- Page 1 LED digital colour TV C22100DVB USER GUIDE...
-
Page 2: Safety Is Important
Introduction Thank you for purchasing this TV which has been designed and manufactured to give you many years of trouble free service. You may already be familiar with using a similar product but please take time to read these instructions which have been written to ensure you get the very best from your purchase. -
Page 3: Table Of Contents
Contents SAFETY INFORMATION Unit and Accessories Remote Control Aerial connection 10-15 Connecting external devices Common Interface slot Auto installation setup Source menu 18-25 Menu settings 26-31 Multimedia Operation 31-32 Recording Operation EPG menu TROUBLE SHOOTING GUIDE TECHNICAL SPECIFICATIONS Wall mounting options... -
Page 4: Safety Information
SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY BEFORE USE. Take note of the following safety information which appears on the back of the TV. CAUTION TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE ANY COVER SCREWS, NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. - Page 5 I MPORTANT SAFETY INFORMATION (Continued) This unit has been produced according to all current safety regulations. The following safety tips should safeguard users against careless use and the dangers connected with such use. Although this appliance has been carefully manufactured and rigorously checked prior leaving the factory, as with all electrical appliances it is possible for problems to develop.
-
Page 6: Headphone Warning
I MPORTANT SAFETY INFORMATION (continued) Liquids spilt into the unit can cause serious damage. Switch the set OFF and disconnect the mains power supply, then consult a qualified service person before attempting to use the unit again. Do NOT remove the safety covers. There are no useable or serviceable parts inside. You may invalidate the warranty. -
Page 7: Unit And Accessories
Unit and Accessories LED Indicator Remote Control Window (keep clear) The functions of the TV buttons are described below. Menu : Press to display the OSD menu, press again to exit the menu. CH+/- : Press to skip through the channels. Vol +/- : Press to adjust the volume. - Page 8 Unit and Accessories (continued) Batteries TV set Remote Control Power cable Mains adaptor QUICK START Remote Guide USER GUIDE Warranty Card GUIDE Remote Guide Quick Start Guide Warranty Card User Guide...
-
Page 9: Remote Control
Remote control Functions of remote control buttons Dependant on the model of theTV some keys will have no function Only used on TVs with Internet Player*. In this mode the remote does not control the TV. iViewer Press to control the TV again. If you have set the remote to work a Satellite receiver, the remote controls only the Satellite receiver and not the TV when... - Page 10 Remote control (continued) Dependant on the Model of the TV some keys will have no function *Dependant on Model Source Menu TV (Analogue) DTV ( Freeview ) SD1 (red card)* Menu SD2 (green card)* Help Picture Scart 1 This displays a page that gives telephone Scart 2 Sound numbers for service.
- Page 11 Remote control (continued) Dependant on the model of TV some keys will have no function *Dependant on Model iViewer HOLD TEXT...
- Page 12 Remote control (continued) Installing Batteries in the Remote Control 1. Remove the battery compartment cover at the rear of the remote control by pushing the retaining clip forward and pulling up. 2. Install the supplied batteries, ensuring the polarity matches what is shown in the battery compartment.
-
Page 13: Aerial Connection
Aerial connection USER GUIDE WARNING! ENSURE THE TV AND ALL ANCILLARY EQUIPMENT IS UNPLUGGED FROM THE MAINS BEFORE MAKING ANY CONNECTIONS! Connecting the TV Antenna Connect the TV antenna to the aerial socket with a 75 ohm co-axial plug. For best results use a high gain TV aerial, preferably roof or loft mounted. - Page 14 Connecting external devices (continued) Common Interface TV Signal Connect to USB device Satellite Box or Blue Ray DVD...
- Page 15 Connecting external devices (continued) CONNECTIONS Name Function Description Connect to power supply POWER Connect to USB device for multimedia Connect to the HDMI socket of your DVD or Satellite Box HDMI Connect to the PC VGA output to display PC graphics PC-IN PC audio input SCART...
- Page 16 Connecting external devices (continued) PC connection As PCs are sometimes still supplied with a ‘conventional’ CRT monitor, you may need to adjust the display settings of your PCs graphics card, otherwise the pictures may not appear correctly. Switch on your PC (still with your original monitor connected) no w select the screen resolution, and select 60Hz refresh rate.
-
Page 17: Connecting Video Camera And Video Recorder
Connecting external devices (continued) Connecting Video camera and Video recorder Video camera Connect the AV cable to the TV and to the video camera. Turn on both video camera and the TV. Select AV/CVBS source You can now see the playback picture from the video camera. Note: To connect the video camera using other cables, refer to the video camera instruction manual. -
Page 18: Connecting An Audio System
Connecting external devices (continued) Connecting an audio system You can supply the TV sound to the stereo system (A) with the Scart socket. Use a special scart cable SCART to RCA. (Please consult your hi-fi instructions for details). If you have a surround sound amplifier/decoder (B) Use the Scart cable or the special scart cable Scart to RCA. -
Page 19: Common Interface Slot
USER GUIDE Common Interface Slot USING YOUR COMMON INTERFACE SLOT Common Interface The Common Interface (CI) slot is designed to accept the Conditional Access Module (CAM) and Smart Card in order to view the pay TV programmes and additional services. Contact your Pay Per View TV service provider to get more information about the modules and subscriptions. -
Page 20: Auto Installation Setup
Auto installation setup Power On / Off the TV Power Switch On / Off Press the power switch to setting and the standby indicator will light red. To turn on the TV Press the power button on the TV or the button on the remote control, the standby indicator will light green. -
Page 21: Menu Settings
Bas c Use Menu Settings 1. Turn the TV on. 2. Press the MENU button on the Remote Control. 3. Use the buttons to navigate through the menu. 4. Press the EXIT button to exit the Menu. CHANNEL MENU Allows you to search channels and set up a variety of channel options. SETTING MENU: Allows you to setup a variety of setup options. - Page 22 Application Menu Settings (continued) Use the buttons to select the CHANNEL menu (as the picture above), press button to enter the menu. The CHANNEL menu includes the following options : Country Press buttons to select the Country. (Can be selected in ATV mode) Auto Search Press button to start auto search.
- Page 23 Menu Settings (continued) Manual Program menu for DTV Program Select the program you want to edit. Start Search Press button to start search. Channel Found Display the channel found. SIG. Quality Display the signal quality of the channel found. SIG. Strength Display the signal strength of the channel found.
- Page 24 Menu Settings (continued) Press button to enter the Favourite List. Favourite List Press button to Multimedia menu. Use the buttons to select the PICTURE menu (as the picture above), press button to enter the menu. Choose from Standard, Movie, Vivid and Personal. Picture Mode Note: Contrast, Brightness, Color and Sharpness can only be adjusted in the Personal mode option in the Picture Mode Settings.
- Page 25 Application Menu Settings (continued) Use the buttons to select the SOUND menu (as the picture above), press button to enter the menu. Sound Mode Allows you to select among: Standard, Music, Movie and Personal. Bass (Can be adjusted when the sound mode is set to User) Controls the relative intensity of lower pitched sounds.
- Page 26 Menu Settings (continued) Use the buttons to select the SETTING menu (as the picture above), press button to enter the menu. The SETTING menu includes the following options: Language Allows you to select menu language. OSD Timer Allows you to select the time for OSD menu displays on the screen.
- Page 27 Menu Settings (continued) Use the buttons to select the FUNCTION menu (as the picture above), press button to enter the menu. The FUNCTION menu includes the following options : Sleep Timer Allows you to setup the sleep timer to : 15min, 30min, 45min, 60min, 75min, 90min,105min, 120min and off.
- Page 28 Menu Settings (continued) Use the buttons to select the PC SETUP menu (as the picture above), press button to enter the menu. The PC SETUP menu includes the following options : H-Position Adjust the transverse position of the screen. V-Position Adjust the vertical position of the screen.
-
Page 29: Multimedia Operation
Multimedia Operation Note: Insert USB device and select DTV mode. Basic Operation Press the MENU button on the remote control to display the main menu. Select the CHANNEL menu using the buttons, then select USB using the buttons. Finally press the button to enter the Multimedia menu seen below. - Page 30 Multimedia Operation (continued) 1. My Music menu Select the music file Play the music My Music My Music Repeat All Repeat All Music: 2 Songs Music: 2 Songs Root(USB) 001. You are not alone.MP3 Root(USB) 001. You are not alone.MP3 002.Pretty Boy.MP3 002.Pretty Boy.MP3 4% 00: 50/03:46...
- Page 31 Multimedia Operation (continued) Picture View Select the photo, and press OK button to view as the picture below: Press button to view the previous/next photo. Zoom : Press the RED button on the remote control to zoom photo on the screen, when the photo is larger than full-screen, press button to move.
- Page 32 Multimedia Operation (continued) 4. My Record menu DVR SETUP Press button to select the item, and press Recorded List OK button to enter the submenu, or press MENU button to MULTIMEDIA menu. Recording Device Recording Preference Enter menu Select Recorded List Recorded List 07/11/06 09:15 09:15...
- Page 33 Multimedia Operation (continued) Recording Device My Recorder Device Type Slot Partition Free 1.8GB Used 12MB Total 1.8GB Move Change Select Format Disk Format Press button to select the item, and press button to select, and press OK button to confirm and back to previous menu, or press MENU to cancel the setting and back to previous menu.
-
Page 35: Recording Operation
Recording Operation (continued) During recording enter the Time Shift mode, the screen display will appear as below. Note1: You may get a message as seen below and it will disappear automatically at once. DVR DEVICE Device writing speed is too slow! Exit Note2: You may get a message as seen below if your recording stops for no reason. -
Page 36: Epg Menu
EPG menu TV GUIDE 13:10 20/07/2005 Display the 12:00 - 18:00 Preview the BBCi information programme BBCi - featuring news, sport, weather of the programme and TV guide BBCi Name 13:00 20/07 15:00 YLE TV1 BBC Ne Titanic Display the YLE PEILI No Information Available Channel list... -
Page 37: Trouble Shooting Guide
USER GUIDE TROUBLE SHOOTING GUIDE To assist in locating possible faults use the help guide below. No Picture, no sound Check that the TV is correctly plugged in. Check that the TV is connected to a suitable power source. Check the electrical supply is turned on. No Picture Ensure that the TV is powered on. -
Page 38: Technical Specifications
TECHNICAL SPECIFICATIONS Specifications of the TV that you have just purchased may vary from the information in this table due to technical innovations. TV Specifications TV System PAL / BG / DK / I Audio System BG / DK / I Screensize 22”(Diagonal) Resolution... -
Page 39: Wall Mounting
Wall Mounting The stand must first be removed. Place the TV face down. Remove the two screws on the back of the TV to release the stand. Remove and store the stand and screws. Use four machine screws to mount the TV on the bracket. This unit is VESA-Compliant and designed to be wall mounted with a VESA- Compliant 100mm x 100mm mounting kit.
