Page 1 PD-35D30ES SERVICE MANUAL PDP COLOUR TELEVISION 52091 2003 PD-35D30ES BASIC CHASSIS TS-35D30ES [FRONT SPEAKER (R)] TS-35D30ES [FRONT SPEAKER (L)] VM-35D30ES TS-35D30ES [PLASMA DISPLAY UNIT] [RM-C61] [SUB WOOFER] TU-35D30ES [RECEIVER UNIT] TABLE OF CONTENTS PRECAUTIONS ............... 1-4 SPECIFIC SERVICE INSTRUCTIONS .
Page 2 PD-35D30ES SPECIFICATION Item Contents Dimensions (W x H x D) Plasma display unit 88.7cm x 54.5cm x 9.9cm (without Front speaker) 97.5cm x 54.5cm x 10.3cm (with Front speaker) Receiver unit 43.5cm x 9.9cm x 38.2cm Front speaker 4.2cm x 54.5cm x 5.4cm Sub woofer 43.5cm x 23.0cm x 12.6cm...
Page 3 PD-35D30ES 21-pin Euro connector (SCART) : EXT-1/EXT-2/EXT-3 PinNo. Signal Designation Matching Value EXT-1 EXT-2 EXT-3 AUDIO R output 500mV(rms) (Nominal), Used (TV OUT) Used (LINE OUT) NC Low impedance AUDIO R input 500mV(rms) (Nominal), Used Used Used High impedance AUDIO L output...
Page 4: Precautions
PD-35D30ES SECTION 1 PRECAUTIONS 1.1 SAFETY PRECAUTIONS [EXCEPT FOR UK] and connecting the other end of the lead through a 10k 2W resistor to the anode button. (1) The design of this product contains special hardware, (8) When service is required, observe the original lead dress.
Page 5 PD-35D30ES 1.2 SAFETY PRECAUTIONS [FOR UK] (1) The design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer.
Page 6 PD-35D30ES 1.3 INSTALLATION 1.3.1 HEAT DISSIPATION 1.3.2 INSTALLATION REQUIREMENTS If the heat dissipation vent behind this unit is blocked, cooling Ensure that the minimal distance is maintained, as specified efficiency may deteriorate and temperature inside the unit will below, between the unit with and the surrounding walls, as well rise.
Page 7 PD-35D30ES 1.4 PRECAUTIONS REGARDING PDP 1.4.1 PRECAUTIONS DURING NOTES FOR Do not use solvents such as benzine or thinner to wipe the filter TRANSPORTATION surface. This may cause the filter to deteriorate in quality or the When transporting the display unit, pressure exerted on the coating on the surface to come off.
Page 8: Specific Service Instructions
PD-35D30ES SECTION 2 SPECIFIC SERVICE INSTRUCTIONS 2.1 FEATURES HIGH-DEFINITION IMAGE TECHNOLOGY (DIST), High Quality Sound Technology (DD) DIST (Digital Image Scaling Technology) Employs an interpolation method that doubles the scanning lines to realize 480-line flicker- free picture making it especially suitable for reproducing high-resolution pictures even on large-screen displays.
Page 9 PD-35D30ES 2.2 TECHNICAL INFORMATION 2.2.1 PDP STRUCTURE AND CHARACTERISTIC This unit (Display Unit) uses the flat type panel PDP (Plasma Display Panel), instead of the conventional CRT (Cathode Ray Tube), as a display unit. 2.2.2 PIXEL (CELL) ARRAY PDP is constructed by sealing the xenon, which emits neon and ultraviolet rays for discharging purpose, in between the electrodes lay on the front glass substrate and rear glass substrate.
Page 10 PD-35D30ES 2.3 MAIN CPU FUNCTIONAL TABLE (RECEIVER UNIT) Pin No. Terminal Name Port Name Remark Pin No. Terminal Name Port Name Remark VSS33 VSS33 VDD33 VDD33 3.3V REMOCON P2.8 KEY1 P2.9 KEY2 P2.10 (NOR/INST) I/O KEY3 P2.11 RESET-IN RSTIN TV_LINK P2.12...
Page 11 PD-35D30ES 2.4 DISASSEMBLY PROCEDURE [DISPLAY UNIT] CAUTION: • When exchanging parts etc. with the front side (PDP side) facing down, please place a protection sheet below before (x6) starting, so as to prevent scratches on the front side. (x2) 2.4.1 REMOVING THE REAR COVER (Fig.1)
Page 12 PD-35D30ES 2.4.7 REMOVING THE PDP POWER PWB (Fig.3) 2.4.9 REMOVING THE DISPLAY INTERFACE PWB (Fig.4) • Remove the REAR COVER and INSULATOR SHEET. • Remove the REAR COVER. (1) Remove the 6 screws [K], and remove the PDP POWER (1) Remove the 1 screw [N], 2 screws [O], 2 screws [P], and PWB.
Page 13 PD-35D30ES (1) Remove the 4 screws [U], and remove the 2 pieces of CAUTION: BOTTOM BRACKET, TOP BRACKET and 2 pieces of • The INNER CASE is attached with the FRONT FILTER SIDE BRACKET. (made of glass). Be careful not to impose shock to it.
Page 14 PD-35D30ES 2.5 DISASSEMBLY OF PROCEDURE [RECEIVER UNIT] 2.5.1 REMOVING THE TOP COVER 2.5.7 REMOVING THE MAIN PWB AND RECEIVER POWER (1) Remove the 4 screws [A] on the both left and right sides. (2) Remove the 3 screws [B] on the rear side.
Page 15 PD-35D30ES (x2) TOP COVER (x3) SUPPORT BRACKET (x2) MI-COM PWB PB HOLDER DIST PWB MI-COM INTERFACE (x5) DIST RELAY PWB AV JACK PWB MI-COM HOLDER SUB TUNER AV SW PWB (x4) TERMINAL FRONT PANEL BRACKET RECEIVER POWER PWB INSULATOR MAIN PWB...
Page 16 PD-35D30ES 2.6 REPLACEMENT OF MEMORY IC This unit uses the nonvolatile memory IC. The memory IC memories data for video and deflection circuits. To replace the memory IC without the data written, malfunctions might occurred while power is on, and the normal image might not appear. When replacing the memory IC, be sure to use the IC written with the initial values of data.
Page 17 PD-35D30ES 2.6.3 SETTINGS OF THE LAST MEMORY FACTORY SHIPMENT Setting item Setting value Setting item Setting value POWER SOUND SETTING · SHIPPING CHANNEL STEREO/I Stereo sound PRESET CHANNEL Refer to BASS Center OPERATING INSTRUCTIONS TREBLE Center VOLUME BALANCE Center PICTURE SETTING...
Page 18 PD-35D30ES 2.6.5 SERVICE MENU SETTING ITEMS Setting item Setting value Setting item Setting value 1.IF 1.VCO 6.STATUS (Do not adjust) 2.ATT ON/OFF 2. V/C 1.CUT OF R 13.COLOUR 7.VNR (Do not adjust) 2.CUT OF G 14.HUE 1.MYLV 10.MCCOR 3.CUT OF B 15.BY GAIN...
Page 19 PD-35D30ES 2.7 REPLACEMENT OF CHIP COMPONENT 2.7.1 CAUTIONS (1) Avoid heating for more than 3 seconds. (2) Do not rub the electrodes and the resist parts of the pattern. (3) When removing a chip part, melt the solder adequately. (4) Do not reuse a chip part after removing it.
Page 20: Adjustments
PD-35D30ES SECTION 3 ADJUSTMENTS 3.1 ADJUSTMENT PREPARATION 3.2 MEASURING INSTRUMENT AND FIXTURES (1) Prior to the following procedure, be sure to connect the receiver • DC voltmeter (or Digital voltmeter) unit and the display unit. • Oscilloscope (2) Adjustment of many Majority of the adjustment items for •...
Page 21 PD-35D30ES 3.4 MAIN PARTS LOCATIONS (DISPLAY UNIT) Fig.2 (No.52091)1-21...
Page 22 PD-35D30ES 3.5 SERVICE MENU SCREEN SERVICE MENU SERVICE MENU 1. IF 2. V/C 3. AUDIO 4. DD/CM 5. VSM PRESET 6. STATUS 7. VNR 8. IP 9. SHIPPING (OFF) 0. BUS FREE 1-9 : SELECT i : EXIT 1.IF 4. DD/CM...
Page 23 PD-35D30ES 3.6 BASIC OPERATION OF THE SERVICE MENU MODE [USING REMOTE CONTROL UNIT] 3.6.1 HOW TO ENTER THE SERVICE MENU MODE 3.6.4 SETTINGS OF THE SERVICE MENUS (1) Press the [INFORMATION] key and the [MUTING] key of 3.6.4.1 [1. IF] (VCO adjustment, ATT setting)
Page 24 PD-35D30ES 3.7 DEFAULT VALUES IN THE SERVICE MENU SETTING MODE • Perform fine-tuning based on the "default values" using the remote control when in the SERVICE MENU setting mode. • The "default values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved may be different from the default values.
Page 25 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC (NO DISPLAY) -128~0127 0000 0000 0000 (NO DISPLAY) 0000~0255 0128 0128 0128 (NO DISPLAY) -128~0127 0000 0000 0000 (NO DISPLAY) 0000~0255 0123 0123 0123 (NO DISPLAY) -128~0127 0000 0000 0000...
Page 26 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC (NO DISPLAY) 0000~0003 0003 0003 0003 (NO DISPLAY) 0000~0003 0003 0003 0003 (NO DISPLAY) 0000~0015 0000 0000 0000 (NO DISPLAY) 0000~0063 0019 0019 0019 (NO DISPLAY) 0000/0001 0001 0001 0001...
Page 27 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC (NO DISPLAY) 0000~0007 0000 0000 0000 (NO DISPLAY) 0000~0003 0000 0000 0000 (NO DISPLAY) 0000~0003 0000 0000 0000 (NO DISPLAY) 0000~0003 0000 0000 0000 Setting value Item No. Item Variable range...
Page 28 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC DDT13 (NO DISPLAY) 0000~0255 0000 0000 0000 DDT14 (NO DISPLAY) 0000~0003 0000 0000 0001 DDT15 (NO DISPLAY) 0000~0007 0000 0000 0000 DDT16 (NO DISPLAY) 0000~0255 0021 0021 0123 DDT17 (NO DISPLAY)
Page 29 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC CMT24 (NO DISPLAY) -128~0127 0010 0010 0003 CMT25 (NO DISPLAY) -128~0127 0020 0020 0010 CMT26 (NO DISPLAY) -128~0127 0010 0010 0005 CMT27 (NO DISPLAY) -128~0127 0015 0015 0010 CMT28 (NO DISPLAY)
Page 30 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC DDP12 (NO DISPLAY) 0000~0007 0006 0006 0006 DDP13 (NO DISPLAY) 0000~0007 0004 0004 0002 DDP14 (NO DISPLAY) 0000~0003 0002 0002 0000 DDP15 (NO DISPLAY) 0000~0015 0000 0000 0001 DDP16 (NO DISPLAY)
Page 31 PD-35D30ES 3.7.4 [7.VNR] (*All fixed) NOTE: • For reference, initial setting values in the following conditions are written here. Input signal :PAL/SECAM/NTSC Picture mode :Standard Zoom :Full Multi screen :Single screen Colour temp. :Normal Setting value Item No. Item Variable range...
Page 32 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC PPB005 (NO DISPLAY) 0000~00FF 0000 0000 0000 PPB006 (NO DISPLAY) 0000~00FF 0000 0000 0000 PPB007 (NO DISPLAY) 0000~001F 0000 0000 0000 PPB008 (NO DISPLAY) 0000~00FF 0000 0000 0000 PPB009 (NO DISPLAY)
Page 33 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC PPD004 (NO DISPLAY) 0000~00FF 0002 0002 0002 PPD005 (NO DISPLAY) 0000~00FF 0038 0038 0038 PPD006 (NO DISPLAY) 0000~00FF 0000 0000 0000 PPD007 (NO DISPLAY) 0000~00FF 001A 001A 001A PPD008 (NO DISPLAY)
Page 34 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC ADS033 (NO DISPLAY) 0000/0001 0001 0001 0001 ADS034 (NO DISPLAY) 0000~00FF 0002 0002 0002 Setting value Item No. Item Variable range SECAM NTSC IPA001 (NO DISPLAY) 0000/0001 0001 0001 0001...
Page 35 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC IPA044 (NO DISPLAY) 0000~003F 0020 0020 0020 IPA045 (NO DISPLAY) 0000~003F 0020 0020 0020 IPA046 (NO DISPLAY) 0000~003F 0020 0020 0020 IPA047 (NO DISPLAY) 0000~0003 0002 0002 0002 IPA048 (NO DISPLAY)
Page 36 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC IPA092 (NO DISPLAY) 0000~00FF 0000 0000 0000 IPA093 (NO DISPLAY) 0000~000F 0006 0006 0006 IPA094 (NO DISPLAY) 0000~00FF 0071 0071 0071 IPA095 (NO DISPLAY) 0000~000F 0000 0000 0000 IPA096 (NO DISPLAY)
Page 37 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC IPB017 (NO DISPLAY) 0000~000F 0000 0000 0000 IPB018 (NO DISPLAY) 0000~00FF 0000 0028 0028 IPB019 (NO DISPLAY) 0000~000F 0000 0000 0000 IPB020 (NO DISPLAY) 0000~00FF 0000 0026 0026 IPB021 (NO DISPLAY)
Page 38 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC IPB065 (NO DISPLAY) 0000~00FF 0000 0000 0000 IPB066 (NO DISPLAY) 0000/0001 009D 009D 009D IPB067 (NO DISPLAY) 0000~000F 0006 0006 0006 IPB068 (NO DISPLAY) 0000~000F 0040 0040 0040 IPB069 (NO DISPLAY)
Page 39 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC IPC022 (NO DISPLAY) 0000~00FF 00FE 00FE 00FE IPC023 (NO DISPLAY) 0000~0003 0000 0000 0000 IPC024 (NO DISPLAY) 0000~00FF 0040 0040 0040 IPC025 (NO DISPLAY) 0000/0001 0000 0000 0000 IPC026 (NO DISPLAY)
Page 40 PD-35D30ES Setting value Item No. Item Variable range SECAM NTSC IPD024 (NO DISPLAY) 0000~00FF 0070 0070 0070 IPD025 (NO DISPLAY) 0000~000F 0060 0060 0060 IPD026 (NO DISPLAY) 0000~00FF 0050 0050 0050 IPD027 (NO DISPLAY) 0000~00FF 0040 0040 0040 IPD028 (NO DISPLAY)
Page 41 PD-35D30ES 3.8 ADJUSTMENT PROCEDURE 3.8.1 DISPLAY UNIT Measuring Item Test point Adjustment part Description instrument PDP POWER DC voltmeter Connector Vs VR :170V ADJ CAUTION: SUPPLY CN0C4 (R628) During adjustment operation of PDP POWER SUPPLY VOLTAGE Signal generator [PDP POWER...
Page 42 PD-35D30ES 3.8.2 RECEIVER UNIT Measuring Item Test point Adjustment part Description instrument VCO (AFC) Remote control [1.IF] (1) Receive a PAL colour bar signal. check unit (2) Select "1. IF" from the SERVICE MENU. (3) Select "1. VCO." Signal generator (4) Make sure that an arrow of "MAIN"...
Page 43 PD-35D30ES Measuring Item Test point Adjustment part Description instrument PAL/SECAM/ Remote control [2.V/C] - PAL COLOUR - NTSC SUB unit 13. COLOUR (1) Receive a PAL colour bar signal (full field colour COLOUR (Colour) bar). Signal generator (2) Select "2. V/C" from the SERVICE MENU.
Page 44 PD-35D30ES Measuring Item Test point Adjustment part Description instrument SUB-SCREEN Remote control [2. V/C] (1) Receive a PAL black and white pattern signal BRIGHTNESS unit 11. TWN BRG (including 0% black signal). (Sub-screen (2) Select "2. V/C" from the SERVICE MENU.
Page 45 PD-35D30ES Measuring Item Test point Adjustment part Description instrument PAL/SECAM/ Remote control [2. V/C] - SUB-SCREEN PAL COLOUR - 16. TWN COL NTSC unit (1) Receive a PAL colour bar signal (full field colour (Sub-screen SUB-SCREEN bar). colour) COLOUR Signal generator (2) Select "2.
Page 46 PD-35D30ES Measuring Item Test point Adjustment part Description instrument WHITE Remote control [2. V/C] (1) Receive a PAL 75% all-white signal. BALANCE unit S13: R GAIN (2) Set colour temperature to "NORMAL." (HIGH LIGHT) S15: G GAIN (3) Select "2. V/C" from the SERVICE MENU.
Page 47: Trouble Shooting
PD-35D30ES SECTION 4 TROUBLE SHOOTING 4.1 SELF-DIAGNOSIS FEATURE 4.1.1 OUTLINE This model has a "Self-diagnosis function," which checks the operation state of the circuits and informs us of a failure by flashing POWER LED when a failure occurs. Diagnosis is performed when power is turned on, and information input to the main microcomputer is monitored at all time.
Page 48 PD-35D30ES VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan (No.52091) Printed in Japan 200304WPC...
Page 49 PD-35D30ES SCHEMATIC DIAGRAMS PDP COLOUR TELEVISION 52091 2003 PD-35D30ES BASIC CHASSIS CD-ROM No.SML200304 TS-35D30ES [FRONT SPEAKER (R)] TS-35D30ES [FRONT SPEAKER (L)] VM-35D30ES TS-35D30ES [PLASMA DISPLAY UNIT] [RM-C61] [SUB WOOFER] TU-35D30ES [RECEIVER UNIT] No.52091 COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.
Page 50: Table Of Contents
PD-35D30ES PD-35D30ES CONTENTS PD-35D30ES USING P.W. BOARD ......................2-3 STANDARD CIRCUIT DIAGRAM SEMICONDUCTOR SHAPES ................... 2-3 BLOCK DIAGRAM - 1 ......................2-4 NOTE ON USING CIRCUIT DIAGRAMS BLOCK DIAGRAM - 2 ......................2-5 1.SAFETY Type CIRCUIT DIAGRAMS [RECEIVER UNIT] The components identified by the...
Page 51: Using P.w. Board
PD-35D30ES PD-35D30ES USING P.W. BOARD BLOCK DIAGRAM - 1 DIST PWB RECEIVER UNIT [TU-35D30ES] MAIN P.W. BOARD SMK-1301A-U2 AV SW P.W. BOARD SMK0S301A-U2 LIN+/- RIN+/- AV JACK P.W. BOARD SMK0J301A-U2 SUB TUNER P.W. BOARD SMK0F301A-U2 DIST RELAY P.W. BOARD SMK0Z311A-U2...
Page 52: Block Diagram - 1
PD-35D30ES PD-35D30ES BLOCK DIAGRAM - 2 RECEIVER UNIT DISPLAY UNIT Q501,Q502 IC501 IC602 MULTI VOLUME SOUND CONTROL MHP_L/R L/R OUT PROCESSOR HEADPHONE UD001 AUDIO PWB L/R OUT SPILTTER TU001 MAIN TV V1 U/V FRONTEND LIN+/- IC601 MAIN SPEAKER(L) RIN+/- IC6521...
Page 53: Circuit Diagrams [Receiver Unit] Main Pwb Circuit Diagram
PD-35D30ES PD-35D30ES CIRCUIT DIAGRAMS [RECEIVER UNIT] MAIN PWB CIRCUIT DIAGRAM (1/4) SHEET 1 HS601 OPEN IC601 OPEN C013 C012 R007 C010 2.2k M_MONO C011 C611 C649 OPEN OPEN R601 R607 C647 C601 R602 OPEN OPEN R006 OPEN OPEN Y608 OPEN...
Page 54 PD-35D30ES PD-35D30ES MAIN PWB CIRCUIT DIAGRAM (2/4) SHEET 2 AV SW PWB CN006 (SHEET5) AV SW PWB CN007 (SHEET5) DIST RELAY PWB CN005 (SHEET8) CN005 CN006 CN007 QGC2507C1-96 QGB1505J1-25 QGB1505J1-35 2.5V L431 C431 QRN143J-0R0X C432 SHEET4 C437 SHEET4 1000 /6.3...
Page 55 PD-35D30ES PD-35D30ES MAIN PWB CIRCUIT DIAGRAM (3/4) SHEET 3 R415 R413 OPEN OPEN IC401 IC401 OPEN IC402 R414 OPEN IC402 OPEN OPEN VMOFF OPEN C404 R406 C402 R404 OPEN OPEN OPEN OPEN OSD_VD2 D421 R410 R405 R409 MA8150/M/-X OPEN OPEN...
Page 56 PD-35D30ES PD-35D30ES MAIN PWB CIRCUIT DIAGRAM (4/4) SHEET 4 CN00C QGA2501F1-06 R711 D771 4.7k MA3056/M/-X R705 4.7k IC901 OPEN R706 HS901 4.7k OPEN D772 MA3056/M/-X D901 OPEN R901 OPEN D991 OPEN C901 C902 OPEN OPEN R751 R730 C715 .056 Y620...
Page 57: Av Sw Pwb Circuit Diagram
PD-35D30ES PD-35D30ES AV SW PWB CIRCUIT DIAGRAM SHEET 5 R636 R635 R625 C610 100k R634 R637 C607 1.8k NCF31AZ-105X C608 QETN1HM-106Z NCF31AZ-105X R341 C343 R623 2.2K CNS00G QETN1HM-105Z AV JACK PWB QJB003-035033 QETN1HM-106Z R343 R626 C613 CNJ00G R342 C344 R631...
Page 58: Av Jack Pwb Circuit Diagram
PD-35D30ES PD-35D30ES AV JACK PWB CIRCUIT DIAGRAM SHEET 6 R109 R107 R108 D304 D104 MTZJ12C-T2 D103 MA3056/M/-X MA3056/M/-X J001 R106 CE40529-006 D102 MA3056/M/-X R105 CNJ020 D101 QGB1505K1-40 MA3056/M/-X CE42681-001Y C104 .0047 K101 C103 .0047 C102 .0047 C101 .0047 K102 CE42681-001Y...
Page 59: Sub Tuner Pwb Circuit Diagram
PD-35D30ES PD-35D30ES SUB TUNER PWB CIRCUIT DIAGRAM SHEET 7 AV SW PWB CNS00A(SHEET5) CNF00A CN008 QGA2501F1-10 QGB1505K1-25 UD001 TU002 QAU0308-001 QAU0301-002 SUB U/V FRONTEND RF SPLITTER C012 C007 R008 MAIN PWB OPEN CN008 C008 C005 TV2_M (SHEET1) R001 C011 C001 .0022...
Page 60 PD-35D30ES PD-35D30ES DIST RELAY PWB CIRCUIT DIAGRAM SHEET 8 DIST PWB CN005 (SHEET9) CN015 QGC2507C1-96 AGND DIST RELAY PWB ASS'Y SMK0Z311A-U2 CN005 MAIN PWB CN005 (SHEET2) No.52091 No.52091 2-21 2-22...
Page 61: Dist Pwb Circuit Diagram
PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (1/9) SHEET 9 DIST PWB ASS'Y (1/9) SMK0Z302A-U2 VCC9A VCC9ASAD LC029 EFP5 VCC9A VCC9AMAD NQR0415-005X RB139 LC017 EFP5 QB102 GND9ASAD RB138 VCC3A VC3ASAD NCB31EK-393X NQR0415-005X 2SA1022/BC/-X VCC5D CB126 QB001 QB002 GND9AMAD LC025 CB052 RB108 0.039...
Page 62 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (2/9) SHEET 10 VCC3D VC3DDR LB108 CB362 CB356 CB355 CB354 RB343 OPEN 0.47 LB109 RB378 RB344 NRZ0034-122W *RA122 *RA122 RA131 RA132 OPEN RA118 RA117 *RA122 *RA122 DQ103 DQ014 DQ100 DQ010 IC107 DQ104 DQ013 LP3964EMP-ADJ-X...
Page 63 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (3/9) SHEET 11 SHEET15, 17 SHEET15 IC203 R1170H151B-X VCC2.5 NRVA02D-562X VC3A1DSD VCC3A VCC3D VC3D1DSD RB474 5.6k RB476 OPEN VCC1.5 NQR0413-003X LB202 RB473 LB201 CB424 CORE3 RB475 CB402 CB412 DGND NRSA02J-0R0X NCF31AZ-105X NRVA02D-103X CB427 CB401...
Page 64 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (4/9) SHEET 12 IC253 R1170H251B-X DIST PWB ASS'Y (4/9) SMK0Z302A-U2 VCC5A VC2.5_1YC L002 LC051 NQR0450-008X NQR0413-003X VC5YC NBE71CM-476X VCC9A R003 C004 C005 C006 L004 C007 C003 NQR0413-003X NCB21AK-105X AGND C001 C002 NCB21CK-334X AGND AGND...
Page 65 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (5/9) SHEET 13 S_CIN S_CV/YIN YM_OUT YM_OUT RYM_OUT RYM_OUT VCC5A REG5V BYM_OUT BYM_OUT C713 L807 CORE3 L707 CORE3 C813 HDM_OUT SHEET9 NQR0413-003X NDC31HJ-6R0X NDC31HJ-6R0X HDM_OUT NQR0413-003X C719 C718 C819 C818 VDM_OUT C714 C814 VDM_OUT 0.01...
Page 66 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (6/9) SHEET 14 DIST PWB ASS'Y (6/9) SMK0Z302A-U2 SHEET9 CLKS VCC3A CB602 CB601 LC601 EFP5 NQR0415-005X RB607 RB601 RB604 3.3k VCC5D GND2 CB603 LB601 0.0047 NCB21HK-472X OPEN RB611 OPEN RB627 CB604 0.47 RB612 VC3D2DSD...
Page 67 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (7/9) SHEET 15 VCC3DPDP NRZ0040-0R0X NRZ0040-0R0X RA463 RA464 RA468 RA466 NRZ0040-0R0X NRZ0040-0R0X RA467 RA465 NRZ0040-0R0X NRZ0040-0R0X VCC2.5PDP VCC3D VCC3DPDP C478 C477 NQR0413-003X C481 C480 C479 L461 CORE3 C461 C462 /6.3 /6.3 DGND NRZ0040-0R0X DOSDR1...
Page 68 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (8/9) SHEET 16 DIST PWB ASS'Y (8/9) SMK0Z302A-U2 SHEET9 CLKCM SHEET15 OSDCLK VCC3A VCC3VAP MICON_H SHEET15,17 MICON_V R564 R565 R513 OPEN OPEN K502 C513 NQR0413-003X K501 C514 C512 C502 NQR0413-003X R515 AGND VCC9A VCC3AD1...
Page 69 PD-35D30ES PD-35D30ES DIST PWB CIRCUIT DIAGRAM (9/9) SHEET 17 MI-COM MI-COM MI-COM INTERFACE PWB CN00L INTERFACE PWB CN0L1 PWB CNJ1 AV SW PWB (SHEET19) (SHEET19) (SHEET20) CN00K (SHEET5) CN00L QGA2001F2-14V CN00K CN0L1 CN0J1 QGA2001F2-06V QGA2001F2-06V QGA2001F2-09V DIST PWB ASS'Y (9/9)
Page 70 PD-35D30ES PD-35D30ES RECEIVER POWER PWB CIRCUIT DIAGRAM SHEET 18 IC9932 LF9901 MM1565AF-X QQR1084-002 QNC0085-002 Y9901 Y9905 AC110 240V D9971 OPEN OPEN MA111-X 50Hz / 60Hz VA9901 CN90PW Y9902 Y9906 QAF0052-621 OPEN OPEN QGA7901C1-02 RY9951 QCZ9054-472 QSK0099-001 CN9001 C9903 C9931 QGB1506M1-16 LF9902 .047...
Page 71 PD-35D30ES PD-35D30ES MI-COM INTERFACE PWB CIRCUIT DIAGRAM SHEET19 MI-COM PWB CN004 (SHEET20) CN014 QGB1232J1-50 CN00L QGA2001C1-14 MI-COM INTERFACE PWB ASS'Y SMK0M311A-U2 DIST PWB CN00L (SHEET17) CN0L1 R101 IC101 QGA2001C1-06 TC74HC4066AP DIST PWB CN0L1 (SHEET17) (HOT PLUG) C101 R103 R102 R106...
Page 72: Mi-Com Pwb Circuit Diagram
PD-35D30ES PD-35D30ES MI-COM PWB CIRCUIT DIAGRAM SHEET 20 DIST PWB CN0J1 CNJ1 QGA2001F2-09V (SHEET17) R143 OPEN C058 R141 OPEN OPEN R142 OPEN C019 R139 2.2k MI-COM PWB ASS'Y C018 OPEN C020 R137 Q007 2.2k R138 2SA1162/YG/-X SMK0M301A-U2 2.2k R169 R125...
Page 73: Front Control Pwb Circuit Diagram
PD-35D30ES PD-35D30ES FRONT CONTROL PWB CIRCUIT DIAGRAM SHEET 21 FRONT CONTROL PWB ASS'Y J8001 J8303 SMK-8301A-U2 QMS3004-C01 QNZ0438-001 QNZ0438-001 QNZ0438-001 QNZ0438-001 R4IN L4IN V4IN QSW0619-003Z J8303 J8303 J8303 S8001 R8010 C8001 R8317 C8310 C8311 C8002 .0047 .0047 R8804 V_GND Q8801...
Page 74: Circuit Diagrams [Display Unit]
PD-35D30ES PD-35D30ES CIRCUIT DIAGRAMS [DISPLAY UNIT] DISPLAY INTERFACE PWB CIRCUIT DIAGRAM (1/4) SHEET 22 AUDIO PWB CN60CE (SHEET26) CN0CE QGA2501C5-06 DISPLAY INTERFACE PWB ASS'Y (1/4) SHEET23 AUDIO_GND SSB-7367A-U2 R819 R820 Y801 VCC5STB NRSA63J-0R0X LC801 R801 IC802 IC801 BA05FP-X BA033FP-X R827...
Page 75 PD-35D30ES PD-35D30ES DISPLAY INTERFACE PWB CIRCUIT DIAGRAM (2/4) SHEET 23 SHEET22 DISPLAY INTERFACE PWB ASS'Y (2/4) SSB-7367A-U2 IC602 C613 DS90LV018ATM-X AVCC LVDSVCC VCC PVCC VCCL LVDSVCC PLLVCC VCC3D VCC3D L601 L501 NQR0351-001X NQR0351-001X VCC3D VCC3D VCC3.3DVI VCC3.3LV C502 C601 C602...
Page 76 PD-35D30ES PD-35D30ES DISPLAY INTERFACE PWB CIRCUIT DIAGRAM (3/4) SHEET 24 VCC3DPDP VCC2.5PDP RGBCLK VCC2.5PDP R441 VCC3D VCC3DPDP RGBCLK RGBHD RGBHD RGBVD R425 R424 R423 RGBVD VCC2.5 VCC3D VCC2.5PDP VCC3DPDP R422 R420 R419 R418 CORE3 L402 CORE3 L401 AJB0 AJB0 NQR0351-003X...
Page 77 PD-35D30ES PD-35D30ES DISPLAY INTERFACE PWB CIRCUIT DIAGRAM (4/4) SHEET 25 DISPLAY INTERFACE PWB ASS'Y (4/4) RGBCLK SSB-7367A-U2 RGBVD RGBHD AJR0 AJR0 AJR1 AJR1 AJR2 AJR2 AJR3 AJR3 AJR4 AJR4 AJR5 AJR5 AJR6 AJR6 C334 R312 AJR7 AJR7 AJR8 AJR8 K301...
Page 78: Audio Pwb Circuit Diagram
PD-35D30ES PD-35D30ES AUDIO PWB CIRCUIT DIAGRAM SHEET 26 IC6621 TA8270H H6621 LC31230-002A AUDIO PWB ASS'Y CN600K C6627 QGA7901C1-02 QETM1EM-228 SYSTEM POWER PWB SMK-6066A-U2 CN900K C6628 (SHEET31) C6686 OPEN C6692 Q6523 OPEN 2SB709A/QR/-X C6587 C6571 C6621 R6571 OPEN R6581 R6601 R6603...
Page 79: Speaker Terminal Pwb Circuit Diagram
PD-35D30ES PD-35D30ES SPEAKER TERMINAL PWB CIRCUIT DIAGRAM SHEET 27 SPEAKER TERMINAL PWB ASS'Y SMK-6166A-U2 CN70SP J7003 L7203 QGA2501C1-09 CEMT019-001 SUB WOOFER C7203 Y7203 QUY160-100Y AUDIO PWB C7202 L7201 L7202 CN60SP (SHEET26) C7201 Y7201 Y7202 QUY160-100Y QUY160-100Y J7002 L7103 CEMT019-001 FRONT SPEAKER(L)
Page 80 PD-35D30ES PD-35D30ES DISPLAY LED PWB CIRCUIT DIAGRAM SHEET 28 DISPLAY LED PWB ASS'Y SMK0L266A-U2 CN10CC QGA2501F1-08 DISPLAY INTERFACE PWB CN0CC (SHEET22) R1744 R1743 1.5k Q1741 R1742 UN2212-X Q1742 UN2212-X R1741 D1743 SPR-39MVWF IC1741 TPS818 R1750 330K R1758 R1752 R1753 C1743...
Page 81: Display Switch Pwb Circuit Diagram
PD-35D30ES PD-35D30ES DISPLAY SWITCH PWB CIRCUIT DIAGRAM SHEET 29 DISPLAY SWITCH PWB ASS'Y SMK0L366A-U2 CN20CD QGA2501F1-06 S2707 QSW0619-003Z DISPLAY INTERFACE PWB CN0CD (SHEET22) S2705 S2706 S2701 QSW0619-003Z QSW0619-003Z QSW0619-003Z POWER CHANNEL CHANNEL VOLUME R2701 R2702 5.6k S2703 S2704 S2702 QSW0619-003Z...
Page 82 PD-35D30ES PD-35D30ES LINE FILTER PWB CIRCUIT DIAGRAM SHEET 30 R902 OPEN Y901 OPEN F901 LF901 LF902 LF903 Y902 OPEN QMFZ041-100-J1 QQR1281-002 QQR1281-003 QQR1376-001 CN00P QGA7901C1-04 CN0PW SYSTEM POWER PWB C904 AV110~240V CN900P QRZ9046 50Hz/60Hz (SHEET31) -105Z QGA7901C1-02 C901 LF904 Y903...
Page 83: System Power Pwb Circuit Diagram
PD-35D30ES PD-35D30ES SYSTEM POWER PWB CIRCUIT DIAGRAM SHEET 31 CN900P QGA7901C1-04 CN900J QGA7901C1-02 LF9001 Y9003 QQR1376-001 LINE FILTER PWB PDP POWER PWB CN00P CN00J Y9004 LF9002 (SHEET30) (SHEET32) C9002 QQR1376-001 C9001 OPEN F9001 OPEN OPEN C9004 OPEN GND3 RY9102 QSK0090-001...
Page 84: Pdp Power Pwb Circuit Diagram
PD-35D30ES PD-35D30ES PDP POWER PWB CIRCUIT DIAGRAM (1/2) SHEET 32 PDP POWER PWB ASS'Y (1/2) SMK-9067A-U2 R002 QRL03EJ-121X H102 LC31942-001A D112 RY001 OPEN QSK0078-001 H103 LC31942-001A D002 C002 L101 C004 D105 CP101 .0022 .0022 QQR1375-001 YG912S6 QMFZ043-5R0Z-J1 QCZ9082-222Z QCZ9082-222Z 375V...
Page 85 PD-35D30ES PD-35D30ES PDP POWER PWB CIRCUIT DIAGRAM (2/2) SHEET 33 SHEET32 H504 IC503 PDP POWER PWB ASS'Y (2/2) C991 OPEN OPEN LC31942-001A OPEN R992 C527 OPEN CN0AO SMK-9067A-U2 OPEN R991 OPEN GND3 GND3 R554 Y992 OPEN OPEN C513 OPEN GND1...
Page 86: Pattern Diagrams [Receiver Unit] Receiver Power Pwb Pattern
PD-35D30ES PD-35D30ES PATTERN DIAGRAMS [RECEIVER UNIT] RECEIVER POWER PWB PATTERN W9203 W9201 CN9001 W8609 CN9002 R9951 L9951 C9952 D9953 IC9932 W8608 C9955 D9952 D9954 C9946 D9941 C9956 C9942 R9955 R9954 R9958 C9957 C9941 Y9941 C9953 R9952 CP9941 R9953 R9943 CL9015...
Page 87: Main Pwb Pattern
PD-35D30ES PD-35D30ES MAIN PWB PATTERN [SOLDER SIDE] FRONT No.52091 2-75 2-76 No.52091...
Page 88 PD-35D30ES PD-35D30ES MAIN PWB PATTERN [PARTS SIDE] FRONT No.52091 No.52091 2-77 2-78...
Page 89: Sub Tuner Pwb Pattern
PD-35D30ES PD-35D30ES SUB TUNER PWB PATTERN [SOLDER SIDE] CN00A FRONT C009 C002 L001 L003 L002 C011 C008 R001 R007 C003 C005 R004 R005 R008 C012 CN018 CN008 C001 UD001 TU002 ( ) ) SUB TUNER PWB PATTERN [PARTS SIDE] CN00A...
Page 90: Front Control Pwb Pattern
PD-35D30ES PD-35D30ES FRONT CONTROL PWB PATTERN CN8016 W8603 Y8001 L8003 C8321 W8205 R8804 W8602 R8002 L8001 Q8803 W8601 R8001 W8206 R8012 C8310 C8311 J8303 R8315 R8022 C8001 R8317 R8316 R8011 R8802 L8002 C8002 C8003 S8001 C8004 J8001 W8207 Y8002 MI-COM INTERFACE PWB PATTEREN [SOLDER SIDE]...
Page 91: Mi-Com Pwb Pattern
PD-35D30ES PD-35D30ES MI-COM PWB PATTERN [SOLDER SIDE] DIST RELAY PWB PATTERN [SOLDER SIDE] FRONT FRONT MI-COM PWB PATTERN [PARTS SIDE] DIST RELAY PWB PATTERN [PARTS SIDE] FRONT FRONT No.52091 2-83 2-84 No.52091...
Page 92: Av Sw Pwb Pattern
PD-35D30ES PD-35D30ES AV SW PWB PATTERN [SOLDER SIDE] FRONT AV SW PWB PATTERN [PARTS SIDE] FRONT No.52091 No.52091 2-85 2-86...
Page 93: Dist Pwb Pattern
PD-35D30ES PD-35D30ES DIST PWB PATTERN [SOLDER SIDE] FRONT RB502 RB361 RB474 RB475 RB365 CB375 LB204 LB201 LB202 RB364 IC206 CB427 RB257 RB575 RA131 RB552 CB376 CB371 RB362 RB532 CB379 RB418 RA129 CB378 CB374 RB622 RB368 RA127 RB367 RB343 RB363 RB573...
Page 94 PD-35D30ES PD-35D30ES DIST PWB PATTERN [PARTS SIDE] FRONT IC203 RB576 RB249 CB501 RB574 RB421 RB244 CB612 CB363 RB344 IC108 CB408 RB462 CB208 RB416 CB303 RB413 RB411 RB415 RB406 RB402 RB246 RB445 KB020 RB459 RB460 CB301 RA108 CB364 RB245 RA113 RA109...
Page 95: Av Jack Pwb Pattern
PD-35D30ES PD-35D30ES AV JACK PWB PATTERN [SOLDER SIDE] C654 D103 R107 R106 R105 D102 J003 J001 D101 R129 C104 C102 C124 C122 D104 K602 J004 C652 R301 R311 D113 R117 R116 R115 C301 C651 D112 K601 D301 R321 J002 C114...
Page 96: Pattern Diagrams [Display Unit]
PD-35D30ES PD-35D30ES PATTERN DIAGRAMS [DISPLAY UNIT] DISPLAY INTERFACE PWB PATTERN [SOLDER SIDE] DISPLAY INTERFACE PWB [PARTS SIDE] No.52091 No.52091 2-93 2-94...
Page 97: Pdp Power Pwb Pattern
PD-35D30ES PD-35D30ES PDP POWER PWB PATTERN [SOLDER SIDE] No.52091 2-95 2-96 No.52091...
Page 98 PD-35D30ES PD-35D30ES PDP POWER PWB PATTERN [PARTS SIDE] No.52091 No.52091 2-97 2-98...
Page 99: Speaker Terminal Pwb Pattern
PD-35D30ES PD-35D30ES SYSTEM POWER PATTERN [SOLDER SIDE] ( ) ) Q9142 Y9003 Y9242 Y9004 R9271 D9144 R9144 Q9143 R9299 Q9263 R9298 Y9292 C9144 D9223 R9272 C9298 R9224 C9122 C9141 IC9142 Q9262 D9266 K9223 R9270 R9234 C9225 Y9291 C9299 R9121 C9267...
Page 100 PD-35D30ES PD-35D30ES SYSTEM POWER PATTERN [PARTS SIDE] Y9003 D9144 Y9004 R9299 H9221 C9141 C9122 D9223 C9144 R9298 C9298 Y9292 L9266 K9223 R9224 IC9142 R9121 C9225 C9299 RY9102 Y9291 K9224 IC9221 R9230 R9122 PC9241 K9221 IC9242 C9222 R9241 C9267 R9226 D9227...
Page 101 PD-35D30ES PD-35D30ES AUIDO PWB PATTERN [SOLDER SIDE] AUIDO PWB PATTERN [PARTS SIDE] R6401 R6402 R6403 R6416 R6415 R6404 R6405 R6406 R6414 R6413 R6412 R6411 R6410 R6409 C6627 R6408 C6402 C6627 R6407 C6401 R6671 R6661 C6401 R6514 C6671 R6513 R6421 R6509...
Page 102: Line Filter Pwb Pattern
PD-35D30ES PD-35D30ES LINE FILTER PWB PATTERN DISPLAY SWITCH PWB PATTERN [SOLDER SIDE] S2702 S2705 R2701 S2706 S2701 S2704 S2703 S2707 R2702 ( ) ) ( ) ) FRONT R901 DISPLAY SWITCH PWB PATTERN [PARTS SIDE] C912 S2702 S2707 S2703 S2704...
Page 103: Voltage Chart [Receiver Unit]
PD-35D30ES PD-35D30ES ∗ VOLTAGE CHART [RECEIVER UNIT] Notes : Mark expresses the portion into which a voltage value is changed. <MAIN PWB> <AV SW PWB> <AV JACK PWB> <SUB TUNER PWB> <DIST RELAY PWB> <DIST PWB> PIN NO. VOLTAGE (V) PIN NO.
Page 104 PD-35D30ES PD-35D30ES <RECEIVER POWER PWB> <MI-COM INTERFACE PWB> <MI-COM PWB> <FRONT CONTROL PWB> PIN NO. VOLTAGE (V) PIN NO. VOLTAGE (V) PIN NO. VOLTAGE (V) PIN NO. VOLTAGE (V) PIN NO. VOLTAGE (V) PIN NO. VOLTAGE (V) PIN NO. VOLTAGE (V) PIN NO.
Page 105: Voltage Chart [Display Unit]
PD-35D30ES PD-35D30ES ∗ VOLTAGE CHART [DISPLAY UNIT] Notes : Mark expresses the portion into which a voltage value is changed. <DISPLAY INTERFACE PWB> <AUDIO PWB> <SYSTEM POWER PWB> <PDP POWER PWB> VOLTAGE (V) VOLTAGE (V) VOLTAGE (V) VOLTAGE (V) VOLTAGE (V)
Page 106: Waveforms
PD-35D30ES WAVEFORMS [ RECEIVER UNIT ] - MAIN PWB - (SHEET 1) (SHEET 2) TU001-16 IC101-6 IC101-7 IC101-8 IC101-12 IC101-13 IC101-14 1.8Vp-p 0.4Vp-p 0.58Vp-p 0.58Vp-p 0.44Vp-p 0.6Vp-p 0.6Vp-p IC101-31 IC101-32 IC101-33 IC201-1 IC201-2 IC201-3 IC201-4 1.0Vp-p 1.0Vp-p 0.98Vp-p 4.4Vp-p 5.0Vp-p 4.4Vp-p...
Page 107 PD-35D30ES IC703-15 IC801-1 IC801-3 IC801-4 IC801-5 IC801-7 IC801-9 0.64Vp-p 0.76Vp-p 1.3Vp-p 5.0Vp-p 0.64Vp-p 0.26Vp-p 4.4Vp-p IC801-11 IC801-21 IC801-22 IC801-23 IC801-46 IC802-7 IC802-25 [1us / div] 0.6Vp-p 0.4Vp-p 0.62Vp-p 0.62Vp-p 0.6Vp-p 0.92Vp-p 0.76Vp-p IC802-27 0.33Vp-p [ DISPLAY UNIT ] - DISPLAY INTERFACE PWB -...
Page 108 PD-35D30ES VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan (No.52091) Printed in Japan 200304WPC...
Page 109: Parts List
PD-35D30ES PARTS LIST CAUTION The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the  safety. The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.
Page 110 PD-35D30ES CONTENTS [DISPLAY UNIT : VM-35D30ES] ........................ 3-3 EXPLODED VIEW PARTS LIST ........................ 3-3 EXPLODED VIEW ............................3-4 PRINTED WIRING BOARD PARTS LIST ....................3-6 AUDIO PW BOARD ASS’Y (SMK-6066A-U2) ................... 3-6 SPEAKER TERMINAL PW BOARD ASS’Y (SMK-6166A-U2) ............3-7 DISPLAY INTERFACE PW BOARD ASS’Y (SSB-7367A-U2) ............
Page 111: [Display Unit : Vm-35D30Es]
PD-35D30ES [DISPLAY UNIT : VM-35D30ES] EXPLODED VIEW PARTS LIST  Ref.No. Part No. Part Name Description Local LC11530-001A REAR COVER  QYSBSFG4016M TAP SCREW 4mm x 16mm(x14) QYSPSPD3008M SCREW 3mm x 8mm(x6) LC21210-002A-0L RATING LABEL  LC21214-001A INSULATOR  LC31946-001A INLET SHIELD ...
Page 112: Exploded View
PD-35D30ES EXPLODED VIEW (x6) (x4) (x2) (x8) AUDIO PWB PDP POWER PWB FILTER SHIELD SYSTEM POWER SPEAKER TERMINAL LINE FILTER PWB (x4) (x2) CHASSIS BASE AC INLET COVER BLACK WHITE GREEN 3-4(No.52091)
Page 113 PD-35D30ES DISPLAY INTERFACE PWB INTERFACE PWB BASE SIDE BRACKET BOTTOM BRACKET TOP BRACKET SIDE BRACKET BACK FRAME (BOTTOM) BACK FRAME BACK FRAME (TOP) (BOTTOM) BACK FRAME (TOP) DISPLAY SWITCH DISPLAY LED (No.52091)3-5...
Page 114: Printed Wiring Board Parts List
PD-35D30ES PRINTED WIRING BOARD PARTS LIST AUDIO PW BOARD ASS’Y (SMK-6066A-U2) Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C6585 QETN1HM-106Z E CAPACITOR 10uF 50V M C6586 QETN1HM-106Z E CAPACITOR 10uF 50V M...
Page 115: Speaker Terminal Pw Board Ass'y (Smk-6166A-U2)
PD-35D30ES DISPLAY INTERFACE PW BOARD ASS’Y Ref No. Part No. Part Name Description Local (SSB-7367A-U2) R6574 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J Ref No. Part No. Part Name Description Local R6575 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R6576 NRSA63J-183X MG RESISTOR 18kΩ...
Page 116 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C409 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z R320 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J C410 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z R321 NRSA63J-0R0X MG RESISTOR 0Ω...
Page 117: Pdp Power Pw Board Ass'y (Smk-9067A-U2)
PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R809 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R914 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R810 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R915 NRSA63J-103X MG RESISTOR 10kΩ...
Page 118 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local Q601 2SB709A/QR/-X TRANSISTOR PC123FY2 PHOTO COUPLER PC602 Q602 2SD601A/QR/-X TRANSISTOR PC701 PC123FY2 PHOTO COUPLER Q603 2SD601A/QR/-X TRANSISTOR PC702 PC123FY2 PHOTO COUPLER Q605 2SK2470-01MR-F1 POWER MOS FET...
Page 119 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R108 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R607 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R109 QRZ9017-220 FUSI RESISTOR 22Ω 1/4W J R608 NRSA63J-102X MG RESISTOR 1kΩ...
Page 120: System Power Pw Board Ass'y (Smk-9166A-U2)
PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local K604 QQR0621-002Z FERRITE BEADS R9228 QRT029J-R22 MF RESISTOR 0.22Ω 2W J K605 QQR0621-002Z FERRITE BEADS R9229 QRK126J-221X UNF C RESISTOR 220Ω 1/2W J...
Page 121: Display Switch Pw Board Ass'y (Smk0L366A-U2)
PD-35D30ES Ref No. Part No. Part Name Description Local R1744 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1748 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1750 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J R1752 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1753 NRSA63J-104X MG RESISTOR 100kΩ...
Page 122: [Receiver Unit : Tu-35D30Es]
PD-35D30ES [RECEIVER UNIT : TU-35D30ES] EXPLODED VIEW PARTS LIST  Ref.No. Part No. Part Name Description Local LC11331-004A TOP COVER  CM43096-002 SPECIAL SCREW (x4) QYSBSG3008N TAP SCREW 3mm x 8mm(x3) QYSBSF3010M TAP SCREW 3mm x 10mm QYSDSG3008N TAPPING SCREW...
Page 123: Exploded View
PD-35D30ES EXPLODED VIEW SUPPORT BRACKET MI-COM PWB PB HOLDER DIST PWB MI-COM INTERFACE DIST RELAY PWB AV JACK PWB SUB TUNER MI-COM HOLDER AV SW PWB TERMINAL BRACKET RECEIVER POWER PWB MAIN PWB FRONT CONTROL FRONT PANEL(BACK SIDE) (No.52091)3-15...
Page 124: Printed Wiring Board Parts List
PD-35D30ES PRINTED WIRING BOARD PARTS LIST MAIN PW BOARD ASS’Y (SMK-1301A-U2) Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C202 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C203 QETN1CM-107Z E CAPACITOR 100uF 16V M...
Page 125: Front Control Pw Board Ass'y (Smk-8301A-U2)
PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R706 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J HS904 CM42862-A0A HEAT SINK ASSY R711 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J HS913 CEHT11B-002QS HEAT SINK...
Page 126: Mi-Com Pw Board Ass'y (Smk0M301A-U2)
PD-35D30ES MI-COM PW BOARD ASS’Y (SMK0M301A-U2) Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local D9954 NJM431L-T D9971 MA111-X SI DIODE IC001 SDA6000-B12 IC002 S-80828CNNB-W PC123FY2 PHOTO COUPLER PC9901 IC003 K4S641632F-TC75 IC(DIGITAL) QFZ9075-104 MPP CAPACITOR 0.1uF AC275V M...
Page 127 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C063 NDC31HJ-820X C CAPACITOR 82pF 50V J R109 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C064 NDC31HJ-820X C CAPACITOR 82pF 50V J R110 NRSA63J-102X MG RESISTOR 1kΩ...
Page 128: Mi-Com Interface Pw Board Ass'y (Smk0M311A-U2)
PD-35D30ES MI-COM INTERFACE PW BOARD ASS’Y Ref No. Part No. Part Name Description Local (SMK0M311A-U2) C321 QETN1HM-106Z E CAPACITOR 10uF 50V M Ref No. Part No. Part Name Description Local C341 NCB31HK-152X C CAPACITOR 1500pF 50V K C342 NCB31HK-152X C CAPACITOR...
Page 129 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C105 QETN1CM-477Z E CAPACITOR 470uF 16V M C606 QETN1HM-106Z E CAPACITOR 10uF 50V M C115 QETN1CM-477Z E CAPACITOR 470uF 16V M C607 NCF31AZ-105X...
Page 130 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R194 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R631 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R201 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R632 NRSA63J-103X MG RESISTOR 10kΩ...
Page 131: Dist Relay Pw Board Ass'y (Smk0Z311A-U2)
PD-35D30ES DIST RELAY PW BOARD ASS’Y (SMK0Z311A-U2) Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local Q859 2SC2412K/QR/-X TRANSISTOR Q860 2SA1037AK/QR/-X TRANSISTOR CN015 QGC2507C1-96 CONNECTOR (1-96) Q862 2SC2412K/QR/-X TRANSISTOR Q863 2SC2412K/QR/-X TRANSISTOR Q864...
Page 132 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C406 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C712 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C431 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C713 NEH71CM-476X...
Page 133 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C851 NDC31HJ-560X C CAPACITOR 56pF 50V J CB027 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C852 NDC31HJ-560X C CAPACITOR 56pF 50V J CB028 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z...
Page 134 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local CB314 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z CB607 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z CB315 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z CB608 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z...
Page 135 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R501 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R785 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R503 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R786 NRSA63J-562X MG RESISTOR 5.6kΩ...
Page 136 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R946 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB023 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R964 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J RB024 NRSA63J-102X MG RESISTOR 1kΩ...
Page 137 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local RB249 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J RB422 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J RB250 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J RB424 NRSA63J-103X MG RESISTOR 10kΩ...
Page 138 PD-35D30ES Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local L761 NQL034K-220X P COIL 22uH K LC601 NQR0415-005X EMI FILTER 0.1uF 25V M L762 NQL034K-101X P COIL 100uH K X101 NAX0539-001X 10.000MHz L763...
Page 139: Packing Parts List
PD-35D30ES PACKING PARTS LIST  Ref.No. Part No. Part Name Description Local AEM1088-001A-U PACKING CASE(TOP) AEM3343-001A-U TOP LAYER AEM1083-001A-U PACKING CASE(BASE) AEM3339-001B-U LAYER PAD AEM1086-001A-U CUSHION ASSY(TOP) 3pcs in 1set AEM1067-001A-E FOAM BAG LC41035-002A POLY BAG (x2) AEM3341-001A-U SEPARATOR (x3)
Page 140: Packing
PD-35D30ES PACKING 22 23 24 40 41 47 48 RECEIVER UNIT 3-32(No.52091)
Page 141 ENGLISH DEUTSCH FRANÇAIS NEDERLANDS CASTELLANO ITALIANO PORTUGUÊS PD-42D30ES PD-35D30ES PDP COLOUR TELEVISION INSTRUCTIONS PDP FARBFERNSEHGERÄT BEDIENUNGSANLEITUNG PDP TELEVISEUR COULEUR MANUEL D’INSTRUCTIONS PDP KLEURENTELEVISIE GEBRUIKSAANWIJZING PDP TELEVISOR A COLOR MANUAL DE INSTRUCCIONES PDP TELEVISORE A COLORI ISTRUZIONI PDP TELEVISOR A CORES...
Page 142 Warning DO NOT cut off the mains plug from this equipment. If As these colours may not correspond with the coloured the plug fitted is not suitable for the power points in your marking identifying the terminals in your plug proceed as home or the cable is too short to reach a power point, then follows: obtain an appropriate safety approved extension lead or...
Page 143 Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Page 144 Burn-in A characteristic of Plasma Display Panels (PDPs) is that displaying the same image for a long time causes a part of the image to stay on the screen (this is called phosphor burn-in). Avoid burn-in as follows. Do not display static images or characters for long periods of time. While an image is displayed With power OFF 19:03...
Page 145 Point defects PDPs use collections of fine pixels to display images. While there is no problem with more than 99.99% of these pixels, please understand that a very small number of pixels may not light or may light all the time. Do not install the TV near electronic equipment that is affected by electromagnetic waves It may cause interference in images, sound, etc.
Page 146 Using the PIP function ........20 Changing the COUNTRY setting ....40 Using the MULTI-PICTURE function ....21 Using the DECODER (EXT-2) function... 40 Operating a JVC brand VCR or DVD player ..21 Additional preparation......41 Teletext function........22 Connecting external equipment ...... 41 Basic operation ..........22...
Page 147: Checking Contents Of Packages
Power cord Speakers Speaker cord (for front speakers) × 2 Speaker cord (for subwoofer) × 1 Left and right front speakers Subwoofer Mounting screw × 6 Rubber foot for subwoofer × 4 Cord clamp × 3 (DD speakers) (only for PD-35D30ES)
Page 148: Setting Up Your Tv
Philips screwdriver. approximately 3 mm. speaker downwards. <PD-35D30ES> 2 Attach the front speakers to 3 Lock the front speakers in 1 Attach the speaker mounting screws to the back of the TV...
Page 149: Installation
Setting up your TV Preparing the subwoofer Either stand the subwoofer vertically or lay it down on its side, peel the Subwoofer paper from the supplied rubber feet, and stick the feet in the four corners on the surface to be used as the base. The rubber feet prevent slipping and resonance, and also protect the speaker cord.
Page 150: Connections
Connections Caution • Turn off all the equipment including the TV before connecting anything. Connection diagram <PD-42D30ES> AC INPUT 110-240V Cable supplied with TV • Refer to page 13 for connection details. TV (back) Right front Left front speaker speaker DISPLAY INPUT CONNECT TO SYSTEM CABLE FRONT...
Page 151 Connections <PD-35D30ES> AC INPUT 110-240V Cable supplied with TV • Refer to page 13 for connection details. Left front speaker TV (back) Right front speaker DISPLAY INPUT CONNECT TO SYSTEM CABLE DISPLAY INPUT CONNECT TO SYSTEM CABLE AC INPUT 110-240V...
Page 152: Connecting The Front Speakers And Subwoofer
Connections Connecting the front speakers and subwoofer Use the supplied speaker cords to connect the speakers to the speaker terminals at the back of the TV. Connecting the speaker cord to the front speaker terminal Connect using the supplied front speaker cords. 1 Press the spring-loaded speaker input terminal 2 Press the core of the cord into the terminal and lever in the direction of the arrow...
Page 153: Connecting The Tv And Receiver
Press connector 2 firmly into place until it is locked. <PD-42D30ES> <PD-35D30ES> Disconnecting the system cable Release connector 1 by unscrewing the screws at left and right and removing it from the socket. Release connector 2 by removing it from the socket while pressing the release bottoms on either side.
Page 154: Recorder (Vcr)
Connections Connecting the aerial and video Aerial cassette recorder (VCR) 75-ohm Coaxial Cable • The connecting cables are not provided. Back of the receiver • For further details, refer to the manuals provided with the devices to be connected. EXT- EXT- If you are connecting a VCR, follow A A A A →...
Page 155: Connecting The Power Cord To The Ac Outlet
Connections Receiver rear Connecting the power cord to the AC outlet Insert the AC plugs on the power cords from the TV and receiver into AC outlets. Caution DISPLAY OUT EXT- EXT- • Operate only from the power source specified (AC 110 EXT- –...
Page 156: Initial Settings
(Standby) button again to turn your TV on. registration of all the TV channels quickly. For details of • If the JVC logo does not appear this is because your the ACI function and how to use it, see “Using the ACI TV has already been turned on for the first time: function”...
Page 157: T-V Link Functions
AC outlets. To use T-V LINK functions: A “T-V LINK compatible VCR” means a JVC video cassette recorder with the T-V LINK logo, or with one of the following logos. However, these VCRs may support some or all of the features described earlier.
Page 158: Tv Buttons And Functions
• Check that the AC plugs on the power cords from the TV and receiver are connected correctly to AC outlets. <PD-35D30ES> Choose a TV channel Press the P p p buttons to choose a programme...
Page 159: Remote Control Buttons And Functions
Remote control buttons and functions 1 Muting button 2 Number buttons 3 c button 4 3 sound button 5 Information button 6 b button 7 5 buttons 8 Standby button 9 Colour buttons 0 a button - 6 buttons = VCR/DVD/Teletext control button ~ VCR P DVD switch ! g (Text) button @ P button...
Page 160: Adjust The Volume
Remote control buttons and functions Use the PR LIST: Use the PR LIST: 1 Press the h h (information) button to display the 1 Press the h h (information) button to display the PR LIST PR LIST Pressing the h (information) button changes the display 2 Press the 5 5 and 6 6 buttons to choose an...
Page 161: Zoom Function
Remote control buttons and functions Choose the ZOOM mode ZOOM function 1 Press the c c button to display the ZOOM You can change the screen size according to the picture menu aspect ratio. Choose the optimum one from the following ZOOM modes.
Page 162: Displaying The Current Time
Remote control buttons and functions Displaying the current time Using the PIP function You can display the current time on the screen. You can view two pictures (Main-picture and sub-picture). Two different TV programmes can be watched at the same Press the h h (information) button to display the time, or a TV programme and a video programme from an...
Page 163: Using The Multi-Picture Function
2 Press the VCR/DVD control button to control your VCR or DVD player Using the MULTI-PICTURE function • If your device is not made by JVC, these buttons will not work. You can display multi-pictures so you can find a program •...
Page 164: Teletext Function
Teletext function Using the List Mode You can store the numbers of your favourite teletext pages MENU in memory and call them up quickly using the colour buttons. To store the page numbers: 1 Press B B button to go into the List mode The page numbers you have stored are displayed at the bottom of the screen.
Page 165: Sub-Page
Teletext function Sub-page Cancel Some teletext pages include sub-pages that are You can search for a teletext page while watching TV. automatically displayed. 1 Press the number button to enter a page You can hold any sub-page, or view it at any time. number, or press a colour button 1 Press the D D (Sub-page) button to operate the...
Page 166: Using The Tv's Menu
Using the TV’s menu This TV has a number of functions you can operate using 5 Press the a a button to complete the setting menus. To use all your TV’s functions, you need to The menu disappears. understand the basic menu operating techniques fully. •...
Page 167: Picture Setting
PICTURE SETTING Refer to “Using the TV’s menu” (see page 24) for details of COLOUR TEMP. displaying the menu. You can select one of three COLOUR TEMP. modes (three tones of white) to adjust the white balance of the picture. PICTURE SETTING Since white is the colour which is used as a reference for all PICTURE MODE...
Page 168: Picture Features
PICTURE FEATURES Refer to “Using the TV’s menu” (see page 24) for details of Super DigiPure displaying the menu. The Super DigiPure function uses the latest in digital PICTURE FEATURES technology to give you a natural-looking picture. The Super DigiPure function includes the following two functions. DIGITAL VNR AUTO Super DigiPure...
Page 169: Colour System
PICTURE FEATURES COLOUR SYSTEM MOVIE THEATRE The colour system is chosen automatically. However, if the The MOVIE THEATRE function displays a cinema film picture is not clear or no colour appears, choose the colour picture more smoothly and naturally on the screen. system manually.
Page 170: Pip (Picture-In-Picture)
PICTURE FEATURES PIP (picture-in-picture) PIP POSITION: You can choose one of four positions for the sub-picture. 1 Press the 6 6 buttons to choose PIP. Then press the a a button The PIP menu appears. PIP POSITION MULTI-PICTURE BACK D0061-EN 2 Press the 6 6 buttons to choose PIP POSITION 3 Press the 5...
Page 171: Sound Setting
SOUND SETTING Refer to “Using the TV’s menu” (see page 24) for details of SPEAKER displaying the menu. You can turn off the sound from the TV speakers; but you SOUND SETTING should only do this if you have connected an audio system STEREO/ to the TV instead of the TV speakers.
Page 172: Headphone
SOUND SETTING HEADPHONE You need to use the HEADPHONE menu to adjust the volume of the headphones. The HEADPHONE menu can also be used to set whether or not sound comes from the TV speakers when the headphones are being used and to perform the settings for the sound coming from the headphones.
Page 173: Ext Setting
EXT SETTING Refer to “Using the TV’s menu” (see page 24) for details of LIST displaying the menu. You can store a name for each of the devices connected to EXT SETTING each EXT terminal. Giving a name to an EXT terminal EXT-1 makes the EXT terminal number appear on the screen, DUBBING...
Page 174 EXT SETTING 2 Press the 6 6 buttons to choose an EXT terminal or TV. Then press the a a button The arrow in the menu represents a signal flow. The left side of the arrow shows a signal source output from the EXT-2 terminal.
Page 175: Features
FEATURES To set the CHILD LOCK function Refer to “Using the TV’s menu” (see page 24) for details of displaying the menu. 1 Choose CHILD LOCK, then press the o button FEATURES “SET ID NO.” (ID number setting screen) appears. SLEEP TIMER BLUE BACK CHILD LOCK...
Page 176: Decoder (Ext-2)
FEATURES 3 Press the number buttons to enter the ID number The lock is temporarily released so you can view the TV channel. If you have forgotten the ID number: Perform step 1 of “To set the CHILD LOCK function”. After confirming the ID number, press the b button to exit the menu.
Page 177: Install
INSTALL Refer to “Using the TV’s menu” (see page 24) for details of • You can now edit the programme numbers (PR) displaying the menu. using the EDIT/MANUAL function. For details, see “EDIT/MANUAL” on page 36. • If you do not need to use the EDIT/MANUAL INSTALL function, go to the next step.
Page 178: Edit/Manual
INSTALL 3 Press the a a button to complete the settings EDIT/MANUAL The T-V LINK menu appears. The EDIT/MANUAL functions are divided into two types: • editing the current programme numbers (PR) (EDIT T-V LINK functions); and DOWNLOAD • manually storing a TV channel you want to view on a BACK particular programme number (PR) (MANUAL function).
Page 179 INSTALL INSERT Preparation: 1 Press the 6 6 buttons to choose a TV channel • A CH/CC number unique to this TV and corresponding Every time you press the 6 buttons, the programme to the Channel number of a TV channel is required. Find number (PR) changes and the picture of the TV channel the corresponding CH/CC number from a table “CH/CC stored in the programme number (PR) appears on the...
Page 180 INSTALL DELETE 4 Press the green or red button to search for a TV channel 1 Press the 6 6 buttons to choose a TV channel Scanning stops when the TV finds a TV channel. Then Every time you press the 6 buttons, the programme the TV channel is displayed.
Page 181: Additional Menu Operations
Additional menu operations Using the ACI function Downloading data to a VCR This TV has an ACI function which decodes the ACI You can send the latest programme numbers (PR) data to a (Automatic Channel Installation) data. VCR with the T-V LINK function. Using the ACI function allows all TV channels transmitted •...
Page 182: Changing The Country Setting
Additional menu operations Changing the COUNTRY setting Using the DECODER (EXT-2) function After the AUTO PROGRAM function is completed, you If you have a decoder connected to a T-V LINK compatible can change the country you have already set by using the VCR, which in turn is connected to the EXT-2 terminal, use AUTO PROGRAM function.
Page 183: Additional Preparation
Additional preparation Connecting external equipment Connect the equipment to the TV, making the correct rear 1 VCR (composite signal) panel and front panel connections. 2 VCR (composite signal/S-VIDEO signal) 3 T-V LINK compatible VCR (composite signal/S-VIDEO Before connecting anything: signal) •...
Page 184: Connecting Headphones
Additional preparation Equipment which can output the S-VIDEO Connecting Speakers/Amplifier signal (Y/C signal) such as an S-VHS VCR See the Audio equipment connection diagram, then connect the audio equipment you desire to the TV. Connect the equipment to an EXT terminal (but not the You can use external front speakers to listen to the TV EXT-1 terminal).
Page 185: Ch/Cc Numbers
CH/CC numbers When you want to use the INSERT function on page 37, find the CH/CC number corresponding to the Channel number of the TV channel from this table. Channel Channel Channel Channel CH 02 / CH 202 E2, R1, IR A CH 40 / CH 240 E40, R40 CC 01 / CC 201...
Page 186: Troubleshooting
Troubleshooting If a problem arises while you are using the TV, please read this troubleshooting guide carefully before you ask to have the TV repaired. You may be able to fix it easily by yourself. For example, if the mains plug is disconnected from the mains outlet, or the TV aerial has problems, you may think there is a problem with the TV itself.
Page 187: Other Issues
Troubleshooting Other issues • When the SLEEP TIMER function operates, the TV is automatically turned off. If the TV suddenly turns off, try to press the # (standby) button to turn on the TV once again. If the TV goes back to normal, there is no problem.
Page 188: Specifications
Specifications Model PD-42D30ES PD-35D30ES Item Broadcasting systems CCIR B/G, I, D/K, L Colour systems PAL, SECAM • The EXT terminals also support the NTSC 3.58/4.43 MHz system. Channels and frequencies • E2-E12, E21-E69, S1-S41, X, Y, Z, Z+1, Z+2, ITALY A-H, ITALY H+1, ITALY H+2, F2-F10, F21-F69, R1-R12, R21-R69, IR A-J •...

JVC PD-35D30ES Service Manual

Service Manual

Table of Contents

Using P.w. Board

Semiconductor Shapes

Block Diagram - 1

Block Diagram - 2

Circuit Diagrams [Receiver Unit] Main Pwb Circuit Diagram

Circuit Diagrams [Display Unit]

Pattern Diagrams [Receiver Unit] Receiver Power Pwb Pattern

Pattern Diagrams [Display Unit]

Voltage Chart [Receiver Unit]

Voltage Chart [Display Unit]

Waveforms

Table of Contents

Table of Contents

Checking Contents of Packages

Setting up Your TV

Connections

Initial Settings

TV Buttons and Functions

Remote Control Buttons and Functions

Teletext Function

Using the Tv's Menu

Picture Setting

Picture Features

Sound Setting

Ext Setting

Features

Install

Additional Menu Operations

Additional Preparation

CH/CC Numbers

Troubleshooting

Specifications

Quick Links

Chapters

Troubleshooting

Related Manuals for JVC PD-35D30ES

Summary of Contents for JVC PD-35D30ES

Table of Contents
