Installation

STEP 1
Connecting the aerial
Use one of these methods to connect a signal to your TV.
Following connection examples are our recommended standard connection. For further information please
consult your local dealer.
For all aerial circuit problems please consult your local dealer.
STEP 2
Connecting AC cord
Connect the power cord of the TV set to a wall outlet.
The TV set is prepared for a mains voltage AC110~240V 50/60Hz. When the TV set is not to be used
for an extended period of time, it is advisable to disconnect the power cord from the power outlet.
WARNING!
High voltages are used in the operation of this set. Refer service to qualified service
personnel.
STEP 3
Plug & Play
Let's start !
This TV set provides a self-automatic tuning system function called "Plug & Play". It automatically begins
searching and storing of all available channels when switching-on the TV set for the first time.
1
1
Press the Power ON/OFF button to turn the TV on, and the TV set will search and store of all
available TV channels automatically.
2
2
Press the MENU button after completing Plug & Play to return to the normal TV mode.
This procedure only appears at the first switch-on time.
Now the installation is completed !
AV1 INPUT AV3 / DVD S-WOOFER MONITOR
INPUT OUT OUT
R
AUDIO S-WOOFER AUDIO
AUDIO
L R R
(MONO)
V
I
L L
D
E C
0 (MONO) R
VIDEO
C
S-VIDEO Y B
3
3
