- Page 1 MPX-MS92P INSTRUCTION MANUAL English B/W Multiplexer Deutsch Schwarzweiß Multiplexer Français Multiplexeur Noir et Blanc Español Blanco y negro Multiplexor Italiano Multi distributore in bianco e nero About this manual Acerca de este manual Before installing and using this unit, please read this manual Antes de instalar y usar este aparato, lea detenidamente este carefully.
- Page 2 However, in the event of a problem, the owner is advised not to attempt to make repairs or open the cabinet. Servicing should always be referred to your dealer or Sanyo Authorized Service Centre. CAUTION Danger of explosion if battery is incorrectly replaced.
-
Page 3: Table Of Contents
CONTENTS FEATURES PARTS NAMES ....... 3 This unit can display live camera images in full screen mode or in a split screen (4 or 9 divisions). -
Page 4: Parts Names
PARTS NAMES FRONT PANEL 3 4 5 6 MENU POWER QUAD MULTI LIVE SELECT RESET NEXT EXIT MENU RESET ZOOM STILL SEQUENCE – DISPLAY This unit is not equipped with a power switch. The power is turned on/off when the supplied power cord is connected/disconnected at the power source. -
Page 5: Rear Panel
PARTS NAMES REAR PANEL CAMERA ALARM 1 2 3 4 5 6 7 8 SENSOR ALARM C A B C AL C R1 R2 C SW C MONITOR RS485 CONTROL TERMI 9 10 NATE RS232C ADDRESS 3 4 5 CAMERA IN terminals (1 – 9) CONTROL terminal CAMERA OUT terminals (1 –... -
Page 6: Connection
OUT terminal, the CAMERA IN terminal termination is open, you must therefore make Ground sure the CAMERA OUT side is terminated. • With model MPX-MS92P, use black and white cameras only. If color cameras are used, that Ground Timelapse VCR (sold separately) may cause image beat, etc. -
Page 7: Connections To The Alarm In And Rs232C/Rs485 Terminals
CONNECTION CONNECTIONS TO THE ALARM IN AND RS232C/RS485 TERMINALS RS485 (RJ-11) terminal connection External alarm sensors Make the connection to the RS485 control terminal using a (door bell, interphone, etc.) modular cable (sold separately). • If using a straight type cable, connect it between the A terminals, or between the B terminals (see illustration below). -
Page 8: Remote Controller Circuit Connections
CONNECTION REMOTE CONTROLLER CIRCUIT CONNECTIONS Use the layout below to make a remote controller and make the connections to the remote input pins (R1, R2) of the CONTROL terminal as indicated. This will permit remote controlled operation of this unit. (make contact LOW input) 220Ω... -
Page 9: Basic Operations
BASIC OPERATIONS FIELD SWITCHER AND MULTI-VIEWER FUNCTIONS This unit can operate in field switcher (full screen) mode and multi-viewer (split screen) mode. When the power is turned on, the default operating mode is field switcher (full screen) mode. Field Switcher Mode (MULTI MODE: OFF) To record multiple live images feeds sequentially in full screen (field) mode. -
Page 10: Mode Switching
BASIC OPERATIONS MODE SWITCHING When the VCR, LIVE or MENU button is pressed the corresponding mode screen is displayed as shown below. VCR playback mode LIVE picture mode Menu mode 01 01 02 02 03 03 (LANGUAGE/LANG./SPRACHE) 01 01 02 02 03 03 ENGLISH 04 04... -
Page 11: Security Lock Function
BASIC OPERATIONS SECURITY LOCK FUNCTION RESET FUNCTION This function lets you lock the camera live picture mode or VCR The menus can be reset or cleared using one of the following playback mode, so that it cannot be switched to another mode. two methods. -
Page 12: Field Switcher Mode
FIELD SWITCHER MODE Live picture mode To select the field switcher mode, in the (MONITOR SET) menu set MULTI MODE to OFF. The display on the monitor will switch to full screen mode (see page 32). LIVE PICTURE MODE Press the LIVE button. LIVE The camera SELECT indicator lights and the signal input at the CAMERA IN terminals is displayed in full screen mode on the monitor screen. -
Page 13: Vcr Playback Mode
FIELD SWITCHER MODE VCR playback mode To select the field switcher mode, in the (MONITOR SET) menu set MULTI MODE to OFF. (see page 32) VCR PLAYBACK MODE Press the VCR button. The VCR playback display mode is selected. When a tape is played back, the recording on the tape will be displayed on the monitor. -
Page 14: Full Screen Operations
FIELD SWITCHER MODE VCR playback mode FULL SCREEN OPERATIONS Press a SELECT (1 – 9) button. The recorded pictures are displayed full screen. Example: To freeze the image from camera 2 Press the SELECT 2 button. The camera 2 indicator lights, the image from camera 2 is displayed full screen. 02 02 S 02 S 02... - Page 15 FIELD SWITCHER MODE VCR playback mode Example: To zoom in the image from camera 4 and set the zoom range You can select the portion of the image to zoom in. The default zoomed in area is the centre of the image, but if a different zoom range is selected it will be memorized until changed or cancelled.
-
Page 16: Divisions Split Screen Operations
FIELD SWITCHER MODE VCR playback mode Automatic sequential full screen display Press the SEQUENCE button. The SEQUENCE indicator flashes. The pictures from each camera are displayed 01 01 01 01 01 01 sequentially full screen, on monitor, according to the monitor sequential mode and speed set in the (MONITOR SET) menu (see page 32). -
Page 17: Multi-Viewer Mode
MULTI-VIEWER MODE Live picture mode To select the multi-viewer mode, in the (MONITOR SET) menu set MULTI MODE to ON. The display on the monitor will switch to split screen mode (see page 32). LIVE PICTURE MODE Press the LIVE button. LIVE The camera SELECT indicator lights and the signal input at the CAMERA IN terminals is displayed on the monitor screen. -
Page 18: Full Screen Operations
MULTI-VIEWER MODE Live picture mode FULL SCREEN OPERATIONS Press a SELECT (1 – 9) button. The live pictures from the selected camera will be displayed full screen. Example: To freeze the image from camera 2 Press the SELECT 2 button. The camera 2 indicator lights, the image from camera 2 is displayed full screen. - Page 19 MULTI-VIEWER MODE Live picture mode Example: To zoom in the image from camera 4 and set the zoom range You can select the portion of the image to zoom in. The default zoomed in area is the centre of the image, but if a different zoom range is selected it will be memorized until changed or cancelled.
-
Page 20: Divisions Split Screen Operations
MULTI-VIEWER MODE Live picture mode Automatic sequential full screen display Press the SEQUENCE button. The SEQUENCE indicator flashes. The pictures from each camera are displayed 01 01 01 01 01 01 sequentially full screen, on monitor, according to the monitor sequential mode and speed set in the (MONITOR SET) menu (see page 32). -
Page 21: Alarm Operations
MULTI-VIEWER MODE Live picture mode ALARM OPERATIONS When an alarm trigger, from a door bell, an interphone, etc., is input at the rear panel ALARM IN terminals, the corresponding camera SELECT indicator flashes and the buzzer is heard. The alarm channel pictures are displayed according to the (ALARM SET) menu settings (see page 28). -
Page 22: Vcr Playback Mode
MULTI-VIEWER MODE VCR playback mode To select the multi-viewer mode, in the (MONITOR SET) menu set MULTI MODE to ON. The display on the monitor will switch to split screen mode (see page 32). VCR PLAYBACK MODE Press the VCR button. The VCR playback display mode is selected. -
Page 23: Menu Setting Mode
MENU SETTING MODE MENUS DISPLAYS To display the menus, press the MENU button. Menu display Menu 1 Menu 6 (MONITOR SET) (LANGUAGE/LANG./SPRACHE) MON. SEQ.TIMER QUAD SEQ.TIMER ENGLISH MON. SEQ.MODE MODE1 MON.MASK LIVE FRANCAIS MON.MASK VCR DEUTSCH MULTI MODE MENU MENU Menu 2 Menu 7 MENU... -
Page 24: Language Setting
LANGUAGE SETTING Menu 1 (LANGUAGE/LANG./SPRACHE) The default menu language is English. The available language settings are English, French and German. Setting the language Press the MENU button once to display the (LANGUAGE/LANG./SPRACHE) menu. Press the l button to highlight the desired language. Press the MENU button to go to the next menu, or Press the EXIT button to exit the menu display and the selected language is set. -
Page 25: Clock And Summer Time Setting
CLOCK AND SUMMER TIME SETTING Menu 2 (CLOCK SET) (TIMER SET) The default setting is as indicated below. The clock will start after You can set a DAY and a NIGHT range for the 24 hour day the actual time and date are set and the operations under period, in order to set each camera mode and programmed (TIMER SET) are completed. - Page 26 CLOCK AND SUMMER TIME SETTING Menu 2 (SUMMER TIME SET) The default summer time function setting is “NO USE”, so the summer adjustment will not be made. If the unit will be used in an area where there is a summer time change, set it to “USE”, then if necessary, set when the summer time is changed.
-
Page 27: Vcr Setting And External Control Communication Speed Setting
VCR SETTING AND EXTERNAL CONTROL COMMUNICATION SPEED SETTING Menu 3 Table 1 (VCR SET) Recording speed setting on the REC SPEED setting real time VCR You must set this unit output to match the type (Timelapse or 8H (8-hour mode) Real time VCR) and settings of the VCR used for recording. - Page 28 VCR SETTING AND EXTERNAL CONTROL COMMUNICATION SPEED SETTING Menu 3 SERIAL SET menu If the VCR is Equipped with a SW (switching) Output Connector (using the VCR switching signal) DATA SPEED (Default setting: 19200 bps) Make the connection from this unit to the VCR SW output The available settings are: 2400, 4800, 9600, 19200 bps connector.
-
Page 29: Alarm And Sensor Setting
ALARM AND SENSOR SETTING Menu 4 DATA (Default setting: ON) (ALARM SET) ON: The alarm data is recorded. OFF: The alarm data is not recorded. When an alarm trigger is received from sensors such as a door bell, movement sensor, etc. you can set the display mode and MON OUT the recording mode for the pictures from the concerned camera. - Page 30 ALARM AND SENSOR SETTING Menu 4 (SENSOR SET) When the internal video sensor detects a movement in the live video signal, it can be set to trigger an alarm. Priority recording of the concerned pictures can also be set (ACTIVE REC). Setting the SENSOR SET Mode Press the l button to highlight the setting to modify.
-
Page 31: Active Recording And Video Loss Setting
ACTIVE RECORDING AND VIDEO LOSS SETTING Menu 5 (ACTIVE REC SET) (VIDEO LOSS SET) To set the priority recording mode when an external alarm or When the live picture signal feed is interrupted, you can set the video sensor trigger is received. action taken (frozen picture or test chart), and if the video loss is recorded as alarm data. - Page 32 ACTIVE RECORDING AND VIDEO LOSS SETTING Menu 5 ACTIVE REC Settings Examples Example 1: Recording on the tape when an alarm trigger is received from camera 2 Camera 2 picture 02 02 (Normal) 01 01 Alarm trigger in Alarm trigger out (REC MODE: MODE1) 02 02 02 02 02 02...
-
Page 33: Monitor Settings
MONITOR SETTINGS Menu 6 You can set the automatic sequential display speed on each monitor and the display sequence order. You can also set the viewing mode for live pictures to multi-viewer (4 or 9 divisions). MON.MASK LIVE (Default setting: ON) (MONITOR SET) ON: If, for certain cameras, in the (CAMERA SET) menu, the “MON.MASK”... -
Page 34: Camera Setting
CAMERA SETTING Menu 7 For each camera connected to the unit, you can enter a camera title, such as the camera location, etc., that will be displayed together with the picture from that camera. Also, each camera operating mode and timer recording mode can be set. Setting the camera title (CAMERA SET) Each camera is selected by pressing the appropriate SELECT (1... - Page 35 CAMERA SETTING Menu 7 Setting up programmed recording for each camera Press the MENU button twice to display the (TIMER SET) menu, then check that the day and night periods (CLOCK SET) are set as desired. (For more information on the day 15-10-1999 FRI 15:20:00 and night periods settings, see “TIMER SET”...
- Page 36 CAMERA SETTING Menu 7 Setting the alarm duration for each camera Press the MENU button twice to display the (TIMER SET) menu, then check that the day and night periods are set as desired. (For more information on the day (CLOCK SET) 15-10-1999 FRI 15:20:00 and night periods settings, see “TIMER SET”...
- Page 37 CAMERA SETTING Menu 7 Setting the monitor masking for each camera Press the MENU button twice to display the (TIMER SET) menu, then check that the day and night periods (CLOCK SET) are set as desired. (For more information on the day 15-10-1999 FRI 15:20:00 and night periods settings, see “TIMER SET”...
- Page 38 CAMERA SETTING Menu 7 Setting the sequential display interval for each camera Press the MENU button twice to display the (TIMER SET) menu, then check that the day and night periods (CLOCK SET) are set as desired. (For more information on the day 15-10-1999 FRI 15:20:00 and night periods settings, see “TIMER SET”...
- Page 39 CAMERA SETTING Menu 7 Setting the video loss operation mode Press the MENU button four times to display the (VIDEO 1, 2 LOSS SET) menu, then press the l button to highlight the “VIDEO LOSS” setting. (ACTIVE REC SET) EXT ALARM REC SENSOR REC REC MODE MODE2...
- Page 40 CAMERA SETTING Menu 7 Modifying the sensor position Setting the video sensor area position, In the default sensor screen, the first line of sensor positions sensitivity level and response mode will be empty. If you need to set sensor points on this line, please first follow the steps below.
-
Page 41: Setting Each Camera Display Position In Split Screen Display Mode
SETTING EACH CAMERA DISPLAY POSITION IN SPLIT SCREEN DISPLAY MODE Menu 8 You can set where each camera will be displayed when viewing a split screen display. Setting for 9 divisions split screen is available. (POSITION SET) Changing a camera position Press the MENU button 8 times to display the (POSITION SET) menu. -
Page 42: Clock And Title Display Settings
CLOCK AND TITLE DISPLAY SETTINGS Menu 9 The clock and the camera title settings entered in the menus (CLOCK SET) and (CAMERA SET, TITLE) can be displayed on-screen, and their display position can be set. DISPLAY SET menu (DISPLAY SET) LIVE CLOCK (Default setting: OFF) Setting the clock and title display... -
Page 43: Alarm Data Display
ALARM DATA DISPLAY Menu 10 The alarm recordings are done according to the settings entered in the (ALARM SET), (SENSOR SET) and (VIDEO LOSS SET) menus. Information about the alarms (alarm data) is also recorded and can be displayed on-screen. (ALARM DATA) Displaying the Alarm Data Press the MENU button 10 times to display the (ALARM... -
Page 44: Alarms Operations
ALARMS OPERATIONS LIVE PICTURES MODE ALARM There are three types of live pictures alarms; the alarms set by an external alarm trigger, the alarms set by a loss of the video signal and the alarms set by the video sensors. EXTERNAL ALARMS VIDEO LOSS ALARM Connect external inputs such as a door bell, an interphone, etc.,... - Page 45 ALARMS OPERATIONS RECORDED PICTURES MODE ALARM VIDEO SENSOR ALARM In VCR playback mode, only the alarms recorded on tape are available. When in the (SENSOR SET) menu, the “SENSOR ALARM” item is set to “ON” or “AND”, a moving subject detected by the video Alarms recorded on tape sensor in the selected area of the image can trigger an alarm.
-
Page 46: Interface Specifications
A proprietary protocol (SSP: Security Serial Protocol) is used. Operates using a Sanyo controller or a controller using The command ON (F6) is sent to start, and the command OFF containing this protocol. - Page 47 INTERFACE SPECIFICATIONS SETTING THE DIP SWITCHES COMMANDS The DIP switches need to be set when a computer, special COMMANDS AVAILABLE FROM THE controller, etc. connected to the RS-232C or RS-485 connectors COMPUTER is used to control the multiplexer. Make sure to turn the multiplexer power off before setting the DIP switches.
- Page 48 INTERFACE SPECIFICATIONS INFORMATION GATHERING COMMANDS Second byte STATUS SENSE (D7) Bit state information When this command is sent from the computer, this unit will EXT/ALARM EXT and ALARM are ON send a 5-byte response (see Table 1). indication VIDEO LOSS VIDEO LOSS is ON indication SENSOR indication...
- Page 49 INTERFACE SPECIFICATIONS ALARM STATUS SENSE (D5) COMMANDS AVAILABLE FROM THE MULTIPLEXER The external and video loss alarm states are indicated by a 6-byte response (see Table 2). ACK(0A) Response when this unit receives a command. NAK(0B) Response if this unit did not receive the command. ALARM STATUS SENSE (D5) byte assignment (Table 2) ALARM(BF)
- Page 50 INTERFACE SPECIFICATIONS COMMAND TABLE (TABLE 4) The commands available are indicated in the table. If a function is not available on the unit, the command will not operate even if sent. LIVE FULL 1 VCR PB FULL 2 VERSION MULTI FULL 3 »...
-
Page 51: Specifications
SPECIFICATIONS Signal format : Based on CCIR B/W signal standard Camera signal input synchronization : Asynchronous : VS/VBS, 1.0 Vp-p/75 Ω, BNC connector x 9 Camera input terminals (IN) : Throughput of each input, 1.0 Vp-p/75 Ω, BNC connector x 9 Camera output terminals (OUT) VCR input terminal (VCR IN) : VS/VBS, 1.0 Vp-p/75 Ω, BNC connector x 1... - Page 52 SANYO Electric Co., Ltd. 1AC6P1P2017-- L8FN5/XE, UK (0100KP-NI01) Printed in Japan...
