Harris DX 25U Technical Manual page 109

839 7855 154 BTM CAP CONTACT PLT
839 7855 155 STRAP
839 7855 158 BTM CAP MTG PLATE
843 5100 079 CAP MTG PLATE
843 5100 080 TOP CONTACT PLT
843 5100 083 CAP MTG PLATE
843 5100 084 TOP CONTACT PLATE
922 0922 205 7 TURN RIBBON COIL
922 0922 215 STRAP, #2C2B
922 0999 210 GROUND STRAP, .5 X 12.0LG
939 7855 170 STRAP
939 8183 001 BTM CAP MTG PLATE
943 5100 100 PLATE, CAP MTG
943 5100 101 PLATE, TOP CONTACT
988 2297 001 DP DX-25U
989 0076 001 PKG CK LIST DX50
990 1090 002 R-SK-DX25U REC S/C KIT
992 7095 001 RF AMPLIFIER MODULE
994 9165 002 R-BK-DX25U REC BDS KIT
994 9166 002 R-PK-DX25U REC PTS KIT
994 9168 002 XMTR, BASIC DX 25U
994 9210 001 XFMR KIT,STEPDOWN 480/240
999 2622 001 HARDWARE LIST, DX50
HARRIS P/N DESCRIPTION
252 0002 000 WIRE, STRD 22AWG GRN
296 0260 000 TUBING, SHRINK 3/32 WHITE
296 0263 000 TUBING, SHRINK 3/8 WHITE
354 0287 000 LUG #10 RING N/INS 7-9AWG
354 0704 000 TERM, MALE FOR 18-22 AWG
382 1274 000 IC LM335AH ESD
610 0738 000 PLUG HOUSING
817 2099 017 ASSY INSTR, TEMP SENSOR
HARRIS P/N DESCRIPTION
324 0281 000 NUT, CAPTIVE 4-40
328 0071 000 WASHER, STEEL COMPRESSION
380 0653 000 XSTR, NPN MPS6602 ESD
380 0681 000 XSTR IRFP350 ESD
380 0708 000 XSTR MPS6652 40V 1A ESD
380 0712 000 XSTR, NPN 2N6718 ESD
384 0253 000 RECTIFIER 1N4007 ESD
384 0612 000 DIODE 1N3070 ESD
384 0661 000 LED, GRN, T 1-3/4, RT ANG ESD
384 0802 000 TRANSZORB, BIPOLAR 18V 5% ESD
384 0803 000 RECT MUR-110 100V ESD
384 0810 000 LED RED ESD
384 0817 000 RECT 1.7A 21DQ03 ESD
Rev.Y1: 5/24/1999
Table 7-2. TEMP SENSOR REPLACEMENT - 917 2099 017
Table 7-3. RF AMPLIFIER MODULE - 992 7095 001
WARNING: Disconnect primary power prior to servicing.
0.0 EA #2C1A/B (1#JKL)
0.0 EA 2C5 (1#FGHJKL)
0.0 EA #2C1A/B (1#ABCDE)
0.0 EA #2C1A/B (1#E)
0.0 EA #2C1A/B (1#E)
0.0 EA #2C1A/B (1#ABCD)
0.0 EA #2C1A/B (1#ABCD)
0.0 EA (#1FGHIJKL)
0.0 EA #2C2B (4#ABCDE) (6#FGHJKL)
0.0 EA #2C3A-L3 (2#ABCDE) (2
REQ'D)
0.0 EA 2L3-2C4A (1#ABCDE)
0.0 EA #2C1A/B (1#FGH)
0.0 EA #2C1A/B (1#FGH)
0.0 EA #2C1A/B (1#FGH)
1.0 EA
0.0 EA
0.0 EA
1.0 EA
0.0 EA
0.0 EA
1.0 EA
0.0 EA 3T001
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
1.50 FT
0.30 FT
0.20 FT
1.0 EA
3.0 EA
1.0 EA
1.0 EA
0.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
2.0 EA
4.0 EA #Q001 #Q002 #Q003 #Q004
2.0 EA Q007 Q008
8.0 EA Q001 Q002 Q003 Q004 Q009 Q010 Q011
Q012
2.0 EA Q005 Q006
2.0 EA Q013 Q014
2.0 EA CR011 CR012
2.0 EA CR014 CR015
1.0 EA DS003
4.0 EA CR001 CR002 CR003 CR004
4.0 EA CR007 CR008 CR009 CR010
2.0 EA DS001 DS002
2.0 EA CR005 CR006
888-2297-002
Section VII - Parts List
7-3
