Panasonic TY-EW3D10U Operating Instructions Manual

Hide thumbs Also See for TY-EW3D10U:
Table of Contents

Advertisement

Quick Links

Download this manual
This product cannot be used as
sunglasses.
This 3D Eyewear can be used
only for Panasonic Plasma HDTVs
supporting 3D.
For the latest information on
applicable models, visit our web site.
http://panasonic.net/
This product can be worn over vision
This product can be worn over vision
correction glasses.
Thank you for purchasing a Panasonic product.
Before operating this product, please read the instructions carefully, and save this
manual for future use.
Before using this product, be sure to read "Safety Precautions" (
Operating Instructions
Model No.
Contents
Safety Precautions ······························ 2
Identifying Controls ····························· 4
Using Precautions ······························· 5
Using for the fi rst time ························· 7
Accessories ········································· 7
Using the 3D Eyewear ························ 8
Storage and Cleaning ························· 9
Replacing the batteries ······················· 9
Specifi cations ···································· 11
Limited Warranty (for Canada) ·········· 14
3D Eyewear
TY-EW3D10U
pages 2 - 3).
TQZJ230
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TY-EW3D10U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic TY-EW3D10U

Summary of Contents for Panasonic TY-EW3D10U

  • Page 1: Table Of Contents

    This product can be worn over vision This product can be worn over vision correction glasses. Thank you for purchasing a Panasonic product. Before operating this product, please read the instructions carefully, and save this manual for future use. Before using this product, be sure to read “Safety Precautions" ( pages 2 - 3).

  • Page 2: Safety Precautions

    Safety Precautions Warning About Prevention of Accidental Ingestion „ Do not store batteries, the band accessory or the nose pad in „ places where small children can reach. There is a danger small children could swallow such parts by mistake. If a child accidentally swallows such parts, seek immediate medical attention.
  • Page 3 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Consult the Panasonic Service Center or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, follow the attached installation instructions. Any changes or modifications not expressly approved by Panasonic Corp.

  • Page 4: Identifying Controls

    Identifying Controls „ Battery case „ Fitting the battery ( page 9) When using for the first time, remove the insulating sheet. page 7) „ Infra-red receiver „ Receives infra-red signals from the television. The liquid crystal shutter open/close timing is controlled by receiving infra-red signals from the television, which provide 3D expression of the images.

  • Page 5: Using Precautions

    Using Precautions „ Liquid Crystal Shutter (Lens) „ Do not apply pressure to the liquid crystal shutter. Also, do not drop or bend the 3D Eyewear. Do not scratch the surface of the liquid crystal shutter with a pointed instrument etc. Doing so may cause damage to the 3D Eyewear, and reduce the quality of the 3D image.

  • Page 6: Viewing 3D Images

    „ For comfortable viewing „ View the screen at a distance at least 3 times of the effective height of the screen. Recommended distance: For a 50-inch television about 6’ 2” (1.9 m) For a 54-inch television about 6’ 6” (2.0 m) For a 58-inch television about 7’...

  • Page 7: Using For The First Time

    Using for the first time „ Remove the insulating sheet „ Attach the specialized band „ „ If the 3D Eyewear slips out of place, use the specialized band included to hold it in place. Specialized band Attach the band to the left and right tips of the frame, and adjust the length.

  • Page 8: Using The 3D Eyewear

    Using the 3D Eyewear „ Using the television menu controls, set so that 3D images are „ shown. 1. (When 3D image signals are being received) press the MENU button on the television remote control. 2. Select "Setup", and press the OK button. 3.

  • Page 9: Storage And Cleaning

    Storage and Cleaning Clean using a soft, dry cloth. Wiping the 3D Eyewear with a soft cloth that is covered in dust or dirt may scratch the eyewear. Shake off any dust from the cloth before use. Do not use benzene, thinner, or wax on the 3D Eyewear, as doing so may cause the paint to peel off.

  • Page 10: Troubleshooting/Q&A

    Troubleshooting/Q&A Are the image settings switched to 3D images? Some 3D image signals are not automatically recognized as 3D images. Set “3D Eyewear” to “On”. For details, see the television operating instructions. Is there a sticker or other such item blocking the infra-red reception section on the 3D Eyewear? If the eyewear stops receiving infra-red signal from...

  • Page 11: Specifications

    Specifications Lens type Liquid Crystal Shutter Batteries Coin-shaped lithium battery CR2032 (duration) (approx. 75 hours in continuous use) Width: 6.97” (177 mm) Dimensions Height: 1.82” (46 mm) Overall length: 6.86” (174 mm) Power supply DC 3 V Main body: Resin Materials Lens section: Liquid crystal glass Mass...

  • Page 12: Limited Warranty (For U.s.a. And Puerto Rico Only)

    Limited Warranty Coverage (For USA and Puerto Rico Only) If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company (referred to as “the warrantor”) will, for the length of the period on the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a)
  • Page 13 For hearing or speech impaired TTY users, TTY: 1-877-833-8855 Accessory Purchases (United States and Puerto Rico) Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pstc.panasonic.com Or, send your request by E-mail to: npcparts@us.panasonic.com...

  • Page 14: Limited Warranty (For Canada)

    One (1) year This warranty is given only to the original purchaser, or the person for whom it was purchased as a gift, of a Panasonic brand product mentioned above sold by an authorized Panasonic dealer in Canada and purchased and used in Canada, which product was not sold “as is”, and which product was delivered to you in new condition in the original packaging.
  • Page 15 ENGLISH - 15...
  • Page 16 Panasonic Corporation Web Site : http://panasonic.net/ © Panasonic Corporation 2010...
