What You Need to Get Started

SCC-RLY01 Relay Module User Guide
Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
Italic text denotes variables, emphasis, a cross-reference, or an introduction
to a key concept. Italic text also denotes text that is a placeholder for a word
or value that you must supply.
Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames, and extensions.
SC-2345 refers to both the SC-2345 connector block and SC-2345 with
configurable connectors.
SCC refers to any SCC Series signal-conditioning module.
To set up and use the SCC-RLY01, you need the following items:
❑
Hardware
– SCC-68 or SC-2345 with one of the following:
• SCC-PWR01
• SCC-PWR02 and the PS01 power supply
• SCC-PWR03 (requires a 7 to 42 VDC power supply,
not included)
– One or more SCC-RLY01 modules
– 68-pin E/M Series DAQ device
– 68-pin cable
– Quick Reference Label
❑
Software
– The latest version of NI-DAQmx
❑
Documentation
– SCC-RLY01 Relay Module User Guide
– SC-2345/2350 User Manual or SCC-68 User Guide
– SCC Quick Start Guide
– Read Me First: Safety and Radio-Frequency Interference
