Specifications - LCD225WNXM
Monitor Specifications
LCD Module
Native Resolution (Pixel Count): 1680 x 1050
Input Signal PC INPUT: Video: ANALOG 0.7 Vp-p/75 Ohms
AUDIO INPUT: STEREO Mini Jack
Head Phone Output
Display Colors Analog input: 16,777,216
Synchronization Range Horizontal: 31.5 kHz to 81.1 kHz
Viewing Angle
Resolutions Supported
Active Display Area Horizontal: 473.8 mm/18.7 inches
Speakers Practical Audio Output: 1.0 W + 1.0 W
USB Hub
Load Current: Maximum 0.5 A per port
Power Supply
Power Consumption
Dimensions
Weight with stand: 9.3 kg/20.5 lbs.
without stand: 6.3 kg/13.9 lbs.
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Storage Temperature: -10°C to +60°C/14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD225WNXM Monitor
Diagonal: 55.9 cm/22.0 inches
Sync: Separate sync.TTL Level (Positive/Negative)
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
500mV rms Input Impedance 20 Kohm
STEREO Mini Jack
Headphone Impedance 32 Ohm
Vertical: 56 Hz to 75 Hz
Left/Right: -80°/+80° (CR>10), -88°/+88° (CR>5)
Up/Down: -80°/+80° (CR>10), -88°/+88° (CR>5)
1
720 x 400* @ 70 Hz
640 x 480* 1 @ 60 Hz to 75
800 x 600* 1 @ 56 Hz to 75 Hz
832 x 624* 1 @ 75 Hz
1
1024 x 768* @ 60 Hz to 75Hz
1280 x 768* 1 @ 60 Hz
1152 x 864* 1 @ 75 Hz
1152 x 870* 1 @ 75 Hz
1
1280 x 960* @ 60 Hz to 75Hz
1280 x 1024* 1 @ 60 Hz to 75Hz
1360 x 768* 1 @ 60 Hz
1400 x 1050* 1 @ 60 Hz to 75Hz
1
1440 x 900* @ 60 Hz to 75 Hz
1680 x 1050 @ 60 Hz................................. optimal display performance.
Vertical: 296.1 mm/11.7 inches
I/P: USB Specification Revision 2.0
Port: Upstream 1
Downstream 4
100 - 240 V ~ 50/60 Hz
60 W
505.7 mm (W) x 391.3 - 501.3 mm (H) x 245.0 mm (D) (with stand)
19.9 inches (W) x 15.4 - 19.7 inches (H) x 9.6 inches (D)
505.7 mm (W) x 344.1 mm (H) x 76.7 mm (D) (without stand)
19.9 inches (W) x 13.5 inches (H) x 3.0 inches (D)
Humidity: 30% to 80%
Altitude: 0 to 3,048 m/0 to 10,000 Feet
Humidity: 10% to 85%
Altitude: 0 to 12,192 m/0 to 40,000 Feet
Notes
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.282 mm dot
pitch; 300 cd/m
1000:1 (Typ) contrast ratio, typical;
response time: 5 ms (Typ).
Digital Input: DVI-D
Depends on display card used.
Automatically
Automatically
Some systems may not
support all modes listed.
Recommended resolution is 60 Hz for
English-13
2
(Typ) white luminance,
