CORE LC41683-002A DD SPEAKER ASSY (x2) LC40226-003A-H SPACER (x4) LC21378-001C CONTROL KNOB QYSBSFG4035MA TAP SCREW M4 x 35mm(x8) LC21377-002B DUCT COVER R...

  • Page 89: Exploded View -2

    EXPLODED VIEW -2 FAN BRACKET POWER CHASSIS PWB BACK BRACKET GAS insertion hole 3-6(No.YA238)

  • Page 90: Exploded View Parts List -3

    EXPLODED VIEW PARTS LIST -3  Ref.No. Part No. Part Name Description Local LC32466-001A SPACER (x2) LC32466-002A SPACER (x2)  LC32655-001A FRONT FILTER LC11712-002A FRONT PANEL  EXPLODED VIEW -3 SIDE FLAME TOP FLAME FILTER BRACKET BOTTOM FLAME SIDE FLAME FILTER BRACKET (No.YA238)3-7...

  • Page 91: Printed Wiring Board Parts List

    PRINTED WIRING BOARD PARTS LIST AUDIO PW BOARD ASS’Y Ref No. Part No. Part Name Description Local (LCA90441-02B) (SFP-6501A) C6546 NCB31HK-103X C CAPACITOR 0.01uF 50V K Ref No. Part No. Part Name Description Local C6551 QETN1HM-105Z E CAPACITOR 1uF 50V M C6552 QETN1HM-105Z E CAPACITOR...

  • Page 92: Display Interface Pw Board Ass'y (Lca10360-08D) (Sfp-7508A)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R6527 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6645 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R6528 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6646 NRSA63J-563X MG RESISTOR 56kΩ...
  • Page 93 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C410 NCB31CK-104X C CAPACITOR 0.1uF 16V K R526 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C412 NCB31CK-104X C CAPACITOR 0.1uF 16V K R528 NRSA63J-0R0X MG RESISTOR 0Ω...

  • Page 94: Temp Sensor Pw Board Ass'y (Lca90146-06B) (Sfp-8381A)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R863 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J RA610 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J x4 R866 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RA611 NRZ0040-0R0X NET RESISTOR 0Ω...

  • Page 95: Line Filter Pw Board Ass'y (Lca90143-12B) (Sfp-9521A)

    Ref No. Part No. Part Name Description Local R9057 QRA14CF-2001Y CMF RESISTOR 2kΩ 1/4W F R9058 QRE141J-273Y C RESISTOR 27kΩ 1/4W J R9059 QRE141J-102Y C RESISTOR 1kΩ 1/4W J T9001 QQS0247-001 SW TRANSF QMFZ043-5R0Z-J1 FUSE 5A AC250V CP9001 CP9051 ICP-N50-Y IC PROTECTOR 2.0A PS2581AL1/QW/...

  • Page 96: Remote Control Unit Parts List [Rm-C1257G-1H]

    REMOTE CONTROL UNIT PARTS LIST [RM-C1257G-1H]  Ref No. Part No. Part Name Description Local UR77EC0603 BATTERY COVER PACKING PARTS LIST  Ref.No. Part No. Part Name Description Local LC21464-004A PACKING CASE LC21463-001B PACKING CASE BOTTOM LC11751-001B CUSHION 6pcs in 1 set LC41035-004A POLY BAG LC41035-006A...

  • Page 97: Packing

    PACKING 19 20 14 15 16 17 FRONT 3-14(No.YA238)

  • Page 98: [Receiver Unit : Tu-50X575/K] Using P.w. Board

    FRONT PANEL ASSY Inc.101-103 QZW0063-001 MAGNET LATCH (x2) LC32512-002A CONTROL PLATE QZW0055-004 DAMPER LC21443-006A DOOR ASSY Inc.201 PQ45130-6 JVC MARK  300 LCA10523-03B RECEIVER PWB  301 LCA10428-37H DIGITAL SIGNAL PWB  302 LCA10466-05B FRONT CONTROL PWB  303 LCA10426-12C REGULATOR PWB ...

  • Page 99: Exploded View

    EXPLODED VIEW DIGITAL HOLDER 3-16(No.YA238)

  • Page 100: Printed Wiring Board Parts List

    PRINTED WIRING BOARD PARTS LIST FRONT CONTROL PW BOARD ASS’Y Ref No. Part No. Part Name Description Local (LCA10466-05B) (SFP-8510A) D2SBA60 BRIDGE DIODE D9004 Ref No. Part No. Part Name Description Local D9007 RGP10J-5025-T3 SI DIODE D9008 D1FL20U-X SI DIODE D9010 SARS01-T2 SI DIODE...

  • Page 101: Regulator Pw Board Ass'y (Lca10426-12C) (Sfp-9520A)

    ANALOG SIGNAL PW BOARD ASS’Y Ref No. Part No. Part Name Description Local (LCA10423-09C) (SFP-0A504A) CP9001 QMFZ043-5R0Z-J1 FUSE 5A AC250V Ref No. Part No. Part Name Description Local CP9002 ICP-N50-Y IC PROTECTOR 2.0A CP9005 ICP-N50-Y IC PROTECTOR 2.0A F9001 QMF51D2-2R5-J1 FUSE 2.5A AC250V IC201...
  • Page 102 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C506 NDC31HJ-270X C CAPACITOR 27pF 50V J C916 NEX50JM-156X E CAPACITOR 15uF 6.3V M C601 NENA1HM-474X BP E CAPACITOR 0.47uF 50V M CB613 NEHL1CM-106X E CAPACITOR 10uF 16V M C602...

  • Page 103: Digital Signal Pw Board Ass'y (Lca10428-37H) (Sfp-0D507A)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R608 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB516 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R612 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB617 NRSA63J-563X MG RESISTOR 56kΩ...
  • Page 104 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local Q0202 2SA1022/BC/-X TRANSISTOR C0209 NCB11AK-106X C CAPACITOR 10uF 10V K Q0203 2SC3928A/QR/-X TRANSISTOR C0210 NCB11AK-106X C CAPACITOR 10uF 10V K Q0204 2SA1022/BC/-X TRANSISTOR C0211 NDC31HJ-820X C CAPACITOR 82pF 50V J...
  • Page 105 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C1306 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4003 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1309 NDC31HJ-151X C CAPACITOR 150pF 50V J C4005 NCB31AK-105X C CAPACITOR 1uF 10V K C1402 NDC31HJ-330X...
  • Page 106 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C9205 NCJ41CK-226X-U C CAPACITOR 22mF 16V K R0523 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C9207 NCB31HK-222X C CAPACITOR 2200pF 50V K R0524 NRSA63J-0R0X MG RESISTOR 0Ω...
  • Page 107 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R3063 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4027 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3064 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4028 NRSA63J-103X MG RESISTOR 10kΩ...
  • Page 108 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R7026 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7216 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7029 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7401 NRSA63J-103X MG RESISTOR 10kΩ...

  • Page 109: Receiver Pw Board Ass'y (Lca10523-03B) (Sfp-0F505A)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local RA3526 NRZ0080-510X NET RESISTOR 51Ω 1/16W J K3010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J RA3530 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 K6101 NQR0413-003X FERRITE BEADS RA3531 NRZ0080-510X...

  • Page 110: Rear Jack Pw Board Ass'y (Lca10444-04C) (Sfp-0J505A)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C3537 NCB31CK-104X C CAPACITOR 0.1uF 16V K R3613 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J C3540 NCB31HK-183X C CAPACITOR 0.018uF 50V K R3631 NRSA63J-563X MG RESISTOR 56kΩ...
  • Page 111 Ref No. Part No. Part Name Description Local C2015 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2201 NCB11CK-105X C CAPACITOR 1uF 16V K C2202 NCB11CK-105X C CAPACITOR 1uF 16V K C2203 NCB11CK-105X C CAPACITOR 1uF 16V K C2204 NCB11CK-105X C CAPACITOR 1uF 16V K C2205 NCB11CK-105X...

  • Page 112: Packing

    PACKING FRONT FRONT FRONT PACKING PARTS LIST  Ref.No. Part No. Part Name Description Local LC32513-006B PACKING CASE LC11750-001A CUSHION ASSY 2pcs in 1set PQM30021-93 POLY BAG LC21462-001B ACC SHEET QPA01203505 POLY BAG 12cm x 35cm QMPL050-250-K POWER CORD(EU) 2.5m BLACK ...

This manual is also suitable for:

Pd-50x575k

Table of Contents
