NEC MultiSync LCD1735NXM User Manual page 9

Controls
Brightness
Contrast
H. Position
V. Position
Sharpness
OSD Transparency To adjust the transparency of the OSD menu from 0 to 3.
Phase
Clock
Color Temperature
9300 CIE coordinated Color Temperature of 9300K
7500 CIE coordinated Color Temperature of 7500K
6500 CIE coordinated Color Temperature of 6500K
User Three colors (Red, Green, Blue) can be adjusted from the OSD
OSD H. Position
OSD V. Position
Graph / Text
Recall
Language
Auto/Input
Exit
LCD35Seriesmanual071904.p65
–continued
To increase or decrease the brightness.
To increase or decrease the contrast (analog only).
This function let's you adjust the display's horizontal position (analog only).
To adjust the display's vertical position (analog only).
To adjust the image sharpness. Five selections are available. A
smoother setting is more suitable for pictures, while a sharper
setting is more suitable for text (analog only).
A total of 101 scales (0 to 100) are available to adjust the focus
and clarity of the display (analog only).
This function carries a frequency-tracking feature that offers users
better stability and clarity from 101 scales (-50 to +50). The
adjustable range can be variable in different modes. This function
records the deviated number of clock period between input timing
and supported timing. The clock value may not be "0" after Auto
Adjustment when the input timing is different from supported
timing (analog only).
Push the (-/+) button to select a different color temperature (analog only).
Sets the CIE coordinate color temperature to 9300K
Sets the CIE coordinate color temperature to 7500K
Sets the CIE coordinate color temperature to 6500K
menu. Sets the settings to a by user defined CIE Temperature.
This function moves the OSD menu window horizontally.
This function moves the OSD menu window vertically.
Because the H and V-Frequencies of both 640x400 70Hz, and
720x400 70Hz, are the same, this function manually selects
either 640x400 (graphics mode) or 720x400 (text mode) (analog only).
This function will return all adjusted parameters to factory preset values.
OSM control menus are available in eight languages.
Select Press < button to activate the select Auto Adjustment
(analog only), Analog Input or Digital Input. The Auto
Adjustment function adjusts the display size, clock and phase to
obtain the best viewing settings. This process will take 3-5
seconds to complete. Attention: After Auto Adjustment, the LCD
might display wrong position or size, if it has received a pattern
which has no screen border. Instead, select Analog or Digital
Input (if available).
Saves the values of this setting and exits the OSD menu function.
7
