REF. CONTROL/INDICATOR
1 LOAD Control
2 TUNE Control
3 Switch Board/
Meter Panel
4 ColorStat™ Panel
5 Driver Control Compartment
6 Center Control Compartment
7 Left Control Compartment
8 Output Network Compartment
Rev AA: 8/9/2000
Figure 3A-1. DX 25 Front View, Controls and Indicators
Table 3A-1. DX 25U Transmitter, Controls and Indicators
FUNCTION
Control for matching load to 50 Ohm transmitter impedance.
Control for matching load to 50 Ohm transmitter impedance.
See Table 3A-2 and Figure 3A-2.
See Table 3A-3 and Figure 3A-3.
888-2297-002
