  • Page 1 Basic Manual Contents Safety Precautions Getting Ready Basic Operation au Disaster Countermeasure Appendix...

  • Page 2: Preface

    "取扱説明書 (Instruction Manual)" (Accessory) ■"Setting Guide"/"Basic Manual" (This manual) (Japanese) and "取扱説明書詳細版 (Full Instruction Manual)" (Japanese) in PDF format from the au homepage. Handles only basic operations for main features. Download URL: For detailed descriptions on various functions, refer to the http://www.au.kddi.com/support/mobile/guide/manual/...

  • Page 3: When Using The Product

    ■ Use of cell phones is not allowed in When using the product some places. • Communication is not possible even inside the service • Do not use a cell phone while driving a car or riding a area in places where the signal does not reach (e.g. motorbike or bicycle.

  • Page 4: List Of Packaged Items

    List of Packaged Items Before your start using the product, make sure that you have all the following packaged with the product. Quick Charge Desktop AC Adapter for Desktop Holder (KYL 21 PQA) Holder (KYY 21 PUA) ● 取扱説明書 (Instruction Manual) (Japanese) ●...

  • Page 5: Table Of Contents

    Names and functions of parts ........34 FCC Notice ..............67 Attaching/Removing the battery pack ......37 European RF Exposure Information ......68 Attaching/Removing au Nano IC Card (LTE) ....38 Declaration of Conformity ..........68 Attaching/Removing microSD memory card ....40...

  • Page 6: Safety Precautions

    Description Explanation Safety Precautions Home screen Tap " (Phone)" at the bottom of the →[ (Phone)] Home screen. And tap " ", " ", →[1][4][1]→[ " ", then tap " " at the end. Regarding notations used in this In sleep mode, F In sleep mode, press F.

  • Page 7: Exemptions

    ◎ Captured image data or downloaded data may sometimes be altered or lost due to faults, repair or other handling of the product. The Company is not liable for any damage or lost ◎ Operations from the vertical display are mainly described. income resulting from recovery of these data.

  • Page 8: Safety Precautions (Observe Strictly)

    ■ Precautions common to the main unit, battery This symbol indicates the possibility pack, battery cover, charging equipment, au (*2) of personal injury to a person or Nano IC Card (LTE), peripheral devices...
  • Page 9 Doing so might cause electric shock, exposed parts with your hands. Doing so might cause ignition, injury or a fault. electric shock or injury from damaged parts. Contact an au shop or Secure cell phone support center.
  • Page 10 Although this product model has waterproof property, Do not leave on unstable places such as rocky stands stop use if liquid such as water gets inside the main or tilting surfaces. Dropping the product may cause unit from the external connection terminal cover, injury or damage.
  • Page 11 Use of a cell phone while riding a use it in that state, and contact an au shop or Secure bicycle may be punishable by some regulations. cell phone support center.
  • Page 12 Doing so might cause injury by the broken part. (e.g. home medical treatment), check individually Contact an au shop or Secure cell phone support with the manufacturer of the electronic medical center. device regarding the influence of radio waves.
  • Page 13 Part Material Surface treatment Be sure to read the following lr key, C / PC resin Acrylic UV hard cautions before use. H / M key coating surrounding area, Use of the main unit in an automobile sometimes External connection affects on-vehicle electronic devices, though this terminal cover, rarely happens.

  • Page 14: Battery Pack

    Stow the TV antenna when not watching TV (1Seg). Be sure to read the following If you operate the product for calling, etc. with the hazards before use. antenna extended, it might cause unexpected injury by hitting your face, etc. Do not short-circuit the positive (+) and negative (-) If you have a weak heart, be careful when setting the terminals of the battery pack.
  • Page 15 Secure cell phone support center. Never charge the Do not use at other voltages than the specified power wet battery pack.
  • Page 16 Do not damage, modify, twist, pull or place a heavy Do not use in places subject to direct splashing with object on the cable of the specified charger. Do not water, pet urine or other liquids. Doing so might result use a damaged cable.
  • Page 17 Cord Connector Iron, copper, zinc, nickel, Do not use or leave the au Nano IC Card (LTE) in hot gold places such as by the fire or a heater. Doing so might cause melting, overheating, fuming, loss of data or a...

  • Page 18: Handling Precautions

    Do not throw the au Nano IC Card (LTE) into a fire or Handling precautions heat it. Doing so might cause melting, overheating, fuming, loss of data or a fault. These precautions are provided to ensure that performance can be fully demonstrated. Thoroughly read these Do not touch the IC (metal) part of the au Nano IC Card (LTE) or short-circuit it.
  • Page 19 ■ Main unit - Main unit ● Do not forcefully press, tap or intentionally subject the - Battery pack, au Nano IC Card (LTE) (attached to the main display to strong impact. Doing so might cause scratching unit) or damage.
  • Page 20 The display response speed will return to normal at room temperature. ● Never use modified au cell phones. Use of a modified device violates the Radio Law. ● Although the display used on the product is made using...
  • Page 21 Swing the product to remove water so that water no longer needed to protect the environment and effectively does not remain in the earphone microphone terminal, then use resources. Old product is collected at au shops and dry it before using. other places.
  • Page 22 Please cooperate in the collection of used battery packs to ● Do not operate the touch panel with fingernails. Doing so protect the environment and effectively use resources. au might result in split nails or jammed fingers. shops and other retailers collect used battery packs.
  • Page 23 Do not use the camera for recording commercially available ● The au Nano IC Card (LTE) is lent to you by au. In case of books or information of which photographing is not allowed. loss or damage, the card will be replaced at your expense.

  • Page 24: Available Security Codes

    * How to make backups: Store important data such as contacts data, music, shot photos and videos on microSD Example of To prevent unauthorized use of the au Nano IC memory cards. You can also send files as mail attachment usage Card (LTE) by third parties or transfer to your PC.
  • Page 25 • PIN code is not reset by initializing the product. ■ PIN code To prevent unauthorized use of the au Nano IC Card (LTE) <Please copy this section and use> by a third party, you can set the product to require PIN code entry every time the power is turned on.

  • Page 26: Notes On Waterproof And Dustproof

    Since operation of the product on each usage scene Notes on waterproof and dustproof was confirmed based on the above assumption, proper operation of the product in every possible condition during This product has a waterproof property equivalent to IPX5 actual use is not guaranteed.
  • Page 27 Do not immerse the product in water with soap, detergent or How to close the external connection terminal cover bath salts in it. After stowing the cover hinge, press on the cover ① evenly Do not immerse the product in seawater, a swimming pool or with the flat part of your finger.
  • Page 28 • Avoid spraying the product with high-pressure water, as the Tips for comfortable use product is not designed to withstand high water pressure. <Washing> Once the product gets wet, water may remain in gaps of the main unit. Shake the product well to drain water. You can wash the product under a mild flow (up to 6 liters per Especially make sure to drain water remaining in the minute) of tap water at room temperature (5℃...
  • Page 29 • If the product gets splashed with pool water, immediately rinse becomes ineffective. In such case, contact an au shop near you. it off with tap water in room temperature, because pool water If any liquid other than plain water gets on the product contains chlorine for disinfection.
  • Page 30 It is recommended to replace the parts for maintaining waterproof property once every two years regardless of whether any abnormality is present. For information on part replacement, contact an au shop near you or Secure cell phone support center.
  • Page 31 ② Wipe drained water. ■ Draining water after wetting the product * The microphone, the speaker, the charging terminal As some parts of this product are not watertight, if you use the and the earphone microphone terminal are particularly product after it gets wet, water remaining in those parts might wet hard to drain water.
  • Page 32 ■ Charging The supplied and optional accessories are not waterproof/ dustproof. Be sure to check the following points before and after charging. • Never charge the battery if the main unit is wet. Doing so might cause electric shock or short circuit resulting in fire or a fault.

  • Page 33: Function

    ® • The Wireless LAN (Wi-Fi ) function cannot be used in ® Notes on using Bluetooth airplane. Be sure to turn off the power even in a Wireless ® Wireless LAN ( Wi-Fi ) function ® LAN (Wi-Fi ) compliant airplane. Some airline companies, however, allow their passengers to use cell phones.
  • Page 34 3. If you are unclear on any points or are troubled by • Since Bluetooth and Wireless LAN (Wi-Fi ) functions use anything, contact an au shop or Customer Service the same frequency band, using the both functions at Center. the same may cause radio wave interference resulting in •...

  • Page 35: Cautions On Using 5 Ghz Band

    Cautions on using 5 GHz band Notes on applications ® Wireless LAN (Wi-Fi ) function of this product uses 5 GHz ◎ Be sure to check the security of the application, then install band. Using 5.2 GHz band and 5.3 GHz band outdoors is it at your own risk.

  • Page 36: Getting Ready

    Getting Ready Names and functions of parts ② ④ ③ ⑤ ⑱ ⑲ ⑥ ⑦ ⑧ ⑨ ⑯ ⑳ ① Air vent* ⑰ ⑩ ⑪ ⑫ ⑬ ⑭ * Since the product is waterproof and hermetically-sealed, an ⑮ air vent (hole for removal of air) is provided. •...
  • Page 37 ⑫ C Back key ① Charging terminal It is a terminal for using Quick Charge Desktop Holder Return to the previous screen. ⑬ H Home key (KYY 21 PUA) when charging. ② External connection terminal Display the Home screen or use for canceling sleep Used for connecting Common AC Adapter 04 (sold mode.
  • Page 38 Atmospheric pressure sensor hearing condition or an immediate environment. Use to measure atmospheric pressure. Receiver au Nano IC Card (LTE) slot microSD memory card slot Battery pack Built-in sub antenna Built-in main antenna ®...

  • Page 39: Attaching/Removing The Battery Pack

    Check the position of connection part and Attaching/Removing the battery pack slide the battery pack to push in securely Use a dedicated battery pack and attach it properly. Check that the lift tab is on the battery. • Before attaching/removing the battery pack and battery cover, turn the power off.

  • Page 40: Attaching/Removing Au Nano Ic Card (Lte)

    ◎ Note the following points, otherwise handling the au Nano IC Card (LTE) may cause malfunction or damage. • Do not touch the IC (metal) part of the au Nano IC Card Lift tab (LTE) or the IC card terminal inside the product.
  • Page 41 The proper position when the tray is pushed into the Hook the tab with your finger to pull the tray end is where the edge of au Nano IC Card (LTE) is straight out to the arrow position shown a little.

  • Page 42: Attaching/Removing Microsd Memory Card

    Removing au Nano IC Card (LTE) Slide the au Nano IC Card (LTE) to remove Turn the power off and remove the battery pack (▶P. 38 "Removing the battery pack") Hook the tab with your finger to pull the tray...

  • Page 43: Removing Microsd Memory Card

    Removing microSD memory card Confirm the direction of the microSD memory card and slowly insert it into the Turn the power off and remove the battery slot until it clicks pack Insert a microSD memory card until you hear a click and confirm it is locked.

  • Page 44: Charging

    Even if the light ◎ The microSD memory card may be warm after a long time keeps blinking, stop charging and then contact an au use. It is normal. shop or Secure cell phone support center.
  • Page 45 Charging with the Quick Charge 21 PUA) Desktop Holder (KYY Stand Using supplied Quick Charge Desktop Holder (KYY 21 PUA) and AC Adapter for Desktop Holder (KYL 21 PQA) enables quick charge, shorter charging time than usual. • Connect AC Adapter for Desktop Holder (KYL 21 PQA) with Quick Charge Desktop Holder (KYY 21 PUA) before using.
  • Page 46 Charging with specified AC Adapter (sold Insert the power plug of Common AC Adapter 04 (sold separately) into an outlet separately)/DC Adapter (sold separately) (100 VAC to 240 VAC)/Insert the plug of Charging with Common AC Adapter 04 (sold separately)/Common Common DC Adapter 03 (sold separately) DC Adapter 03 (sold separately) is explained.

  • Page 47: Charging With A Pc

    Close the external connection terminal cover Check the orientation of plug of microUSB Cable 01 (sold separately) and insert it Pull out the power plug of Common AC straight into the external connection terminal Adapter 04 (sold separately) from the outlet/ Check that the charging light on the product lights in red.

  • Page 48: Turning The Power On/Off

    Do not touch the screen. The touch panel may not work properly. Press and hold F until the incoming light ◎ "auかんたん設定 (au Easy Setting)" can be set up later turns on even though it is skipped.

  • Page 49: Basic Operation

    Using the Simple menu Basic Operation When you purchase the product, you can display "Simple menu", which places basic functions. Tap an icon to start Using Home screen the application. On the Home screen, shortcuts, widgets and folders can Home screen→[ (Simple)] be added.
  • Page 50 LTE Available/ 3G Available/ Finished installing in roaming Update notification for installed applications Airplane mode is activated Connected, Unconnected to VPN au Nano IC Card (LTE) not inserted Major Update (OS Update)/Software Update ® Wi-Fi signal strength available level 4/...

  • Page 51: Notification Panel

    ① Function icon Icon Description Enable/Disable frequently-used functions. ® Bluetooth in use ② Notification area waiting/ connecting You can check the status of the product or details of Answering memo set notification. For some information, tap to activate the Answering memo set/ All answering corresponding application.

  • Page 52: Au Disaster Countermeasure

    6 lower. Registered information of the Emergency Rapid Mail is set to "受信する (Receive)". can be viewed on any cell phones and PCs besides by au Reception setting of Tsunami Warning is available in the cell phone users.
  • Page 53 (au Disaster Countermeasure) menu→[緊急速報メール (Emergency Rapid ◎ The service is available only in Japan (it cannot be used Mail)] overseas). Inbox appears. ◎ No information fee or communication charge is required Select a mail you want to view to check the detail.

  • Page 54: Using Disaster Voice Messaging Service

    ◎ Voice message can be recorded for up to 30 seconds. ◎ Tsunami Warning is a notification delivered from the ◎ Messages can be sent and received to or from au cell meteorological bureau (major tidal wave, seismic sea phones, NTT DOCOMO and SOFTBANK cell phones.

  • Page 55: Appendix

    ■ AC Adapter JUPITRIS (White) (L 02 P 001 W) homepage (http://www.au.kddi.com/) or contact the (sold separately) Customer Service Center. ◎ Accessories on this page can be purchased from au online shop. ■ AC Adapter JUPITRIS (Red) (L 02 P 001 R) http://auonlineshop.kddi.com/ (sold separately) ■...

  • Page 56: Troubleshooting

    Turn off the power and then turn it P. 46 on again. The power is Is the battery pack fully charged? going off while the " " appears. Is your au Nano IC Card (LTE) P. 42 P. 39 activation logo is inserted? displaying. A message such The battery is almost dead.

  • Page 57: Updating Software Or Os

    Place your ear hole to the receiver. ■ Notes P. 35 to hear the other P. 36 • When au Nano IC Card (LTE) is not inserted, software party. cannot be updated. The screen Turn off the power and then turn it cannot be on again.
  • Page 58 • If you fail to update software, it may become impossible ◎ After updating software/major update, older version to operate the product. If this happens, bring it to an au cannot be reverted back. shop or PiPit (not accepted by some shops).

  • Page 59: After-Sales Service

    "Secure cell phone support plus LTE" (monthly ◎ Before handing in the product for repair, make a backup fee: 399 yen including tax) is available for using your au cell of the contents of memory since they may disappear during repair.
  • Page 60 Partially damage, service water soak, 2nd: 8,400 The au Nano IC Card (LTE) is lent to you by au. In case of irreparable loss or damage, the card will be replaced at your expense. damage, theft or When malfunction is suspected, or in case of theft or loss, loss contact an au shop or PiPit.
  • Page 61 LTE Service Members Others Replacement cell phone delivery service Free of Free of ◎ When you have trouble with your au cell phone, year charge charge replacement cell phone (same model, same color, Spontaneous Free of including new battery) is delivered by calling to.

  • Page 62: Main Specifications

    Continuous Approx. 450 minutes (LTE on WAN) Main specifications tethering time Approx. 620 minutes (3G on WAN) Maximum Display Approx. 4.7 inches, Approx. 16,770,000 number colors, Transparent TFT of Wi-Fi 720×1280 dots (HD) tethering connection Weight Approx. 140 g (with battery pack) devices Charging Quick Charge...

  • Page 63: Specific Absorption Rate Of Mobile Phone

    ® Output Bluetooth standard Class 1 *5 The profile supports part of car navigation systems. Refer to the au homepage for use. Communication Within 10 m with no range obstacles in the range Supported SPP (Serial Port Profile)
  • Page 64 Environment set up in the Information and Communication Technology Group of the Advisory Committee on Information and Communications. by KDDI (*2). In case you are not using the au Carrying (As of October 2011) Case F Black ( 0105 FCA) (sold separately), use a product that contains no metal parts, and one that can hold the mobile phone at least 1.5 cm away from your body.

  • Page 65: Intellectual Property Rights

    ® ® ® ® ® Microsoft , Microsoft Excel , Microsoft PowerPoint Intellectual property rights ® ® Windows Media , and Exchange are trademarks or registered trademarks of Microsoft Corporation in the United States and ■ Trademarks other countries. ® ®...
  • Page 66 Twitter and Twitter logo are trademarks of Twitter, Inc., and are ACCESS, the ACCESS logo, and NetFront are registered used under license. trademarks or trademarks of ACCESS CO., LTD. in the United States, Japan and/or other countries. GREE and the GREE logo are registered trademarks of GREE, This software is based in part on the work of the Inc.
  • Page 67 ® The product is equipped with DeepCore 3.0 Plus for Android by Note that the existing license agreement takes priority for usage E-Globaledge Corporation as infrared communication function. of GNU General Public License (GPL), GNU Library/Lesser Copyright© 2012 E-Globaledge Corp. All Rights Reserved. General Public License (LGPL) included in software, software based on other open source software license and software that ®...

  • Page 68: Openssl License

    indirectly, take the required measures on your responsibility and A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE at your expenses. For details on the procedures, contact the LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, Ministry of Economy, Trade and Industry, the U.S.

  • Page 69: Fcc Notice

    FCC Notice FCC RF EXPOSURE INFORMATION Warning! Read this information before using your phone. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may Warning! Read this information before using your phone. In not cause harmful interference, and (2) this device must accept August 1996, the Federal Communications Commission (FCC) any interference received, including interference that may cause...

  • Page 70: European Rf Exposure Information

    Declaration of Conformity European RF Exposure Information Product is declared to conform with the essential requirements of European Union Directive 1999/5/EC Radio and Your mobile device is both a radio transmitter and receiver, and Telecommunications Terminal Equipment Directive 3.1 (a), 3.1 (b) is designed not to exceed limits for exposure to radio waves and 3.2.
  • Page 71 From au cell phones: 0077 - 7 - 111 area code not required PRESSING ZERO WILL CONNECT YOU TO AN OPERATOR AFTER CALLING 157 ON YOUR au CELL PHONE For loss, theft or damage and operation information (toll free) From fixed-line phones:...
