NEC MultiSync LCD225WNXM User Manual page 8

Controls
OSD (On-Screen-Display) control buttons on the front of the monitor
function as follows:
1. Basic function at pressing each key
Button
At No OSD
Showing OSD.
showing
At OSD showing
Go to Adjustment stage.
(Icon selection stage)
At OSD showing Go to Icon selection stage.
(Adjustment stage)
2. OSD structure
Main Menu (Icon Select, Analog Input)
Press
"SELECT"
key
Example Tool:
Press
"SELECT" key
Sub Menu (Icon Select)
SELECT
Shortcut to Brightness
adjust Menu.
Cursor goes to left.
Adjust value decrease or
Cursor for adjust goes to left.
Press
"–" or "+"
Sub Menu (Adjust)
– +
Shortcut to Volume adjust
Menu.
Cursor goes to right.
Adjust value increase or
Cursor for adjust goes to
right.
Main Menu (Adjust)
Press
"SELECT"
key
Press "SELECT" key
Press "SELECT" key
Press
"–" or "+"
Press
"SELECT" key
Adjust by using
"–" or "+"
English-7
1<->2 / RESET
Input signal select.
Reset operation.
Mute off/on switch on Volume
adjustment Menu.
Adjust by using
"–" or "+"
