REMstar
®
www.respironics.com
Heated Humidifier
The REMstar Heated Humidifier is for use
with certain Respironics CPAP devices. The
humidifier moistens the air delivered by the
Respironics CPAP devices.

TABLE OF CONTENTS

Warnings & Cautions ........... 2
Symbols ................................ 2
Features ................................ 3
Set Up .................................... 4
Daily Use ............................... 5
Cleaning ................................ 6
Service .................................. 6
Specifications ....................... 7
Traveling ............................... 8
Warranty ................................ 8

Advertisement

Table of Contents
loading

Related Manuals for Respironics REMstar

Summary of Contents for Respironics REMstar

  • Page 1: Table Of Contents

    REMstar ® www.respironics.com Heated Humidifier The REMstar Heated Humidifier is for use with certain Respironics CPAP devices. The humidifier moistens the air delivered by the Respironics CPAP devices. TABLE OF CONTENTS Warnings & Cautions ... 2 Symbols ........ 2 Features ........ 3 Set Up ........

  • Page 2: Warnings & Cautions

    WARNINGS AND CAUTIONS! IMPORTANT! Read all instructions before using the humidifier. Use only with Respironics CPAP devices whose instructions specify the use of this humidifier. CAUTIONS! Indicates the possibility of damage to the device. US federal law restricts this device to sale by or on the order of a physician.

  • Page 3: Features

    Light Heater Plate Power Cord: Use the power cord included with your CPAP device. Power Jumper Cord: Plug this cord into the AC inlet on the Respironics CPAP device. Heater Plate: Warms the water in the water chamber. Indicator Light: When lit, this indicates that the heater plate has been turned on.

  • Page 4: Set Up

    SET UP 1. Place the CPAP device on the humidifier platform. Position the CPAP device so that the four feet match up with the humidifier base. 2. Connect the humidifier’s power jumper cord to the AC inlet on the device. Plug the CPAP device’s power cord into the AC connector on the humidifier.

  • Page 5: Daily Use

    DAILY USE 1. Rinse the chamber with water. Fill the chamber to the fill line with water (approx. 1-2/3 cups or 400 ml). Distilled water is recommended. Do not overfill the water chamber. Fill Line CAUTION! Always remove the chamber from the humidifier before filling with water.

  • Page 6: Cleaning

    CLEANING The water chamber should be cleaned daily or after each use. WARNING! Emptying and cleaning the water chamber daily will help to prevent mold and bacteria growth. WARNING! Allow the water in the chamber to cool down to room tempera- ture before removing it from the humidifier.

  • Page 7: Specifications

    SPECIFICATIONS Size Dimensions: 13.25” x 6.5” x 2.125” ( 33.7 x 16.5 x 5.4 cm Weight: < 1.85 lbs. (< .84 kg) Water Capacity 1 2/3 cups (400 ml) at recommended water level Operation Transport & Storage Product Use, Temperature: 41 to 95°...

  • Page 8: Traveling

    (1) year from the date of sale by Respironics, Inc. to the dealer. If the product fails to perform in accordance with the product specifications, Respironics, Inc. will repair or replace, at its option, the defective material or part.
