INSTRUCTION MANUAL
Aluminum Groove Cutter
CA5000
DOUBLE INSULATION
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita CA5000

Summary of Contents for Makita CA5000

  • Page 1 INSTRUCTION MANUAL Aluminum Groove Cutter CA5000 DOUBLE INSULATION Read before use.

  • Page 2: Specifications

    SPECIFICATIONS Model: CA5000 Groove cutter blade diameter 118.0 mm Max. cutting depth (with groove cutter blade) 11.0 mm No load speed 2,600 - 6,400 min Overall length 346 mm Net weight 5.1 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. •...

  • Page 3: Circular Saw Safety Warnings

    Use personal protective equipment. Always tool is maintained. wear eye protection. Protective equipment such Follow instruction for lubricating and chang- as dust mask, non-skid safety shoes, hard hat, or ing accessories. hearing protection used for appropriate conditions Keep handles dry, clean and free from oil and will reduce personal injuries.
  • Page 4 — when the blade is pinched or bound tightly by the kerf closing down, the blade stalls and the motor reaction drives the unit rapidly back toward the operator; — if the blade becomes twisted or misaligned in the cut, the teeth at the back edge of the blade can dig into the top surface of the wood causing the blade to climb out of the kerf and jump back toward the operator.

  • Page 5: Functional Description

    Assure that the base plate of the saw will not inhalation and skin contact. Follow material shift while performing the “plunge cut” when supplier safety data. the blade bevel setting is not at 90 °. Blade Do not stop the blades by lateral pressure on shifting sideways will cause binding and likely kick the saw blade.

  • Page 6: Adjusting Depth Of Cut

    0 mm depth is set properly when the tool is shipped Switch action from the factory, but if you changed the depth of groove by the adjusting knob, refine the 0 mm depth as follows: CAUTION: Before plugging in the tool, always Turn the quick stop to 0 mm. check to see that the switch trigger actuates Turn the depth adjusting knob to adjust the depth.

  • Page 7: Overload Protector

    And align the plate edge with teeth pointing up at the front of the tool. the cutting line again. CAUTION: Use only the Makita wrench to Other features install or remove the blade. To remove the groove cutter blade, perform following...

  • Page 8: Operation

    Maintenance section. Such efforts do not replace the need to check guard operation before each use. Connecting a vacuum cleaner For groove cutting operation, connect a Makita vacuum cleaner to your tool. Connect a hose of the vacuum cleaner to the dust port.

  • Page 9: Groove Cutting

    Groove cutting CAUTION: Be sure to move the tool forward in a straight line gently. Forcing or twisting the tool may result in overheating the motor and dangerous kickback, possibly causing severe injury. CAUTION: Never approach any part of your body under the tool base when section cutting, especially at starting.

  • Page 10: Maintenance

    To maintain product SAFETY and RELIABILITY, MAINTENANCE repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. CAUTION: Always be sure that the tool is switched off and unplugged before attempting to perform inspection or maintenance.
  • Page 12 Makita Corporation 885435B4 20150608 www.makita.com...
