- Page 1 DS-7200HVI-ST/SE Series DVR Technical Manual...
- Page 2 Overview Developed on the basis of the latest technologies, DS-7200HVI-ST/SE Series Digital Video Recorder combines with the advanced H.264 video encoding and decoding standard and maintains high performance rock-solid reliability and nger recording service time. DS-7200HVI-ST/SE Digital Video Recorder can be used as a standalone video surveillance product, as well as to build up a powerful surveillance network which is suitable for home or small-scale business applications.
-
Page 3: Main Features
Main Features User-friendly GUI for easy operation Up to 1024×768 VGA output resolution Simultaneous VGA and CVBS output CIF/QCIF real-time resolution Normal and event recording parameters configurable per individual camera Partial digital zoom by using mouse when in PTZ control mode 4/8/16-ch synchronous playback Support dual stream Different recording storage period configurable for each channel... -
Page 4: Hard Disk Management
Functions & Performances ompression PAL/NTSC adaptive video inputs. H.264 video compression with high reliability and superior definition. OggVorbis audio compression standard. Independent video encoding parameters, including frame rate, resolution, bit rate, video quality, etc. Scheduled and event recording parameters configurable for per individual camera. - Page 5 Multiple recording types, including manual, continuous, alarm, motion, motion | alarm and motion & alarm recording, etc. 8 recording time periods with separate recording types. Pre-record and Post-record time for alarm and motion detection, and pre-record time for schedule and manual recording. Lock and unlock of video files.
- Page 6 RS -485 transparent channel transmission. Event alarm and exceptions upload to remote management host. Remote manual recording. Remote video image capture in JPEG format. Voice talk and broadcast. Built-in WEB Server. D evelopment Provision of SDK in Windows and Linux operating systems. Application software source code of Demo.
-
Page 7: Rear Panel & Interfaces
Rear Panel & Interfaces Rear Panel of DS-7204HVI-ST/SE USB Interface VIDEO OUT VIDEO IN AUDIO IN, AUDIO OUT VGA Interface RS-485 Interface 12VDC Power Supply Interface POWER... - Page 8 Rear Panel of DS-7208HVI-ST/SE USB Interface VIDEO OUT VIDEO IN AUDIO IN, AUDIO OUT VGA Interface RS-485 Interface 12VDC Power Supply Interface POWER...
- Page 9 Rear Panel of DS-7216HVI-ST/SE USB Interface VIDEO OUT VIDEO IN AUDIO IN, AUDIO OUT VGA Interface RS-485 Interface 12VDC Power Supply Interface POWER...
-
Page 10: Specifications
Specifications Model DS-7204HVI-ST/SE Video H.264 compression Analog video 4-ch, BNC connector (1.0 Vp-p, 75 Ω); input PAL / NTSC adaptive Audio G.711 compression Audio input 1-ch,RCA connector (2 Vp-p, 1 kΩ) Video/Audio 1-ch, RCA (2.0 Vp-p, 1 kΩ) input Voice talk input (Using AUDIO IN) VGA output 1-ch, resolution: 1024 ×... - Page 11 Model DS-7208HVI-ST/SE Video H.264 compression Analog video 8-ch, BNC connector (1.0 Vp-p, 75 Ω); input PAL / NTSC adaptive Audio G.711 compression Audio input 1-ch,RCA connector (2 Vp-p, 1 kΩ) Video/Audio 1-ch, RCA (2.0 Vp-p, 1 kΩ) input Voice talk input (Using AUDIO IN) VGA output 1-ch, resolution: 1024 ×...
- Page 12 Model DS-7216HVI-ST/SE Video H.264 compression Analog video 16-ch, BNC connector (1.0 Vp-p, 75 Ω); input PAL / NTSC adaptive Audio G.711 compression Audio input 1-ch,RCA connector (2 Vp-p, 1 kΩ) Video/Audio 1-ch, RCA (2.0 Vp-p, 1 kΩ) input Voice talk input (Using AUDIO IN) VGA output 1-ch, resolution: 1024 ×...
