Specifications for MultiSync LCD175VXM+
Monitor Specifications
LCD Module
Viewable Image Size: 43 cm/17 inches
Native Resolution (Pixel Count): 1280 x 1024
Input Signal
Display Colours Analog input: 16,7 M
Synchronization Range Horizontal: 31.5 kHz to 81.1 kHz
Viewing Angle
Resolutions Supported Landscape: 720 x 400*
Active Display Area Horizontal: 337.9 mm
Speakers Practical Audio Output: 1.0 W + 1.0 W
Power Supply
Power Consumption
Dimensions Landscape: 368.0 mm (W) x 358.5 - 408.5 mm (H) x 230.0 mm (D) (with stand)
Weight
without stand: 3.8 kg
Environmental Considerations
Operating Temperature: 5 °C to 35 °C
Storage Temperature: -10 °C to +60 °C
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 LCD Module at 25°C.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD175VXM+ Monitor
Diagonal: 43 cm/17 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level (Positive/Negative)
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Vertical: 56 Hz to 76 Hz
Left/Right: -80°/+80° (CR>10), -88°/+88° (CR>5)
Up/Down: -75°/+85° (CR>10), -85°/+85° (CR>5)
1
: VGA
1
640 x 480* @ 60 Hz to 75 Hz
800 x 600* 1 @ 56 Hz to 75 Hz
832 x 624* 1 @ 75 Hz
1024 x 768* 1 @ 60 Hz to 75 Hz
1152 x 864* 1 @ 70 Hz to 75 Hz
1
1152 x 870* @ 75 Hz
1
1280 x 960* @ 60 Hz to 75 Hz
1280 x 1024 @ 60 Hz to 75 Hz................... optimal display performance.
Vertical: 270.3 mm
100 - 240 V ~ 50/60 Hz
34 W
368.0 mm (W) x 320.5 mm (H) x 61.0 mm (D) (without stand)
with stand: 4.8 kg
Humidity: 30% to 80%
Altitude: 0 to 3,048 m
Humidity: 10% to 85%
Altitude: 0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.264 mm dot
pitch; 300 cd/m
contrast ratio, typical; response time: 5 ms.
Digital Input: DVI-D
Depends on display card used.
Automatically
Automatically
Some systems may not
support all modes listed.
Recommended resolution is 60 Hz for
English-11
2 * 2 white luminance, 700:1
