Summary of Contents for Goldmund Prolog Active
- Page 2 At Goldmund, we strive to lead in the creation, development and manufacture of the industry’s most advanced technologies, including audio and video systems. The guiding principle at Goldmund is to produce a precise sound with the least possible loss of quality through the different stages. Goldmund will never adopt a technology before it is sufficiently developed to satisfy the high quality standards we set.
- Page 3 !" & GOLDMUND PROLOGOS Active Speaker - 3...
- Page 4 PROLOGOS active speaker is quite simple and convenient. PLEASE DO NOT CONNECT ANY CABLES OR MOVE ANY PARTS BEFORE READING THE FOLLOWING INSTRUCTIONS. GOLDMUND PROLOGOS Active Speaker - 4...
- Page 5 This packaging has been designed especially to protect the speaker in transit. Use of alternative packaging will almost inevitably result in damage, which cannot be covered by the warranty. GOLDMUND PROLOGOS Active Speaker - 5...
- Page 6 Listening position Assembling the PROLOGOS frame. Rear-Left Rear-Right Depending on the room acoustics, the speakers may be standing parallel or slightly tilted toward the listener. GOLDMUND PROLOGOS Active Speaker - 6...
- Page 7 Adjust the 4 leveling screws of each foot to provide a stable position to the speaker • (3), the weight of the speaker should be put on the pointed bar for a better mechanical grounding. GOLDMUND PROLOGOS Active Speaker - 7...
- Page 8 Depending on the above mentioned factors, the maximum range will normally be from 5 to 20 meters. To use the PROLOGOS in wireless, follow these steps: Connect the speaker to a mains outlet using the power cords contained in the box. • GOLDMUND PROLOGOS Active Speaker - 8...
- Page 9 (hardware crossover). The PROLOGOS uses a full digital filtering, the crossover is made by software inside the DSP speaker board. Only an official Goldmund representative is able to load and change the configuration file, do not change it by yourself. GOLDMUND...
- Page 10 A wrong setting can damage the speakers; the warranty will not cover any factory change without the approval of an official Goldmund representative The PROLOGOS is automatically powered ON when it receives modulation. When the digital input does not receive any data for 3 seconds, the drivers are muted. They are de- muted as soon as a signal is present on the digital input and the orange led will light up.
- Page 11 Rated Power Consumption: 240W per unit • Amplifier dynamic Range: > 100 dB (no weighting) • Wireless audio stream from USB dongle or Goldmund Transmitter • Digital input & Digital output • 1 x soft dome tweeter, 1 x 7” medium, both selected for their high linearity and •...
