Atlantic Speaker User Manual

Assembly Instructions and Diagrams
Parts Included
A
2pcs
B
2pcs
C
2pcs
D
2pcs
E
4pcs
F
2pcs
G
2pcs
H-a
2pcs
H-b
2pcs
I
4pcs
Tools
If speaker
has the built in
mounting screw
Phillips Tip
then use (G), (H), and
Screw Driver
(I-a) or (I-b) for
various speakers.
(not provided)
C
Flat Tip
Screw Driver
(not provided)
Required
B
Power Drill
(not provided)
Optional
1
B
speaker
wire
management
A
2 Mounting Speakers:
G
F
D
If speaker
has the built in
mounting screw
then use (G), (H), and
(I-a) or (I-b) for
E
various speakers.
3
Use the double sided
I
tape (J). Peel backing
to expose adhesive
and mount on item (C).
Screw mount directly
to the speaker.
Mark holes on bottom
of speaker and drill
holes. Screw speaker
onto speaker stand.
(Wood screws
NOT provided.)
4
H-a
or
H-b
OR
Adjust to desired
height by unscrewing
and extending (B).
OR
c 5
U.S. and other foreign patents pending
Patentes de los EUA y países extranjeros en trámite
Brevets én sours pour Etats Unis et autres pays étrangers
U.S. und andere ausländische Patente sind hängig
All Rights Reserved / Derechos Reservados /
Tous droits réservés / Alle Rechte vorbehalten
Made in China /
Hecho en China / Fabriqué en Chine /
Hergestellt in China
R 2.0 051021 #77335067
