• As with any hazardous voltage wiring, make sure that all
wiring and connections meet applicable electrical codes and
common sense practices. Mount terminal bases in an area,
position, or cabinet that prevents accidental or unauthorized
access to wiring that carries hazardous voltages.
• The isolation of the FP-QUAD-510 is certified as
double-insulated for normal operating voltages of 250 Vrms.
Do not use the FP-QUAD-510 as the only isolating barrier
between human contact and working voltages of more than
250 Vrms.
Channel Operation Summary
Table 3 summarizes the functionality of each of the FP-QUAD-510
channels as accessed through FieldPoint Explorer or other
software.
Table 3. FP-QUAD-510 Channel Operation Summary
Channel
No.
0 Axis 0 Position LSW
1 Axis 1 Position LSW
2 Axis 2 Position LSW
3 Axis 3 Position LSW
4 Axis 0 Position MSW
5 Axis 1 Position MSW
6 Axis 2 Position MSW
7 Axis 3 Position MSW
8 Axis 0 Velocity
9 Axis 1 Velocity
10 Axis 2 Velocity
11 Axis 3 Velocity
12 Axis 0 Index Active
13 Axis 1 Index Active
14 Axis 2 Index Active
15 Axis 3 Index Active
FP-QUAD-510
Channel Description Type
Count Input
Count Input
Count Input
Count Input
Count Input
Count Input
Count Input
Count Input
Analog Input
Analog Input
Analog Input
Analog Input
Discrete Input
Discrete Input
Discrete Input
Discrete Input
10
Range
0–65535
0–65535
0–65535
0–65535
0–65535
0–65535
0–65535
0–65535
8 ranges
8 ranges
8 ranges
8 ranges
Boolean
Boolean
Boolean
Boolean
