INSTALLATION, OPERATING
SERVICE MANUAL
WOOD FURNACE WFA-85
WOOD/ELECTRIC FURNACE WFA-85E
NOTICE TO HOMEOWNER:
READ THESE INSTRUCTIONS
SAVE THESE INSTRUCTIONS
and
WAREHOUSE
Newmac Mfg. Inc.
430 SPRINGBANK AVE., SOUTH
P.O. BOX 545
WOODSTOCK, ONTARIO
PHONE: 519-539-6147
FAX:
HOMEPAGE: newmacfurnaces.com
N4S 7Y5
519-539-0048
2210xxx
June 2012
Printed: _______________
