WIR 150 Listening System Instructions
Model WIR TX5 Transmitter, WIR RX1 Receiver
O
VERVIEW
Thank you for purchasing the WIR 150 Listening
System from Williams Sound Corporation.
Anyone needing auditory assistance to overcome
background noise, reverberation, or distance from
the sound source can benefit from the WIR 150.
You can use the WIR 150 for listening to the TV
or other audio equipment, or for hearing assis-
tance in conference rooms. You can also use your
RX1 Receiver in most facilities which have an
infrared transmitter operating on 95 kHz, such as
theaters, cinemas, or churches.
If at anytime you have problems with the sys-
tem, do not hesitate to call us toll-free at 1-
800-843-3544.
S
C
YSTEM
OMPONENTS
The WIR 150 Listening System includes the fol-
lowing elements.
1. TX5 Transmitter
• AC to DC Adaptor
• TV Microphone
• RCA Plug Adaptor
• Audio Cable With Two 3.5 mm Plugs
2. RX1 Receiver
• AAA Batteries
1. S
U
T
T
ET
P
HE
RANSMITTER
The WIR TX5 Transmitter has an adjustable base
that allows it to be mounted on a wall or cabinet,
or placed on top of a TV or shelf. If you will be
mounting it on a wall, use the keyed mounting
holes on the bottom of the transmitter. The two
horizontal mounting holes are 2-1/4" (5.8cm)
apart and the two vertical holes are 3" (7.5cm)
apart.
Williams Sound
Helping People Hear
®
F
1: TX5 T
IGURE
RANSMITTER
RCA adaptor
(CNA 008)
AC to DC Adaptor
(TFP 021)
12VDC
Input
3.5mm plug
F
2: TX5 T
IGURE
RANSMITTER
F
3: WIR RX1 R
IGURE
ECEIVER
Volume/
On-Off Wheel
(R
V
)
EAR
IEW
TV Microphone
(MIC 070)
3.5mm jack
Mic
3.5mm plug
Input
Blue Band
Audio Cable
(WCA 073)
(F
V
)
RONT
IEW
Red Power
Indicator
Infrared "Eye"
Battery
Compartment
1
