Controls

1. Adjustment Control
and Volume Buttons
2. DC Power Switch/
DC Power-On Indicator
3. Function/Select Buttons
4. External Headphone Jack The monitor speakers will be disabled when using
5. Stereo Speakers
On-Screen Manager Menu
To access OSM main menu, simply press the Function Select (<) button. Continue
pressing the Function Select buttons (< or >) to scroll through the entire menu
items, then press Adjustment Control buttons to adjust content of selected item.
LCD35Seriesmanual071904.p65
Press the (-) button to decrease the OSM setting
and press the (+) button to increase the OSM
setting, when OSM menu is displaying. Press the (-)
or (+) button to decrease or increase the audio
volume when OSM menu is not displaying.
Press the power switch to switch the monitor ON/OFF.
LED light is blue - power is ON
LED light is amber - monitor is in "Power Saving Mode"
LED is off - power is OFF
Press either (< or >) control button to activate
the On-Screen Manager (OSM) menu selection.
an external headphone or external speakers.
PC Audio Stereo output.
