Instructions for use

MICROWAVE OVEN
Contents
EN
Installation and connection
EN
Built-in furniture
Prepare the Cabinet
English
Install the oven
Overall view
Utensils, 15-16
9
145

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MWX 222.1 X and is the answer not in the manual?

Questions and answers

Related Manuals for Hotpoint MWX 222.1 X

Summary of Contents for Hotpoint MWX 222.1 X

  • Page 1: Table Of Contents

    Start-up and use, 8-10 Operation instruction Important safety instructions, 11-14 Utensils, 15-16 Utensil Test Materials you can use in microwave oven Materials to be avoided in microwave oven MWX 222.1 X Maintenance and care, 17 Cleaning Troubleshooting, 18 Assistance, 1...
  • Page 2 Installation Installation and connection ! Read these instructions carefully before using your microwave oven, and keep it carefully. This appliance is only intended for domestic use. If you follow the instructions, your oven will provide you with 2. This oven is intended for built-in use only. It is not many years of good service.
  • Page 3 A. Built-in furniture The built-in cabinet shall not have a rear wall behind the appliance. Minimum installation height is 85cm. Do not cover ventilation slots and air intake points. (45) (45)
  • Page 4 Installation B. Prepare the Cabinet CENTER LINE FRONT EDGE 1. Read the instruction on the BOTTOM CABINET TEMPLATE, put the template on the bottom plane of cabinet. SCREW A BRACKET CENTRE LINE 2. Make marks on the bottom plane of cabinet according to marks “a” of the template. Screw A BRACKET 3.
  • Page 5 C. Install the oven BRACKET 4. Install the oven into the cabinet. • Make sure the back of the oven is locked by bracket. • Do not trap or kink the power cord. Screw B Installation Hole 5. Open the door, fix the oven to the cabinet with Screw B, at the installation hole.

  • Page 6: Mwx 222.1 X

    Installation Turntable Installation MWX 222.1 X Model: a) Never place the enamel tray upside down. The Rated Voltage: 240V~50Hz enamal tray should never be restricted. Rated Input Power 1450W (Microwave): b) Both glass tray and turntable ring assembly must always be used during cooking.

  • Page 7: Setting Up Your Oven

    Setting up your oven Names of Oven Parts and Accessories A) Control panel B) Turntable shaft Remove the oven and all materials from the carton C) Turntable ring assembly and oven cavity Your oven comes with the following D) Glass tray accessories: E) Observation window Enamel Tray...

  • Page 8: Start-Up And Use

    Start-up and use Operation instruction 5) Press “ START ” to start cooking. This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for Note: cooking. the step quantities for the adjustment time of the coding switch are as follow: 1.Clock Setting 0---1 min...
  • Page 9 4) Press “START” to start cooking. “Grill/Combi.” Pad Instructions Microwave Grill Order Display Power Power Tabella Menu Automatico: 100% Menu Weight Display Time 200 g 1'20” Pizza 400 g 2’30” Note: If half the grill time passes, the oven sounds twice, 250 g 4’00”...
  • Page 10 Start-up and use 7. Multi-Stage Cooking 9. Lock-out Function for Children Two stages can be maximally set. If one stages is Lock: STOP defrosting, it should be put in the first stage. In waiting state, press “ ” for 3 seconds, The buzzer will ring once after each stage and the next there will be a long “beep”...

  • Page 11: Important Safety Instructions

    Important safety instructions 7. Read and follow the ”PRECAUTIONS TO AVOID POSSIBLE EXP OSURE TO EXCESSIVE MICROWAVE ENERGY”. WARNING To reduce the sk of re, electr c shock, 8. When ng fo n pl c or paper njury to persons or exposure to ners, keep an eye on the oven exces ve crowave oven energy...

  • Page 12: Important Safety

    Important safety instructions 16. If the supply cord s damaged, t 24. The appl ance s not ntended for must replaced use by persons ( nclud ng ch ldren) manufacturer, ts serv ce agent or w th reduced phys cal , sensory or s m larly qual f ed persons n order mental capab l t es, or lack of to avo d a hazard.
  • Page 13 Important safety instructions 32. Keep the appl ance and ts cord out of reach of ch ldren less than 8 years. 33. Th s appl ance s ntended to be used n household and s m lar appl cat ons such as: -sta k tchen a reas n shops, o ces and other work ng env ronments;...
  • Page 14 Important safety instructions DANGER Disposal Electric Shock Hazard Touching some of the internal • When disposing of packaging material: observe local components can cause serious personal injury or death. legislation so that the packaging may be reused. Do not disassemble this appliance. •...

  • Page 15: Utensils

    Utensils Utensil Test: See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.” 1) Fill a microwave-safe container with 1 cup of cold There may be certain non-metallic utensils that are not water (250ml) along with the utensil in question.

  • Page 16: Materials To Be Avoided In Microwave Oven

    Utensils Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal May cause arcing. Transfer food into microwave-safe dish. handle Metal or metal-trim- Metal shields the food from microwave energy. Metal trim may cause arcing. med utensils Metal twist ties May cause arcing and could cause a fire in the oven.

  • Page 17: Maintenance And Care

    Maintenance and care Cleaning Be sure to unplug the appliance from the power supply. 1) Clean the inside of the oven after using with a slightly damp cloth. 2) Clean the accessories in the usual way in soapy water. 3) The door frame and seal and neighboring parts must be cleaned carefully with a damp cloth when they are dirty.

  • Page 18: Troubleshooting

    Troubleshooting Problem Possible causes/Remedy Microwave oven interfering TV reception • Radio and TV reception may be interfered when microwave oven operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal. •...

  • Page 19: Assistance

    Assistance Before contacting the After Sales Service: • make sure you can’t fix the anomaly yourself; • if you can’t, contact an authorized Technical Assistance Service. ! Never engage non-authorized technicians. Report: • the type of anomaly; • the oven model (Mod.); •...
  • Page 20 195XXXXXX.00 10/2013 PN:261800318701...
