OFF MODE

This function allows the monitor to enter into a power saving mode after a period of inactivity.
The OFF MODE has two settings.
OFF: Monitor does not go into power save mode when the input signal is lost.
STANDARD: Monitor enters power save mode automatically when the input signal is lost.
UNIFORMITY
This function electronically compensates for the slight variations in the white uniformity level, as well as for
deviations in color that may occur throughout the display area of the screen. These variations are characteristic of
LCD panel technology. This function improves the color* and evens out the luminance uniformity of the display.
NOTE: Using the UNIFORMITY feature reduces the overall peak luminance of the display. If greater luminance is
desired over the uniform performance of the display, then UNIFORMITY should be turned off.
After changing UNIFORMITY setting, please execute "Self Calibration" and "Gamma Adjust".
*: MD212MC/MD213MC only.

MENU Tools

LANGUAGE
OSD control menus are available in eight languages.
OSD LEFT/RIGHT
You can choose where you would like the OSD control image to appear on your screen. Selecting OSD Location
allows you to manually adjust the position of the OSD control menu left or right.
OSD DOWN/UP
You can choose where you would like the OSD control image to appear on your screen. Selecting OSD Location
allows you to manually adjust the position of the OSD control menu Up or Down.
OSD TURN OFF
The OSD control menu will stay on as long as it is use. You can select how long the monitor waits after the last touch
of a button to shut off the OSD control menu. The preset choices are 10-120 seconds by 5-second increments.
OSD LOCK OUT
This control completely locks out access to all OSD control functions. When attempting to activate OSD controls
while in the Lock Out mode, a screen will appear indicating the OSD controls are locked out.
There are three types of OSD LOCK OUT:
OSD LOCK OUT with no control: To activate the OSD Lock Out function, press SELECT, then the "Right" button and
hold down simultaneously. To deactivate the OSD Lock Out, press SELECT, then the "Right" button and hold down
simultaneously while in the OSD menu. No controls can be adjusted while in this lock out mode.
OSD LOCK OUT with LUMINANCE (only) control: To activate the OSD Lock Out function, press SELECT, then the
"Down" and "Left" buttons and hold down simultaneously. To deactivate the OSD Lock Out, press SELECT, then the
"Down" and "Left" buttons and hold down simultaneously while in the OSD menu. Only the LUMINANCE can be
adjusted while in this lock out mode.
CUSTOM: Refer to the Advanced OSD Menu.

OSD ROTATION

Determines the OSD display direction.
AUTO: The OSD rotates automatically when the monitor is rotated.
LANDSCAPE: Show the OSD in landscape mode.
PORTRAIT: Show the OSD in portrait mode.
OSD COLOR (Only for MD212MC/MD213MC)
"Tag window frame color", "Item select color" and "Adjust window frame color" can be changed to Red, Green, Blue,
or Gray.
RESOLUTION NOTIFIER
The optimal resolution is 1200 x 1600 (in Portrait mode) or 1600 x 1200 (in Landscape mode) for MD212MC and
1536 x 2048 (in Portrait mode) or 2048 x 1536 (in Landscape mode) for MD213MC/MD213MG. If ON is selected,
a message will appear on the screen after 30 seconds, notifying you that the resolution is not at 1200 x 1600
(in Portrait mode) or 1600 x 1200 (in Landscape mode) for MD212MC and 1536 x 2048 (in Portrait mode) or
2048 x 1536 (in Landscape mode) for MD213MC/MD213MG.
