Specifications for MultiSync LCD195VXM+
Monitor Specifications
LCD Module
Viewable Image Size: 48 cm/19 inches
Native Resolution (Pixel Count): 1280 x 1024
Input Signal
Display Colours
Synchronization Range
Viewing Angle
Resolutions Supported
Active Display Area
Speakers Practical Audio Output: 1.0 W + 1.0 W
Power Supply
Power Consumption
Dimensions
Weight
Environmental Considerations
Operating Temperature: 5 °C to 35 °C
Storage Temperature: -10 °C to +60 °C
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 LCD Module at 25°C.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD195VXM+ Monitor
Diagonal: 48 cm/19 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level (Positive/Negative)
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Analog input: 16,7 M
Horizontal: 31.5 kHz to 81.1 kHz
Vertical: 56 Hz to 76 Hz
Left/Right: -80°/+80° (CR>10), -88°/+88° (CR>5)
Up/Down: -75°/+85° (CR>10), -85°/+85° (CR>5)
Landscape: 720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 864*
1152 x 870*
1280 x 960*
1280 x 1024 @ 60 Hz to 75 Hz................... optimal display performance.
Horizontal: 376.3 mm
Vertical: 301.1 mm
100 - 240 V ~ 50/60 Hz
40 W
Landscape: 405.5 mm (W) x 385.8 - 435.8 mm (H) x 240.0 mm (D) (with stand)
405.5 mm (W) x 345.5 mm (H) x 66.5 mm (D) (without stand)
with stand: 6.0 kg
without stand: 5.0 kg
Humidity: 30% to 80%
Altitude: 0 to 3,048 m
Humidity: 10% to 85%
Altitude: 0 to 12,192 m
1 : VGA
1
@ 60 Hz to 75 Hz
1
@ 56 Hz to 75 Hz
1
@ 75 Hz
1 @ 60 Hz to 75 Hz
1 @ 70 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
English-12
Notes
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.294 mm dot
pitch; 300 cd/m 2 * 2 white luminance,
800:1 contrast ratio, typical;
response time: 5 ms.
Digital Input: DVI-D
Depends on display card used.
Automatically
Automatically
Some systems may not
support all modes listed.
Recommended resolution is 60 Hz for
