INSTALLATION, OPERATING
and
SERVICE MANUAL
THE INSTALLATION OF THE UNIT SHALL BE IN ACCORDANCE WITH THE
REGULATIONS OF THE AUTHORITIES HAVING JURISDICTION.
OIL-FIRED HI-BOY – HEAVY DUTY FURNACES
MODELS: NH3 and LFR
HEAD OFFICE
MARKETING / PRODUCTION
WAREHOUSE
Newmac Mfg. Inc.
Newmac Mfg. Inc.
208 LANCASTER CRESCENT
430 SPRINGBANK AVE., SOUTH
P.O. BOX 9, DEBERT
WOODSTOCK, ONTARIO
NOVA SCOTIA, BOM 1G0
N4V 1B2
PHONE: 902-662-3840
PHONE: 519-539-6147
FAX:
902-662-2581
FAX:
519-539-0048
EMAIL: newmac@newmacfurnaces.com
WEB SITE: newmacfurnaces.com
NOTICE TO HOMEOWNER:
READ AND SAVE THESE INSTRUCTIONS
156156
2210272 March 2010
Subject to change without notice
Printed:__________
Advertisement
Table of Contents
Related Manuals for Newmac NH3–122
Summary of Contents for Newmac NH3–122
- Page 1 REGULATIONS OF THE AUTHORITIES HAVING JURISDICTION. OIL-FIRED HI-BOY – HEAVY DUTY FURNACES MODELS: NH3 and LFR HEAD OFFICE MARKETING / PRODUCTION WAREHOUSE Newmac Mfg. Inc. Newmac Mfg. Inc. 208 LANCASTER CRESCENT 430 SPRINGBANK AVE., SOUTH P.O. BOX 9, DEBERT WOODSTOCK, ONTARIO...
- Page 2 TABLE 1 NH3 GENERAL INSTRUCTIONS UPFLOW CONFIGURATION CHIMNEY EXTERNAL B.T.U.H. BURNER AIR SETTING GROSS DIRECT DRIVE SPEED TAP BELT DRIVE RIELLO B.T.U.H. AFUE PUMP INSERTION FILTER SIZE FLUE STATIC MODEL INPUT NOZZLE STACK BURNER OUTPUT p.s.i. inches (QTY) PRESSURE 12” 10”...
- Page 3 TABLE 2 – NH3 BLOWER PERFORMANCE STATIC STATIC DIRECT DRIVE BLOWER DIRECT DRIVE BLOWER SPEED SPEED TAP PRESSUR PRESSUR BLOWER MOTOR TONS BLOWER MOTOR TONS E (in w.c.) E (in w.c.) HIGH 1,045 1,610 4.00 HIGH 1,010 1,775 4.25 MED-HI 1,200 3.00 MED-HI...
- Page 4 MED-LO 0.20 Models marked -V can be used with the Newmac SVS sealed vent system. Use burner air settings as a guide only. Set burner air to give a trace of smoke. Re-adjust burner air to reduce CO by 1 to 1.5 percent.
-
Page 5: Furnace Location
FURNACE LOCATION IMPORTANT Please read this entire manual and all labels before installing the furnace. UNPACKING AND INSPECTION It is the responsibility of the consignee of the unit to examine the packages for damage and, if found, to note the same on the Carrier’s Bill of Lading. The NH3 furnace is shipped in one package complete with oil burner, draft regulator, filter racks, air filters, A/C Control Center (optional) and instruction manual. - Page 6 The WMO-1 blocked vent control is required on Newmac oil-fired and combination furnaces or boilers installed in Canada. The WMO-1 switch must be installed on the chimney vent pipe for Newmac oil fired furnaces and boilers; and installed on the burner plate for Newmac combination wood/oil or coal/oil fired furnaces.
-
Page 7: Electrical Connections
PROPER DUCT SIZING Locate the furnace as close as possible to the center of the heat distribution system and make sure the top is level. Refer to TABLES 6 and 7, DUCT SIZING FOR HEATING and COOLING in this manual. AIR CONDITIONING This appliance is designed to accommodate air conditioning equipment. - Page 8 FAN & LIMIT CONTROL This thermally operated control has a probe to sense air temperature inside the appliance adjacent to the heat exchanger. Fig. 3 shows the main parts of a Honeywell L4064 Fan & Limit Control. Refer to Fig. 4 for its settings.
- Page 9 However, every house is subject to different internal and external conditions and regulations vary among localities. With this in mind, Newmac recommends provision for combustion and ventilation air as specified in Table 5. Table 5 is based on relevant commonly available codes and regulations.
- Page 10 The incoming cold air is confined to the furnace room. Therefore, the residence occupants are less susceptible to drafts. Cool outdoor air will be tempered by the ambient temperature of the furnace room before it enters habitable spaces. Noise levels may be reduced.
- Page 11 OIL BURNER INSTRUCTIONS BURNER CARE This burner is fully automatic in operation. All adjustments should be made by a qualified technician. Keep the burner free from excess dirt and moisture. Oil leaks should be tended to immediately. If the burner motor has oiler openings, the motor should be given a few drops of SAE 20 non-detergent oil at least two or three times a year.
- Page 12 ELECTRODE SETTINGS FIG 6A FIG 6B FIG 6C FIG 7 BURNER INSERTION TABLE 6 DIMENSIONAL RELATIONSHIPS (Figs 6 & 7) Riello 40 or BF Beckett Std. Beckett Aero Carlin Head Adj. Head 5/32” 5/32” 5/32” 1/8” 1/8” to 5/32” 13/64” 7/16”...
- Page 13 Install the pressure gauge directly on the gauge or nozzle port. Adjust to the pressure specified by Newmac for the nozzle input rating. Refer to TABLE 1 (NH3) or 3 (LFR), GENERAL INSTRUCTIONS in this manual or the certification label on the appliance.
- Page 14 See FIG. 15 for STANDARD WIRING SCHEMATIC - BELT DRIVE and follow the motor manufacturer’s instructions. Make sure replacement and retrofit belt drive motors meet or exceed the OEM motor specifications. Two speed belt drive motors are available from Newmac.
- Page 15 The heat exchanger should be inspected on an annual basis. If cleaning is required, remove the cleanout cover. Use a wire brush or cleaning tool (available from Newmac) to loosen scale and soot and a vacuum cleaner to remove it from the furnace. Replace gaskets if necessary before replacing the cleanout cover.
- Page 16 IMPORTANT HOMEOWNER INSTRUCTIONS 1. AN EMERGENCY POWER SWITCH IS REQUIRED TO BE INSTALLED IN A CONVENIENT LOCATION AT A SAFE DISTANCE FROM THE BURNER. THIS SWITCH INTERRUPTS THE ELECTRICAL SUPPLY CIRCUIT TO THE APPLIANCE. MAKE SURE YOU ARE AWARE OF ITS LOCATION AND THE OFF POSITION IS CLEARLY MARKED.
- Page 17 FIG. 10. TYPICAL OIL TANK PIPING INSTALLATIONS...
- Page 18 FIG. 11. DIMENSIONS & CONTROL LOCATION – NH3...
- Page 19 FIG. 12. LFR SET UP...
- Page 20 FIG. 13. STANDARD WIRING SCHEMATIC - DIRECT DRIVE...
- Page 21 FIG. 14. STANDARD WIRING SCHEMATIC - A/C READY DIRECT DRIVE...
- Page 22 FIG. 15. STANDARD WIRING SCHEMATIC - BELT DRIVE...
- Page 23 TABLE 6. DUCT SIZING FOR HEATING WITHOUT A/C COIL Min. Number Supply Runs MINIMUM SIZE Min. Sq. Inch @ 600 FPM OUTPUT Supply Duct or Needed for Min. Air Return Duct Return Air Grille CAPACITY Extended Plenum Spec. CFM Flow Req'd. Furnace or (or equivalent) (See Notes)
- Page 24 FIG. 16. NH3 EXPLODED ASSEMBLY...
- Page 25 TABLE 8, NH3 PARTS LIST ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4110400 25 A BASE PANEL TWO SPEED FAN & LIMIT 4110401 2010024 SIDE PANEL R.H. HONEYWELL L6064A 1086B (8") 4110402 SIDE PANEL L.H. 25 B SINGLE SPEED FAN & LIMIT 4110403 REAR PANEL 2010025...
- Page 26 TABLE 9 LFR PARTS LIST Item No. Part No. Description Item No. Part No. Description 4110507 Base Panel 2010040 5uF 370v Capacitor 4110503 Side Panel RH 2040116T GT10DD or DCT-1020-1020-5 Blower 4110504 Side Panel LH 2020007 1/3HP 4 speed Direct Drive Motor 4110506 Rear Panel 4110502...
- Page 27 FIG 18 RIELLO BURNER MODEL 40 F3 & F5 EXPLODED ASSEMBLY FIG 19 RIELLO BURNER MODEL 40 BF3 & BF5 EXPLODED ASSEMBLY Item 2030016 Riello Burner End Cone Protector not shown. See Fig. 9 for its location.
- Page 28 TABLE 10 RIELLO BURNER PARTS LIST ITEM PART NUMBER BURNER MODEL DESCRIPTION F3 & F5 BF3 & BF5 RIELLO NEWMAC F3 F5 BF3 BF5 3006911 2090055 Hydraulic jack 3006912 Capillary tube 3000878 Hydraulic air shutter 3005708 3005844 2090041 Capacitor 12.5 uF...
- Page 29 TABLE 10 RIELLO BURNER PARTS LIST – continued ITEM PART NUMBER BURNER MODEL DESCRIPTION F3 & F5 BF3 & BF5 RIELLO NEWMAC F3 F5 BF3 BF5 3008023 Burner Cover 3007319 Acoustic liner 3007320 Acoustic liner 3007087 Crushable metal washer 5/8" ID...
- Page 30 FIG. 20. BECKETT BURNER MODEL AFG60YHHS EXPLODED ASSEMBLY BECKETT BURNER MODEL AFG60HYYS PARTS LIST BURNER MODEL ITEM PART NUMBER AFG60YHYS DESCRIPTION NM504 BECKETT NEWMAC 5877 2090024 Burner Housing Assembly 3709 Air Shutter 3492 Air Band 3493 Escutcheon Plate 5941 Adjusting Plate Assy...
- Page 31 FIG. 21. AERO BURNER MODEL HF-US-2X EXPLODED ASSEMBLY AERO BURNER MODEL HF-US-2X PARTS LIST ITEM PART NUMBER DESCRIPTION REQ'D AERO NEWMAC 35222100 2090016 HF-US Housing 35040000 Blast Tube, 6" 35161000 2090017 Mounting Flange - Fixed 26200005 Flange Spacer (Specify 5" Insertion & 6" Air Tube)
- Page 32 FIG. 22. CARLIN EZ-PRO EXPLODED ASSEMBLY CARLIN EZ-PRO PARTS LIST ITEM PART NUMBER DESCRIPTION REQ'D CARLIN NEWMAC EZ-PRO EZ-PRO PP 77735 7" Air Tube c/w Welded Flange 98022 Motor, 1/6 hp, 3450 rpm Electrode Wire, Set of 2 Nozzle Line / Adapter Assembly...
- Page 33 FIGURE 23. COMMON CHIMNEY DRAFT PROBLEMS...
- Page 34 FIGURE 24 TROUBLESHOOTING CHART PROBLEM CAUSE CORRECTION Check for Broken Wires Tighten Connections Thermostat Clean Contacts Burner Motor Fails to Start Replace Thermostat Burner Motor Overload Tripped Press Rest Button Ceased Pump Repair or Replace Faulty Primary Relay Repair or Replace Oil Supply Check Oil Supply Air Leak in Oil Supply Line...
- Page 35 FIG 24 TROUBLESHOOTING CHART – continued PROBLEM CAUSE CORRECTION Firing Rate Too Low Use Higher Input Nozzle Dirty Heat Exchanger Clean Heat Exchanger Poor Combustion Adjust Using Instruments Not Enough Heat Undersized Capacity Size Based on Heat Loss Distribution System Ensure Proper Design Faulty Thermostat or Location Repair, Replace, or Relocate...
- Page 36 INSTALLER INFORMATION NAME: COMPANY: INSTALLATION DATE: THE HOMEOWNER SHOULD TELEPHONE ( FOR SERVICE OR ADDITIONAL INFORMATION. MODEL: APPLIANCE INITIAL TEST AND SERVICE INFORMATION FUEL INPUT (USGPH) FUEL PRESSURE (PSIG) FLUE PRESSURE (INCHES W.C.) OVERFIRE PRESSURE (INCHES W.C.) NOZZLE ANGLE / PATTERN PERCENT BURNER MODEL FLUE GAS TEMPERTURE (F...
- Page 37 4. Defects or damages caused by nozzle failure and/or plugging and/or oil flow restrictions due to cold oil from outside tanks or misalignment of burner at installation. 5. This warranty in no way can be considered as a guarantee of workmanship of an installer connected with the installation of the Newmac Oil Fired Furnace or as imposing on Newmac any liability of any nature for unsatisfactory performance as a result of faulty workmanship in the installation which liability is expressly disclaimed.
