Velleman K8049 Illustrated Assembly Manual
Velleman K8049 Illustrated Assembly Manual

Velleman K8049 Illustrated Assembly Manual

15-channel ir transmitter

Advertisement

Quick Links

15 Channel IR transmitter
Total solder points: 53
3 ⌧ 4
Difficulty level: beginner 1
2
5
advanced
K8049
K8049
ILLUSTRATED ASSEMBLY MANUAL
H8049IP-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the K8049 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Velleman K8049

  • Page 1 15 Channel IR transmitter Total solder points: 53 3 ⌧ 4 Difficulty level: beginner 1 advanced K8049 K8049 ILLUSTRATED ASSEMBLY MANUAL H8049IP-1...
  • Page 2 Features & specifications Features: Works together with K6711, K6712, K6713, K8046, K8050, K4100, K4500, MK161, MK163, MK164, … 4 addresses allow the use of multiple receivers in one room Ergonomic design for extra comfort. LED function indication. Rubber keypad Specifications: •...
  • Page 3 Assembly hints 1. Assembly (Skipping this can lead to troubles ! ) Ok, so we have your attention. These hints will help you to make this project successful. Read them carefully. 1.1 Make sure you have the right tools: • A good quality soldering iron (25-40W) with a small tip.
  • Page 4 Assembly hints 1.3 Soldering Hints : 1- Mount the component against the PCB surface and carefully solder the leads 2- Make sure the solder joints are cone-shaped and shiny 3- Trim excess leads as close as possible to the solder joint REMOVE THEM FROM THE TAPE ONE AT A TIME ! AXIAL COMPONENTS ARE TAPED IN THE CORRECT MOUNTING SEQUENCE !
  • Page 5 Construction 1. Jumpers 5. LEDs. Watch the polarity! LD2 : 3mm RED First : Bend the leads exactly like the drawing. (Fig 1.0) FIG. 1.0 2. 1/8W Resistors Next : Mount this LED like in the drawing (fig. 2.0). Solder one lead, check the position, if necessary correct it by heating the soldering.
  • Page 6 Construction 7. Transistor : BC639 Attention : Mount the transistor on the solder side! FIG. 5.0 Now bend the transistor towards the pcb, away from the IR & 3mm LED. Make sure the transistor connections do not contact any other parts of the circuit.
  • Page 7 Construction Now place the battery contacts into the housing on their right places. Positive battery lip Common battery lip Common battery lip Negative battery lip FIG. 8.0 Connect now the wire that you earlier have mount to the negative battery lip. Negative battery lip Positive battery lip Connect a jumper between the positive battery lip and positive connection on the pcb.
  • Page 8 Assembly 10. Assembly First bend the battery lips over before closing the enclosure. Close the enclosure with the supplied screws. FIG. 9.0...
  • Page 9 Keyboard layout 11. Keyboard Layout SHIFT Mute Power Volume up Preset up Volume down Preset down Source Tuner seek Insert the batteries in the battery compartment as indicated in fig. 10 and close the compartment. Remark : Respect your national FIG.
  • Page 10 Mode selection & Use 12. Mode selection At first power up, mode 1 is automatically selected. Press and hold SHIFT to change mode. Led starts flashing. Press button 1..8 to select desired mode as shown below. Hint : When the batteries are inserted, the led flashes 1..4 times indicating the selected mode. Description 'K6710 emulation with D4 mounted'- mode.
  • Page 11 14. PCB layout.
  • Page 12 VELLEMAN KIT NV Legen Heirweg 33 9890 Gavere Belgium Europe Info ?: http://www.velleman.be Modifications and typographical errors reserved © Velleman Kit nv H8049IP - 2003 - ED2 5 4 1 0 3 2 9 2 9 1 9 8 3...
