LM3647 Reference Design
User's Manual
GENERAL DESCRIPTION
The LM3647 is a charge controller for Nickel-Cadmium
(Ni-Cd), Nickel-Metal Hydride (Ni-MH) or Lithium-Ion (Li-Ion)
batteries. The device uses a pulsed-current charging or a
constant-current charging technique. The device can also be
configured to discharge before charging. Throughout the
charging sequence the LM3647 monitors voltage and/or
temperature and time in order to terminate charging.
• Negative delta voltage (− V)
• Maximum voltage
• Optional: Delta temperature/delta time ( T/ t)
• Optional: Maximum temperature
• Backup: Maximum time
The LM3647 is user configurable for three battery
chemistries: Ni-Cd, Ni-MH or Li-Ion.
In Ni-Cd/Ni-MH mode, four different charging phases are
used:
• Softstart charge
Fast charge
• Topping charge
• Maintenance charge
In Li-Ion mode, four different charging stages are used:
• Qualification
• Fast Charge Phase 1, Constant Current
• Fast Charge phase 2, Constant Voltage
• Maintenance charge
KEY FEATURES
• Auto-adaptive fast charge
• High-resolution, accurate voltage monitoring prevents
Li-Ion under-charge or overcharge
• Fast charge, pre-charge and maintenance currents are
provided. Different currents are selectable via external
resistors
• Fast-charge termination by temperature/time, maximum
voltage, maximum temperature and maximum time
• Dynamically detects battery insertion, removal, short
circuit and bad battery without additional hardware
• Supports charging of battery packs with 2-8 cells of
Ni-Cd, Ni-MH or 1-4 cells of Li-Ion
• Three LED indicators and one Buzzer output indicate
operational modes
• Ni-MH/Ni-Cd charge mode, Li-Ion charge mode or
discharge mode can be selected manually
• PWM switching controller
DOCUMENTATION INFORMATION
The following documentation describes how to use the
LM3647 demo-board and also gives a few tips on design
calculations. Please note that not all components on the
demo-board are used when designing a charger
© 2001 National Semiconductor Corporation
National Semiconductor
Application Note 1164
March 2001
application. The demo-board has extra components to
make it simple for the user to try out different batteries and
configurations. There are actually two different charge
current regulation methods and these are referred to as fast
and slow (LM317).
JUMPER SETTINGS
J5
V
CC
GND
Hi-Z
J2
V
CC
GND
Hi-Z
J2
V
CC
GND
Hi-Z
J5
V
CC
GND
Hi-Z
Timeout
Timeout settings J18 (set according to charge-rate C), See
Section 3.0 for more information.
Temperature Input
The optional Temperature input is connected to J3 and if not
used Short J8.
Voltage Regulation Range
Voltage regulation loop setting J14 (not used with external
LM317 regulation I.e. J7 = slow), defines maximum voltage
output. See also Section 3.0 LM3647 REFERENCE
DESIGN DEMO-BOARD .
Voltage Measurement
The battery voltage is selected with the Voltage jumpers J11
& J12 depending on number of cells/chemistry. For instance,
a 9V Ni-Cd block battery has 6 cells in it and therefore needs
the jumper at Ni 6-Cells on J11 and J12:
AN101315
Type Select
Ni-MH
Ni-Cd
Li-Ion
Charge Mode
No discharge
Maintenance charge only
Discharge before charge
Maintenance Mode
Charge indefinitely
No charge and restart fast-charge if battery
becomes discharged
Charge indifinitely and restart fast-charge if
battery becomes discharged
Regulation Method / Cell
J6
J7
Voltage
V
Fast
LM3647 controls charge current
CC
GND
Slow
External (LM317) charge control
V
Fast
LM3647 controls charge current
CC
GND
Slow
External (LM317) charge control
V
Fast
4.2V/Cell Li-Ion
CC
GND
Fast
4.1V/Cell Li-Ion
www.national.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM3647 and is the answer not in the manual?

Questions and answers

Summary of Contents for National Semiconductor LM3647

  • Page 1 • PWM switching controller DOCUMENTATION INFORMATION The following documentation describes how to use the LM3647 demo-board and also gives a few tips on design calculations. Please note that not all components on the demo-board are used when designing a charger ©...
  • Page 2: Functional Description

    J9, J10 and J13 have no relevance, when using LM317 regulation mode, this jumper must be placed in either position. If external (LM317) regulation is used then set jumper J7 to position slow ; for LM3647 regulation set J7 to fast . LM3647 Current Regulation The I jumper J10 is used to select between different current sense resistors.
  • Page 3 RC-network that generates the DC-voltage from the PWM-output of the LM3647. 1.2.2.3 Setting The Charge Timeout The LM3647 uses the charge timeout value as a backup termination method if the normal termination methods fail. The charge timeout also controls the length of some of the phases like the Topping Charge phase (Ni-Cd/Ni-MH).
  • Page 4 2.5V reference by the operational amplifier and fed to the CS pin on the LM3647. The gain must be dimensioned by setting the appropriate ratio between R1 (R2) and R3 (R4). The figure below is dimensioned for a maximum current of about 1.1A.
  • Page 5 This mode uses an external constant-current power-source, which is switched on and off according to the charge-phase of the LM3647. The frequency is approximately 0.1 Hz. The advantage of this charge method is that operational amplifiers and the current feedback circuitry are not needed, which provides a low-cost solution.
  • Page 6: Application Information

    2.0 APPLICATION INFORMATION 2.1 Typical Example 2.1.1 Ni-Cd/Ni-MH Set To: No Discharge before Charge Hi-Z Discharge before Charge Maintenance Charge Only www.national.com SEL1 SEL2 Ni-MH Ni-Cd AN101315-8 SEL3 Fast-PWM (LM3647 has current feedback) Slow-PWM (external current control)
  • Page 7 2.1.2 Li-Ion Set To: After charging, maintenance charging until battery removal. Hi-Z After charging, maintenance charging until battery removal. If battery voltage drops below a predefined value, the charger restarts the charge-process. After charging, no maintenance charging is applied. If battery voltage drops below a predefined value, the charger restarts the charge-process.
  • Page 8 The demo-board provides a combined multi-chemistry solution with hardware for both external constant current source and LM3647 controlled charge current. Located near the top-left corner of the board is the power supply connector (next to the heatsink). When using the external constant current source, a power resistor needs to be connected at the connector marked 317-resistor.
  • Page 9: Life Support Policy

    LIFE SUPPORT POLICY NATIONAL’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL COUNSEL OF NATIONAL SEMICONDUCTOR CORPORATION. As used herein: 1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into the body, or (b) support or sustain life, and whose failure to perform when properly used in...
